Acme Furniture Glancio 97257 Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
Thank you for purchasing this quality product. Be sure to check all packing material
carefully for small parts which may have come loose inside the carton during
shipment.Separate,identify and count all parts and metal hardware.Compare with
parts list to be sure all parts are present. If any part(s) are missing or damaged,please
contact your local fumiture dealer.For efficient and speedy service,please indicate the
model number and code letter of part(s) needde.
*** Do not fully tighten screws until fully assembled ***
DESCRIPTION
①
②
③
HARDWARES REQUIRED
L-ALLEN KEY φ 5MM
A
Bolt φ 5/16"x 1
B
Lock Washer φ 5/16"
C
Flat Washer
D
Bolt 3x12
E
F
Attention:
***Some number parts listed on the instruction sheet may not be in parts bag as
they may already be assembled.
Carefully check parts and packing materlals prior to odering replacements.
MODEL #97257 DRESSER
COMPONENT PARTS
PART NAME
Table
Leg
Shelf
"
3/4
φ 5/16"xφ 19mm
1PC
8PCS
8PCS
8PCS
8PCS
4PCS
Q'TY(PCS)
1PC
4PC
1PC
1
