Diasonic DDR-3032 User Manual

Diasonic user's manual digital voice recoder & music player model : ddr-3032/ddr-3064/ddr-3128/ddr-3256 ddr-3032r/ddr-3064r/ddr-3128r/ddr-3256r
Hide thumbs Also See for DDR-3032:

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
DIGITAL VOICE RECORDER & AUDIO PLAYER
MODEL : DDR-3032/DDR-3064/DDR-3128/DDR-3256
DDR-3032R/DDR-3064R/DDR-3128R/DDR-3256R
User's Manual
Thank you for choosing our DIGITAL VOICE RECODER & MUSIC
PLAYER from DIASONIC TECHNOLOGY CO. LTD. Before use,
read through the User's Manual carefully. We advise you to keep
this user's manual to avoid possible technical difficulties.
Copyright
2001, DIASONIC TECHNOLOGY CO. LTD. All rights
reserved.
No part of this User's Manual may be reproduced, translated or used
for profits. It is against copyright law to violate these rules. The
content of this User's Guide is produced under the greatest care of
our company. To improve the quality and function of the product, the
content of manual can be modified without any advance notice. Our
company does not take any responsibility for the loss or damage by
the modification of the manual.
MP3 files should not be used for the purpose of commercial use or
service other than personnel use. It is in conflict with the domestic
copyright law in case of below.
It is prohibited to copy recorded matter other than the purpose of
personnel enjoyment by law.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DDR-3032 and is the answer not in the manual?

Questions and answers

Related Manuals for Diasonic DDR-3032

Summary of Contents for Diasonic DDR-3032

  • Page 1 DIGITAL VOICE RECORDER & AUDIO PLAYER MODEL : DDR-3032/DDR-3064/DDR-3128/DDR-3256 DDR-3032R/DDR-3064R/DDR-3128R/DDR-3256R User's Manual Thank you for choosing our DIGITAL VOICE RECODER & MUSIC PLAYER from DIASONIC TECHNOLOGY CO. LTD. Before use, read through the User's Manual carefully. We advise you to keep this user's manual to avoid possible technical difficulties.

  • Page 2: Ddr-3000 Series

    1. DDR-3000 SERIES 1) Suggestions for Users 2) About DDR-3000 SERIES 3) Functions and Features 4) Names of Each Part/ LCD Screen 5) Use of Battery and Components in Package 6) Basic Directions for Use 7) How to Use Buttons 8) How to Set Menu in VOICE/MP3/FM Part 9) Operation of Playback Dial 10) How to Record and to Set Up Mode...
  • Page 3 LCD of DARK-BLUE colors with attached BACKLIGHT on the back. Additional DVR-EXPLORER / MAIL MANAGER DDR-3000 SERIES is the player, which is convenient when transmitting recorded data, and MP3 files from one PC to another, and which helps regenerating, managing saved data and sending data through e-mail.
  • Page 4 TIMER RECORDER FUNCTION: can receive and record radio broadcast automatically -daily, weekly or monthly. ALARM PLAY FUNCTION: can play messages automatically at requested time after setting time and date. Repeat & A-B Repeat function: can play as long as you want to, and you choose the intervals between two part that you want to listen.
  • Page 5 Slide open the battery cover. Put two LR 03 type batteries in accordance with (+) (-) diagram inside of the device, and slide the cover back on. Battery: LR 03 or similar batteries of same kind (size "AAA" or UM-4) Check the battery life by pressing the PLAY/STOP button or REC button.
  • Page 6 Power ON/OFF Press Playback or REC button for 2seconds, device will power up and LCD screen will be displayed as shown below. If no buttons are pressed within 1 minute, device will power off automatically to conserve power. Power off manually: Press "RADIO/OFF" for 5 seconds. We recommend that you to set up the time right after inserting the supplied batteries.
  • Page 7 FM RADIO SECTION(RADIO KEY) BUTTON KEY ACTION WHEN RECEIVING FM SIGNALS Start to create and set channels for each FM station Select channel memory(01~10) and frequency Select channel memory(01~10)and frequency Start to record FM radio broadcast Set menu MENU Change to FM memory channel mode and release VOL+ Turn up the volume...
  • Page 8 1. Map of menu-Voice section When pressing menu button, choose MODE. Then LCD screen displays the content of MODE. After you choose the part that you want by moving PLAYBACK button upward and/or downward, then press the button in to save it in the memory. 2.
  • Page 9 Move Playback dial upward and downward, (2) press button in When setting menu, (1)move the button up and down(when it is moving up and down, playback dial does not work), and (2) press button in. Then the section of menu is set. (1) Move the button up and down (2) Press button in.
  • Page 10 How to Set ARS Press MENU button and select ARS while player is in the stopped position, When ARS is ON, recoding will pause automatically when there is no sound present so that you can save and minimize recording time ("ARS PAUSE" will appear repetitively while it is in action).
  • Page 11 Search & Play If you press PLAYBACK dial for 2 seconds, the recorder will play its every message for just 10 seconds orderly. While the recorder is scan-playing, if you press PLAYBACK dial one more time, you can hear the message of the number you chose. As for playback of MP3, its Search &...
  • Page 12 For TIMER/REC, SET mode and time need to be fixed. Press MENU buttons, "MODE" appears on LCD screen. Set “TMR(Timer)” by moving and pushing PLAYBACK dial. Delete "ON" by shifting PLAYBACK dial and set PLAYBACK dial. DAT(DATE) flickers. Each number for year (Y), month (M) and day (D) will flicker one by one by pressing PLAYBACK dial so that select numbers by moving the button.
  • Page 13 How to Set ALARM/PLAY Function ALARM/PLAY is the function which automatically starts the message that you selected before. Bring the message that you want to play with ALARM/PLAY function on LCD screen.(See No. 1 of How to Play to know specifically) By moving PLAYBACK dial up and down, bring "ARM(ALARM)"...
  • Page 14 How to Connect with External Microphone -. Put the plug of a microphone into the external microphone terminal of the player. When the external mike is connected with the microphone terminal of the player, internal microphone does not work. Connection with external appliances The message that you recorded with DDR-3000 SERIES through audio cable and telephone adaptor(for either portable or domestic use) can also be recorded with other external appliances such as cassette...

  • Page 15: Cd-Rom Drive

    If you want to check the condition of recorded message, see 11. of "How to Play in VOICE mode" DVR-Explorer is a managing program for DDR-3000 SERIES which transfer or plays MP3 files from computer to DDR-3000 SERIES, it manages recorded voice or FM radio file (DVF) from DDR-3000 SERIES and has following features.
  • Page 16 (1) Insert the DDR-3000 Series setup CD into the CD-ROM drive and it will start automatically. If Auto-run doesn't work execute setup file "CD-ROM:\setup.exe" or "CD-ROM:\Voice Bank\setup.exe". Setup will progress automatically. Once setup is completed software icon will be installed in the START Menu. (2) Using the supplied USB Cable connect the USB port terminal on the DDR-3000 Series to USB port on the Computer (PC ONLY).
  • Page 17 Figure of Software Play Manage Window File Manage Window Flash Memory Manage Window Flash Memory Transfer list Manage Window Manage Window (1) Paying MP3, WAV, CD and DVF Double click on MP3, WAV, Audio CD Track and DVF file on file control window or use drag and drop to playlist for instant play.
  • Page 18 (4) Buttons Particular information Button Function print Prints file list in flash memory. reload Re-reads the information on flash screen. Choose the file stored in flash memory, delete then press this button to delete the file. Choose the files to be move to flash memory for file Transfer to flash manage window, then click this button to transfer memory...
  • Page 19 It's very simple to transfer MP3 file to DDR-3000 SERIES. Mentioned up at top, select MP3 files from file manage window and choose folder manage window. Then, drag and drop files to flash memory manage window. Also, click on icon from flash memory managing section for same reaction.
  • Page 20 The way to transfer DVF file to DDR-3000 Series is choose from Album Managing section then left mouse click on the file you want transferred, select icon. Procedure is same as transferring MP3 file to the DDR-3000 Series. Through steps 5). 6), you can easily transfer DVF or MP3 files in the flash memory.
  • Page 21 Just like formatting a hard disk on a computer, the flash memory used in the DDR-3000 Series can be reset (formatted). All the data in the flash memory will be lost when formatting. Select "File" from the main tool bar, then select 'Format Flash Memory' to format the flash memory.
  • Page 22 Special Features Play/Record DVF file Voice mail function: auto appending at mail program Creates self play function : voice file+player Edit DVF file : delete/insert beginning, ending, and/or middle of recording 16various voice effect Mail Manager is a program that plays self created voice files (DVF files) from the DDR-3000 Series.
  • Page 23 F2 : Play F3 : Rewind F4 : Fast Forward F5 : (Pause/Stop) MODEL Voice file+player(.exe) VOICE RECORD Deleting of front radio (stereo/ option) DDR-3032/ DDR-3064/ DDR-3128/ 3032R 3064R 3128R SHQ: 136min SHQ: 272min SHQ:544min Recording HQ : 272min HQ : 544min...

  • Page 24: El/ Back Light

    Easy to find convenient and easy tracks Search Repeat Playback of one track or all tracks & optional playback Network USB 1.1 Hard disk space of more than CPU 200MHz, RAM 64Mb and 20MB System requirement windows98 , windows2000 , windows ME , windows XP interface Sound Bluster 16 Sound card...
  • Page 25 5) Breakdown or damage caused by fire, pollution, and any natural disaster. 6) Breakdown or damage caused by lealcage from battery. 7) When accessories(battery) need replacement. <Request when mailing> Please beware of following when mailing. 1. Contact our customer service department to receive a RMA # before mailing in the product.

  • Page 27: Warranty Card

    WARRANTY CARD Product Category: Digital Voice Recorder Model: DDR-3000 SERIES The Term of Guarantee: 1 Year Date of Purchase: . . . Name PURCHASER Address Telephone Name SELLER Address Telephone Please refer to our customer service department for any information or breakdown on the product.
