Thank you for purchasing Diasonic DDR-6000R, a digital voice recorder and audio player. Please read this
manual before using the product.
use.
It is recommended to keep this manual near the product for convenient
- 1 -
DDR-6000R
User Manual
Advertisement
Table of Contents
Related Manuals for Diasonic DDR-6000R
Summary of Contents for Diasonic DDR-6000R
-
Page 1: User Manual
User Manual 그림 추가 (제품 빗면 그림) Thank you for purchasing Diasonic DDR-6000R, a digital voice recorder and audio player. Please read this manual before using the product. It is recommended to keep this manual near the product for convenient use. -
Page 2: Information To The User
Store this manual in a separate place as this manual contains important information for the operation of the product. In case the user loses the manual, Diasonic Technology does not separately provide a manual. All manuals are provided with the product. - Page 3 DIASONIC Technology has all copyrights of this user manual. Reproduction, distribution, and commercial use of a part of or the entire user manual without prior consent of DIASONIC Technology are strictly prohibited by laws. All information contained in this manual has been carefully studied and written and is subject to change without prior notice for functional and performance improvement.
- Page 4 Table of Contents - 4 -...
-
Page 5: Safety Notes
● Do not place the device near a magnet. The speakers may not function. ● Diasonic Technology is not responsible for any damage caused by the use of this device or damage claim made by a third party. ● Diasonic Technology is not responsible for the loss of data caused by other actions than repair services by Diasonic Technology personnel. -
Page 6: Features And Characteristics
Features and Characteristics Diasonic Digital Voice Recorder is a next-generation portable digital recorder equipped with the state-of-the-art technologies. With this digital voice recorder, the user can record and play voice with the best quality in various recording ways – SHQ, HQ, and SP. The device supports various playing methods (including speakers and earphones) as well as diverse file formats including MP3 and WMA. - Page 7 Parts and Configuration Main Body Speaker Earphone Jack Line-in Jack Menu Button Play Button Erase Button USB Jack Hold Switch Battery Cover FM FREQUENCE Mode Battery Status Folder Index REC Quality Play Time - 7 -...
-
Page 8: Checking The Remaining Battery
If the full-battery icon is not displayed after a new battery is inserted, check whether the battery has been correctly inserted. If the battery is correctly inserted, immediately remove the battery and contact Diasonic Technology for repair. - 8 -... - Page 9 Battery Hours (at Normal Temperature) Earphones Speaker Playing Earphones Playing Battery Recording (Volume: Middle) (Volume: Middle) (Volume: Middle) Alkaline Battery Approximately 00 Approximately 00 Approximately 00 Size ‘AAA’ LR03 hours hours hours Notes ● Do not mix different types of the batteries. ●...
-
Page 10: Basic Operation
Basic Operation Turning On/Off Power ● Turning On the Power Press Play button for 0 seconds to turn on the power. ● Turning Off the Power Press Play button for 0 seconds to turn on the power. Hold Switch Before using the player, check whether the hold switch is disabled. ●... - Page 11 Recording With the voice recorder, the user can record not only voice but also other various music sources from cassette, MD, MP3 player, audio, telephone, mobile phone, and FM radio. ● Various Input The user can record audio data not only from the internal microphone but also from external microphones and external devices connected through the line-in port.
-
Page 12: Voice Recording
Voice Recording With the voice recorder, the user can record conversations and lectures. The recorded files are stored under Voice folder and the file name format is MIC001_SHQ.MP3. By accessing the PC, the user can check the files. ① Select the DIR in the Voice menu, and select the folder. (See the Menu Setup.) ②... - Page 13 ● Recording from External Device By connecting an external device through the Line-in cable, the user can record sound sources from the cassette, MD, MP3 player, and the stereo set. Set the volume of the external device properly before starting recording. ①...
- Page 14 ● Recording from Mobile Phone (Option) The user can record the mobile phone conversations through the earphones. ① Connect the mobile phone and the voice recorder through the Line-in port and the earphone jack of the mobile phone. ② Change S_SEL into E_MIC in the Voice menu. (See the Menu Setup.) ③...
-
Page 15: Voice Playing
Playing After entering Voice or Music mode, the user can search files to play by pressing the Play button right and left. The user can play the file in various modes at various quality by selecting Repeat and EQ in the Menu Setup. The Voice mode does not support EQ feature. -
Page 16: Fm Radio Reception
Playing Next File and Fast Forwarding Button Stop Playing Operation Selects the next file. Selects and plays the next file. Automatically adds next files to select. Fast forwards the current file. Goes back to the beginning of the file 5 seconds after the playing starts. -
Page 17: Deleting Preset Channels
Storing Auto Preset Channels The user can have maximum 20 FM frequencies automatically searched and stored. To use this feature, press the Erase button long. Preset Channel ① Select the Preset mode by pressing the Play button. ② By moving the Play button right and left, the user can listen to the stored channels. -
Page 18: Deleting A Folder
Deleting a Folder The user can delete an entire folder. ① Select the folder to delete, and press the Erase button long. ② “Erase” will be displayed on the LCD. ③ Press the Erase button again to delete the folder. If the user presses other buttons, the folder will not be deleted. Deleting All Files The user can delete all files stored in the voice recorder. -
Page 19: Menu Setup
Menu Setup By setting up the menus, the user can use various features more efficiently. To set up menus, press the Menu button long. Menu Selection Move the Play button up and down and select a menu item. ① ② Press the Play button to apply the selected menu item. ③... - Page 20 Menu Band (FM Band Setting) The user can select one of the following FM bands: USA: 87.5MHz~108.0MHz (100KHz STEP) JRP: 76.0MHz~108.0MHz (100KHz STEP) EUP: 87.50MHz~108.00MHz (50KHz STEP) R_QTY (Recording Quality Setting) When recording voice or FM radio broadcasting or through the Line-in cable, the user can set the bit rate: SHQ: High HQ: Middle...
- Page 21 REP (Reception Method Setting) The user can play the folders in the same folder in the following ways: NOR: To play the files once in order. ONE: To repeat the current file. ALL: To continue playing all files in order. SHUFF: To randomly play all files in the folder.
- Page 22 S_DEF (Default Menu Values Setting) The user can call the factory menu setup. Yes: To call the factory menu setup. No: Not to call the factory menu setup. F_INF (Version Information) The user can view the FW version. V_100: Version information R_027: Release information M_INF (Folder Information) The user can check the total folder size and the currently used folder size.
-
Page 23: Installation Of Window 98 Se Driver
Windows ME, 200, and XP automatically detects the voice recorder. Installation of WINDOW 98 SE Driver ① Download Win98 SE driver to C:W of the PC from the web site of Diasonic Technology. ② Double-click on install.bat file under the downloaded directory. - Page 24 ③ After the PC is rebooted, connect the voice recorder to the PC using the USB cable. Select “Search Driver (Recommended) in the Hardware Installation Wizard, and click on the [Next] button. ④ When “Unknown Device” is displayed, click on the “Next” button. ⑤...
-
Page 25: Disconnecting The Usb Port
Now, the device has been installed. ⑨ Check the installation state. ⑩ [My Computer] - [Control Panel] - [System] - [Device Manager] - [Hard Disk Controller] Disconnecting the USB Port Before removing the voice recorder, disconnect the cable first. Otherwise, the data may be lost or damaged. -
Page 26: Folder And File Management
Folder and File Management When the voice recorder is connected to the PC, the recorder will be recognized as a portable disk. In the portable disk drive, FM, Line, Music, and Voice folders are created. The user can create folders and write, read, and delete files in the voice recorder like in the portable hard disk. The user can also format the portable disk. -
Page 27: Voice Folder
FM Folder Under the FM Radio folder, the FM radio broadcasting recorded files are stored. Maximum recorded files can be created in order. FM001_SHQ_1077.MP3 Mode Recording No. Recording Quality Recording Frequency Voice Folder Under the Voice folder, the voice recorded files are stored. Maximum recorded files can be created in order. -
Page 28: Firmware Upgrade
By upgrading the firmware, the user can improve performance of the voice recorder and correct errors in the recorder. * The user can download free firmware upgrade files from the web site of Diasonic Technology. Ater downloading the upgrade file, copy the file to the Root directory of the voice recorded connected to the PC. -
Page 29: Troubleshooting
Troubleshooting When a breakdown is suspected, please check the following: Symptom Things to Check Measures Check if the hold switch is in On position. Move the hold switch to Off position. Check the battery state. Replace the battery. The power is off. Check the insertion of the battery. - Page 30 The speakers do not Check whether the earphones are Disconnect the earphones. generate sound. connected. The earphones do not Check whether the earphones are Connect the earphones. generate sound. connected. The FM radio reception is poor in the The device and the earphones The player does not frequency shadow areas, inside the function as antennas.
-
Page 31: Specifications
Specifications Model DDR-6000R Mode MP3 Format 32Kbps / 16Kbps FILE Voice: 99ea/ MP3 FM Record Stereo (87.5MHz~108MHz) Voice Built-in Mic / Line (external Mic) RECORD/ 45db (50dB input 1KHz, speaker Output 200mW)75KHz Play Distortion 3%±0.2 (dB input 1KHz, speaker Output 100mW: HQ mode) Freq. -
Page 32: Product Warranty
DIASONIC Technology at 82-031-474-0852. ● Warranty (Service Policy) Free repair services will be provided in compliance with the free repair policy of DIASONIC Technology. If a breakdown occurs during the warranty period, bring the product with the warranty card to the sales agency or the service center of DIASONIC Technology. Free repair service will be provided only when the purchase date and the name of the sales agency appear on the warranty card. -
Page 33: Warranty Card
Seller Address Telephone ● Please contact the sales agency or customer center of DIASONIC Technology Co., Ltd. for breakdown of the product. ● Exchange, (charged or free) repair services, refund, and part-keeping periods comply with regulations of the customer protection act.
