DIGITAL VOICE RECORDER
MODEL : DDR-5100
User Guide manual
Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from
DIASONIC TECHNOLOGY Co. Please carefully read the Instruction manual for
safe use of the product. We recommend that you to keep this instruction manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDR-5100 and is the answer not in the manual?

Questions and answers

Related Manuals for Diasonic DDR-5100

Summary of Contents for Diasonic DDR-5100

  • Page 1 DIGITAL VOICE RECORDER MODEL : DDR-5100 User Guide manual Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC TECHNOLOGY Co. Please carefully read the Instruction manual for safe use of the product. We recommend that you to keep this instruction manual...

  • Page 2: Preface

    Note This instruction manual is required for the effective use of Diasonic MP3 Player. Pay special attention not to lose the manual as it is not provided separately from the unit.

  • Page 3: Table Of Contents

    Contents Preface Safety Precautions Functions and Features Parts and Components Basic Function Buttons FM Radio Mode Menu Main Menu Record in Recording Mode Connecting External Device Installation of Windows 98SE Driver Uninstallation of Windows 98SE Driver Managing Folders and Files Deleting Files Downloading Files Formatting Files...

  • Page 4: Parts And Components

    MP3/WMA PLAYER & ENCODER - ID3 TAG SUPPORT(ARTIST/TITLE) - SCROLL SPEED CONTROLLING - MULTI LANGUAGE SUPPORT - 5EQ (NORMAL/CLASSIC/LIVE/POP/ROCK) - SYNC FUNCTION: AUTOMATICALLY RECOGNIZE THE END AND BEGANNING OF THE MUSIC FROM EXTERNAL AUDIO DEVICE IN RECODING THRU CONNECTING AUDIO CABLE AND RECORD. USER EASILY UPGRADES NEW FIRMWARE PROVIDED BY MAKER EASY-TO-USE BUTTON FOR QUICK NAVIGATION THROUGH FOLDERS AND OPTIONS...
  • Page 5 (2) LCD FOLDER INDEX INFORMATION FILE INFORMATION SYNC/BIT RATE /EQ/SPEED HOLD TIMER ON/OFF ARS ON/OFF REPEAT L/R SPECTRUM (3) BATTERY 1) PUT BATTERIES (LR03 TYPE) MODE PLAY/STOP/PAUSE /REC/REW/FF REPEAT TIME 2) BATTERY POWER STATUS INDICATOR ALARM ON/OFF 3D SOUND ON/OFF INTRODUCTION PLAY BACK BATTERY STATUS CHECK THE POLARITIES OF THE BATTERIES IF LCD DISPLAY DOESN...

  • Page 6: Basic Function

    3) TYPICAL BATTERY LIFE TIME PLAYBACK VIA BATTERY TYPE RECORDING (VOLUME:MEDIUM) SPEAKER (VOLUME:MEDIUM) 2 AAA LR03 APPROX. 14HRS APPROX. 14HRS BATTERY LIFE MAY BE DIFFERENT FROM ABOVE MENTIONED TIME ACCORDING TO BATTERY BRAND & CONDITION. DO NOT USE DIFFERENT TYPE AND BRAND BATTERY TOGATHER. WHEN THE DEVICE IS LEFT UNUSED FOR A LONG TIME, REMOVE BATTERIES.
  • Page 7 (4) CHANGING MODE MENU BY PRESSING MENU BUTTON FOR 1-2 SECONDS, MODE MENU WILL DISPLAY. FOR MOVING TO THE MODE WANTED, PRESS REW/FF“ BUTTON. SELECT THE MODE BY PRESSING MENU” OR “PLAY/PAUSE” BUTTON. VOICE MUSIC L-IN ENC FM ENC (5) INTRO PLAY THIS IS FOR PLAYING THE FIRST FEW SECONDS OF EVERY TRACK FOR QUICK REVIEW OF VOICE FILES OR MUSIC.

  • Page 8: Buttons

    Buttons (1) VOICE MODE THE STATUS OF SET BUTTON OPERATION STOP PLAYBACK PLAYBACK SHORT PLAY/ LONG PAUSE INTRO PLAY GO TO NEXT FILE AND GO TO NEXT FILE SHORT GO TO NEXT FILE S-FORWARD LONG IN SEQUENCE CURRENT FILE GO TO BEGINNING OF THE FILE, IF PLAY CURRENT FILE OVER GO TO PREVIOUS...

  • Page 9: Fm Radio

    (3) MUSIC/L-IN ENC/FM ENC MODE THE STATUS OF SET BUTTON OPERATION STOP PLAYBACK SHORT PLAY PLAY / PAUSE LONG NTRO PLAY GO TO NEXT FILE GO TO NEXT FILE SHORT AND PLAY S-FORWARD GO TO NEXT FILE IN LONG CURRENT FILE SEQUENCE GO TO BEGINNING OF THE FILE, IF PLAY...

  • Page 10: Mode Menu

    (4) RECORDING FM IF YOU WOULD LIKE TO RECORD THE PRESENT STATION, PRESS “REC” BUTTON. THE RECORDED FILE IS STORED TO FM ENC FOLDER WITH FM001- 48KBPS_040101_010101.MP3 AND THE FILE NAME IS SEQUENTLY ADDED ACCORDING TO RECORDED ORDER. NOISE MAY OCCUR WHEN RECORDING FM IN WEAK COVERAGE OR INSIDE OF THE BUILDING.

  • Page 11: Main Menu

    (4) FM ENC PLAY THE FILE IN FM ENC FOLDER. FILE IS STAMPED IN FM001-128KBPS_040101_010101.MP3 IN SEQUENCE. 256FILES CAN BE RECORDED AS MUCH AS MEMORY IS AVAILABLE. (5) FM RECEVING RADIO STATION. (6) B-MARK ✽ B-MARK STORE FAVOITE SONGS.(2OFILES ARE AVAILABLE.) BOOKMARK IS SET BY PRESSING STOP BUTTON ON THE MUSIC, L-IN ENC, FM_ENC MODE.
  • Page 12 TIMER REC : RESERVATION RECORDING . USER MUST SET UP SET DATE FIRST. - ON THE SETTING DISPLAY, NO. 1 CHANNEL WILL BE BLINKING. - MOVE TO THE SPECIFIC NO. YOU WANT TO SET UP BY PRESSING REW/FF BUTTON AND PRESS MENU OR PLAY/PAUSE BUTTON FOR SELECTION. ※...
  • Page 13 POWER OFF TIME : 1MIN, 3MIN, 5MIN, ALWAYS ON AUTOMATIC POWER OFF TIME SLEEP TIME : OFF, 15MIN, 30MIN, 45MIN, 60MIN, 75MIN, 90MIN, 105MIN, 120MIN AUTOMATICALLY TURN OFF AFTER THE TIME YOU SET UP. INTRO TIME : 5SEC, 10SEC, 15SEC PLAYING FILE BACK FOR THE TIME YOU SET UP.
  • Page 14 SYSTEM THIS IS FOR PLAYER S SYSTEM CONTROL. THIS CONSISTS OF LANGUAGE, REPEAT, SYNC, ARS, INPUT SELECTOR, MIC SENSITIVITY, RESUME, BITRATE, FM BAND, CONTINUE FOLDER, FORMAT, DEFAULT. LANGUAGE: ENGLISH, GERMAN, JAPANESE, CHINESE(SIMPLIFY TRADITIONAL) YOU CAN SELECT THE LANGUAGE YOU WANT FOR MODE/MENU.

  • Page 15: Record In Recording Mode

    BIT RATE : VOICE BITRATE, MP3 BITRATE SET UP THE BIT RATE IN VOICE RECORDING, LINE IN AND FM RECORDING. - VOICE RECORDING : SHQ(32Kbps), HQ(16Kbps), SP(8Kbps) - MP3 ENCODE : 48Kbps, 64Kbps, 96Kbps, 128Kbps, 192Kbps, 256Kbps FM BAND : WORLD, JAPAN, EUROPE YOU CAN SELECT FM BAND YOU WANT.

  • Page 16: Connecting External Device

    Connecting External Device (1) RECORDING FROM EXTERNAL DEVICE OR SET 1) RECORDING EXTERNAL DEVICE TO DDR-5100 CONNECT THE PROVIDED AUDIO CABLE TO LINE IN JACK ON THE SET. 2) RECORDING DDR-5100 TO EXTERNAL DEVICE CONNECT THE PROVIDED AUDIO CABLE TO EARPHONE JACK ON THE SET AND MICROPHONE OR LINE IN ON THE EXTERNAL DEVICE.

  • Page 17: Installation Of Windows 98Se Driver

    Installation Of Windows 98SE Driver IT SUPPORTS USB MASS STORAGE AND IT CAN BE USED AS HARD DRIVE. IT CAN BE CONNECTED TO PC DIRECTLY WITHOUT ANY APPLICATION BY PLUG & PLAY METHOD ON WINDOWS ME, 2000, XP EXCEPT FOR WINDOWS 98SE. HOW TO INSTALL DRIVER (1) In case of Windows ME, 2000, XP WHEN CONNECTING DEVICE TO PC BY USB PORT, NEW HARDWARE...
  • Page 18 OR RIGHT CLICK “ “ BELOW WINDOW WILL APPEAR, SO FOLLOW UP THE DIRECTION. CLICK “DDR-5100 UMS SYSTEM USB Device”. WHEN BELOW TOOL BAR APPEAR, REMOVE THE SET FROM PC. (2) Windows 98SE REMOVE IT FROM PC WITHOUT ANY PROCEDURE. AS Windows ME, 2000, XP.

  • Page 19: Uninstallation Of Windows 98Se Driver

    Uninstallation of Windows 98SE THE PROVIDED CD CONTAINS UNINSTALLING PROGRAM AUTOMATICALLY. 1 INSERT THE PROVIDED CD. 2 DOUBLE CLICK “DVR-II-WIN98SE.EXE” 3 CLICK “REMOVE DRIVER” 4 WHEN IT COMPLETE, BELOW WILL APPEAR AND CLICK “OK” Managing Folders and Files (1) DEFAULT FOLDERS WHEN YOU CONNECT THE UNIT TO PC, YOU CAN FIND THAT THE VOICE, L- IN_ENC, FM_ENC &...
  • Page 20 (3) AUDIO MODE IS NOT DEFAULTED LIKE VOICE, L-IN_ENC, FM_ENC. CREAT IT ON THE PC AND CAN CHECK IT AT FOLDER & MUSIC MODE. THE CREATED FOLDER BY USER CAN BE CHECKED AT FOLDER ON THE MODE MENU AND ONLY MUSIC FILE IS DISPLAIED ON MUSIC MODE. FOLDER DOES NOT APPEAR.

  • Page 21: Deleting Files Downloading Files

    Deleting Files Downloading Files COPY MUSIC FILES OR DATA FROM PC FOLDER AND DOWNLOAD THEM TO THIS WORK IS SAME AS DONE IN PC. DEVICE. • Don t detach USB cable under the condition file delete or file transfer. It might cause data loss or could break down.

  • Page 22: Formatting Files

    Formatting Files (1) FORMAT on PC GO TO [MY COMPUTER], CHOOSE PORTABLE DISK(F:) AND CLICK RIGHT BUTTON OF MOUSE. FOLLOWING TOOLBAR APPEARS. AT THE TIME, CLICK FORMAT. CLICK START WHEN FOLLOWING WINDOW APPEARS. THIS SET DOSE NOT SUPPORT FAT32 . FORMAT MUST DO IN SETTING FAT .

  • Page 23: Firmware Upgrade

    After completed upgrading, set turn off AND TURN ON automatically BEFORE UPGRADING, BATTERY STATUS MUST BE CHECK. IF THE STATUS IS LOW, CHANGE IT. IT MIGHT CASUE SERIOUS PROBLEM TO THE SET. General Specification DDR-5100 DDR-5100R DDR-5100R MODEL (064MB) (128MB)

  • Page 24: Warranty

    OUTPUT Max 5mW (16ohm) EARPHONE EQ : Normal / Classic / Live / Pop / Rock 5/10/15 sec in each track INTRO PLAY SEARCHING Easy track search & track search REPEAT Normal/ One/ One All/ All/ Shuffle/ A B INTERFACE Mass Storage USB 1.1 SYSTEM CPU 200MHz more than , RAM 64MB more than, 20MB of free space...

  • Page 25: Warranty Card

    Warranty Card Product Category : Digital Voice Recorder Model : DDR-5100 The Term of Guarantee : 1 Year Date of Purchase : Name Address PURCHASER Telephone Name SELLER Address Telephone Please refer to our customer service department for any information or breakdown on the product Exchange, repair(charge.
  • Page 26 March, 2005 Printed in korea...
