DIGITAL VOICE RECORDER
MODEL : DDR-5000
User Guide manual
Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC TECHNOLOGY Co.
Please carefully read the Instruction manual for safe use of the product. We recommend that you to
keep this instruction manual for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDR-5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Diasonic DDR-5000

Summary of Contents for Diasonic DDR-5000

  • Page 1 MODEL : DDR-5000 User Guide manual Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC TECHNOLOGY Co. Please carefully read the Instruction manual for safe use of the product. We recommend that you to keep this instruction manual for future reference.
  • Page 2 ● The memory content may be changed or lost due to misuse, static electricity or electric shock during the repair or battery change. Be sure to make a note of important content. ● Diasonic assumes no responsibility for any damage caused by change or loss of memory content.

  • Page 3: Safety Precautions

    Safety Precautions Warning ● Keep the batteries out of reach of the children. If a child swallowed a battery, please consult a doctor immediately. ● Do not have the battery shorted, disassembled, heated or put in fire. This may cause leakage, heat, explosion or fire.

  • Page 5: Table Of Contents

    Contents Precautions 1. Functions and Features 2. Parts and Components 3. Basic Operation Guide 4. Button 5. Receiving FM Radio 6. Mode Menu 7. Main Menu 8. Recording in Recording mODE 9. Connecting to external audio device 10. Installation of Win98SE deriver & removing device 11.

  • Page 6: Functions And Features

    Functions and Features DIGITAL VOICE RECORDER ▣ UP TO 16,960 MIN RECORDING TIME(SP MODE AND 1GB) 8FOLDERS TO ORGANIZE FILES STORE UP TO 128 FILES FOR EACH FOLDER CONTINUE FOLDER FUNCTION: AUTOMATICALLY MOVE TO NEXT FOLDER IF INFEX IS FULL. VARIABLE RECORDING MODE (SHQ/HQ/SP IN MP3 FORMAT AND USER MODE IN MPEG1 LAYER3) MIC SESITIVITY ADJUSTABLE IN RECORDING.
  • Page 7 USER EASILY UPGRADES NEW FIRMWARE PROVIDED BY MAKER EASY-TO-USE BUTTON FOR QUICK NAVIGATION THROUGH FOLDERS AND OPTIONS SET UP THE ALARM TO PLAY AUTOMATICALLY AS A REMINDER TO MEETING, BIRTHDAY AND MORE. EASY-TO-READ ALL STATUS ON THE LARGE BACKLIGHT LCD DISPLAY WITH DOT MATRIX VARIABLE FLASH MEMORY UP TO 1G(64MB/128MB/256MB/512MB/1GB) 25HOURS PLAY BACK WITH 2 AAA BATTERIES...

  • Page 8: Parts And Components

    Parts and Components (1) Main set USB JACK NECK STRAP HOLDER EARPHONE MIC & LIN-IN JACK INTERNAL MIC REC/PAUSE DC JACK STOP ERASE HOLD MENU VOLUME + VOLUME -...
  • Page 9 (1) LCD MODE INDEX INFORMATION FILE INFORMATION SYNC/BIT RATE/EQ/SPEED KEY/REPEAT TIME ALRAM ON/OFF INTRO PLAY REPEAT 3D SOUND EFFECT VOLUME LEFT/RIGHT HOLD BATTERY STATUS TIMER ON/OFF ALARM ON/OFF ARS ON/OFF 3D SOUND ON/OFF REPEAT INTRUDUCTION PLAY BACK L/R SPECTRUM BATTERY STATUS (3) BATTERY 1) PUT BATTERIES (LR03 TYPE)
  • Page 10 2) BATTERY POWER STATUS INDICATOR FULL CHARGED SOME POWER CUSTOMED THINKING OF CHANGING BATTERY CHANGE BATTERY ☞ CHECK THE POLARITIES OF THE BATTERIES IF LCD DISPLAY DOESN’T TURN ON AFTER INSERTING NEW BATTERIES. 3) TYPICAL BATTERY LIFE TIME BATTERY TYPE RECORDING PLAYBACK VIA SPEAKER PLAYBACK VIA EARPHONE...
  • Page 11 BASIC FUNCTION (1) TURN ON/OFF TO TURN ON, HOLD THE KEY FOR 2-3 SECONDS. TO TURN OFF, HOLD THE KEY AGAIN WITH LONG KEY. ☞ IF USB CABLE IS CONNECTED, AUTOMATICALLY POWER IS ON. ☞ IF YOU PUT THE BATTERY TO SET, “A”...
  • Page 12 (4) CHANGING MODE BY PRESSING MENU BUTTON FOR 1-2 SECONDS, MODE MENU WILL DISPLAY. FOR MOVING TO THE MODE WANTED, PRESS “+/-“ BUTTON. SELECT THE MODE BY PRESSING “PLAY/PAUSE” BUTTON. VOICE MUSIC L-IN ENC FM ENC B-MARK FOLDER PLAY (5) INTRO PLAY THIS IS FOR PLAYING THE FIRST FEW SECONDS OF EVERY TRACK FOR QUICK REVIEW OF VOICE FILES OR MUSIC.
  • Page 13 (9) BOOKMARK SETTING TO BOOKMARK A SELECTED MUSIC FILE, PRESS “STOP” BUTTON IN STOP FOR 1SECOND. BOOKMARK IS AVAILABLE IN THE MUSIC MODE. (10) PC CONNECTION WHEN THE UNIT IS CONNECTED TO A PC VIA USB CABLE, USB ICON APPEARS ON THE LCD.
  • Page 14 FM Radio (1) TURN ON FM TURN ON THE SET AND SELECT FM IN THE MENU. (2) AUTOMATIC TUNEING The AUTOMATIC TUNEING IN THE STATION WITH STRONG SIGNAL. PRESS AND HOLD FORWARD OR REWIND BUTTON FOR ONE SECOND. THE TUNNER AUTOMATICALLY SCAN AND STOP ON THE NEXT STATION WITH A STRONG SIGNAL.

  • Page 15: Button

    BUTTONS (1) VOICE RECORDING MODE THE STATUS OF SET BUTTON OPERATION STOP PALYBACK RECORDING SHORT PLAYBACK PAUSE REMAINING TIME PLAY LONG TURN OFF INTRO PLAY INCREASE INDEX(AFTER SHORT GO TO NEXT FILE GO TO NEXT FILE AND PLAY 5SECONDS) LONG GO TO NEXT FILE S-FORWARD CURRENT FILE SEQUENTLY...
  • Page 16 (2) FM RADIO MODE MODE BUTTON OPERATION SET UP THE FREQUENCY MODE PRESET MODE STATION ENTERING SETTING SHORT SETTING STATION STATION PLAY/PAUSE LONG POWER OFF POWER OFF POWER OFF TUNE FM FREQ. FORWARD NEXT PRESET SHORT CHANNEL UP SLIGHTLY LONG AUTO SEEK + AUTO CHANEL UP TUNE FM FREQ.
  • Page 17 (3) MP3/WMA MODE THE STATUS OF SET BUTTON OPERATION STOP PLAY SHORT PALY PAUSE PLAY/PAUSE LONG TURN OFF INTRO PLAY SHORT GO TO NEXT FILE GO TO NEXT FILE AND PLAY LONG GO TO NEXT FILE S-FORWARD CURRENT FILE SEQUNETLY GO TO BEGANNING OF THE FILE, IF PLAY CURRENT FILE OVER 5SECONDS.

  • Page 18: Mode Menu

    MODE MENU YOU CAN GO TO “MODE MENU” BY PRESSING “MENU” BUTTON FOR 1 SECOND. MODE MENU IS CONSIST OF BELOW MODE. TO MOVE TO ANOTHER MODE, USE “VOLUME +/-“ BUTTON. VOICE MUSIC L-IN ENC FM ENC B-MARK FOLDER PLAY (1) VOICE PLAY BACK VOICE FILE RECORDED IN VA001-8KBPS_20040101_010101.MP3 TYPE.
  • Page 19 RECEVING READIO STATION. (6) B-MARK STORE FAVOITE SONGS.(2OFILES ARE AVAILABLE.) BOOKMARK IS SET BY PRESSING STOP BUTTON ON THE MUSIC MODE. BOOKMARK IS DISPLAYED ON THE FILE INFORMATION. INITIALY PLAYLIST FOLDER EXSITS AND M3U FORMAT FILE CAN BE SAVED AND PLAYED. 32 FILES CAN BE STORAGED.

  • Page 20: Main Menu

    MAIN MENU TO ENTER INTO “MAIN MENU”, PRESS “MENU”BUTTON FOR 2-3SECONDS. VOLUME +/- WORKS AS A MOVING BUTTON TO ANOTHER FUNCTION AND PRESS “PLAY/PAUSE” BUTTON FOR SELECTION OF THE FUNCTION YOU WANT. BY PRESSING MENU BUTTON AGAIN, YOU CAN GO OUT OF SUBORDINATE MENU. IF YOU DO NOT OPERATE ANY BUTTON AFTER ENTERING INTO MENU FOR 5SECONDS, AUTOMATICALLY MENU FUNCTION WILL BE RELEASED.
  • Page 21 ② TIMER REC : RESERVATION RECORDING . UP TO 10 AVAILABLE ☞ YOU MUST SET UP “SET DATE” FIRST. - ON THE SETTING DISPLAY, NO. 1 CHANNEL WILL BE BLINKING. - MOVE TO THE SPECIFIC NO. YOU WANT TO SET UP BY PRESSING “REW/FF” BUTTON AND PRESS “PLAY/PAUSE”...
  • Page 22 ③ ALARM PLAY : THE FILE SELECTED PLAYS BACK ON TIME WHEN IS SET UP IN ADVANCE. (10PCS AVAILABLE) ※ SET UP THE ALARM PLAY (이하 설정은 TIMER REC와 동일합니다.) - THIS FUNCTION HAS DATE/DAILY/WEEKLY MODE. 1. DATE (1 TIME) a.
  • Page 23 ⑤ SLEEP TIME : OFF, 15MIN, 30MIN, 45MIN, 60MIN, 75MIN, 90MIN, 105MIN, 120MIN AUTOMATICALLY TURN OFF AFTER THE TIME YOU SET UP. ⑥ INTRO TIME : 5SEC, 10SEC, 15SEC PLAYING FILE BACK FOR THE TIME YOU SET UP. SOUND THIS MENU HAS EQUALIZER, 3DS USER SETTING, DEFAULT VOLUME. ①...
  • Page 24 1. ON : DISPLAY Title, Artist, Bit Rate, Frequency 2. OFF : DISPLAY NAME ONLY ③ SCROLL SPEED : 0~10 SPEED CONTROL FOR FLOWING FILE INFORMATION ON THE LCD UP TO 10LEVEL. ☞ EVEN IF SCROLL SPEED IS SET UP, FULL FILE INFORMATION IS ABLE TO DISPLAYED ON THE LCD, INFORMATION IS NOT FLOWING.
  • Page 25 - OFF : IN RECORDING THE SOUND FROM EXTERNAL DEVICE THRU LINE-IN, ALL SOUNDS OR SONGS ARE RECORDED INTO ONE FILE, IF YOU SEPARATE. ③ ARS : A, B, OFF IN RECORDING, IF THERE IS SOUND AT A WEAK SOUND FOR A CERTAIN TIME, RECORDING PAUSES AUTOMATICALLY FOR SAVING MEMORY, BUT IF THERE IS SOUND AT SPECIFIC LEVEL AGAIN, START RECORDING AGAIN.
  • Page 26 1. WORLD: 87.50MHz ~ 108.00MHz, 100KHz STEP 2. JAPAN: 76.00MHz ~ 108.00MHz, 100KHz STEP 3. EUR: 87.50MHz ~ 108.00MHz, 50KHz STEP (DEFAULT: 87.50MHz) ⑨ CONTINUE FOLDER : ON, OFF IT WORKS IN VOICE MODE RECORDING. - ON : IF INDEX RECORDED(128PCS) IS FULL FOR A FOLDER, AUTOMATICALLY MOVE TO NEXT FOLDER AND RECORDING CONTINUOUSLY.
  • Page 27 Setting PC Environment It supports USB Mass Storage and it can be used as hard drive. It can be connected to PC directly without any application by Plug & play method on Window Me, 2000, XP except for Windows 98SE. ☜...
  • Page 28 ○ 2 Check ‘Find appropriate driver ’ and click ‘next’. ○ 3 Check ‘designating location’ and click [Retrieval] button. ○ 4 Find installation program on [Folder Retrieval] window.
  • Page 29 ○ 5 Click ‘next’ on [New hardware wizard] window. ○ 6 Below window is shown when installation is completed. ○ 7 Check finally whether installation has been completed successfully. [My Computer]-[Control Panel]-[System]-[Device Manager]-[Hard Disk Controller]...
  • Page 30 When installation is completed successfully, it is recognized as USB Mass Storage on Device Manager of My computer. ( In case of WINDOWS ME, it is normal even though ‘?’ mark is shown.)

  • Page 31: Recording In Recording Mode

    Recording in RECORD Mode (1) RECORDING METHOD THE SET HAS 4 WAYS TO RECORD AS BELOW. 1) RECORDING THRU INTERNAL MIC: PRESS “MENU” BUTTON SELECT “INTERNAL-MIC” ON SYSTEM/INPUT SELECTOR. PRESS “REC” 2) RECORDING THRU EXTERNAL MIC: PLUG EXTERNAL MIC INTO LINE IN JACK. SELECT EXTERNAL MIC ON SYSTEM/INPUT SELECTOR.

  • Page 32: Connecting To External Audio Device

    (1) RECORDING FROM EXTERNAL DEVICE OR SET WHEN CONNECT EXTERNAL DEVICE TO SET, AUTOMATICALLY MODE TRANFERS TO “LINE IN”. 1) RECORDING EXTERNAL DEVICE TO DDR-5000 CONNECT THE PROVIDED AUDIO CABLE TO LINE IN JACK ON THE SET. 2) RECORDING DDR-5000 TO EXTERNAL DEVICE CONNECT THE PROVIDED AUDIO CABLE TO EARPHONE JACK ON THE SET AND MICROPHONE OR LINE IN ON THE EXTERNAL DEVICE.
  • Page 33 CONNECT “CELLULAR EAR MICROPHONE” ONTO EXTERNAL MICROPHONE ON THE SET AND EARPHONE JACK ON THE MOBILE PHONE. ☞ CELLULAR EAR MICROPHONE IS OPTIONAL ITEM AND YOU MAY ASK RETAILER THAT YOU CAN PURCHASE. IF YOU CELLULAR IS NOKIA BRAND, YOU MUST CHECK “CELLULAR EAR MICROPHONE” IS COMPATIBLE OR NOT.
  • Page 34 Managing Folders and Files (1) Default folders ◈ When you connect the unit to PC, you can find that the LINE, RADIO and VOICE folders are created by default. AUDIO MODE ◈ No folder is created by default for AUDIO MODE. You can create the audio folders on the PC, and check the folders with FOLDER PLAY and MUSIC PLAY on the MP3 Player.
  • Page 35 FOLDER PLAY. ** FOLDER PLAY in the MODE menu shows the folders you created, and MUSIC PLAY shows the music files within the folder. (3) LINE IN MODE ◈ LINE IN MODE contains the files recorded from external devices through the line-in cable. ◈...
  • Page 36 (5) VOICE MODE ◈ VOICE MODE contains the voice recording files. ◈ When recording data, up to 256 files can be created in sequence. If the number of files exceeds 256, the “INDEX FULL” message is displayed. ♠ Deleting files in the LINE, RADIO and VOICE MODE ♠ ◈...
  • Page 37 Downloading Files Wait until ‘new hardware detect’ and ‘it is ready to operate’ appears after connecting device to USB port. Click on My Computer. Copy music files or data from PC folder and download them to device. Following folder is created.

  • Page 38: Deleting Files

    Deleting Files (1) Deleting on PC ○ 1 Click file which you try to delete and click right button of mouse. Then following toolbar appears. ○ 2 Click ‘Yes’. ○ 3 It indicates the status of deleting. ☞ Deleting on LINE, RADIO, VOICE MODE...
  • Page 39 ◈ In case of deleting VOICE005 V005 is deleted, V006 is renamed to “V005”.
  • Page 40 FORMATTING File FORMAT on PC ○ 1 Go to [My Computer], choose portable disk(F:) and click right button of mouse. Following toolbar appears. At the time, click format. ○ 2 Click ‘start’ when following window appears. ○ 3 Click ‘confirm’.
  • Page 41 ○ 4 Format is completed.

  • Page 42: Upgrading Firmware

    FIRMWARE This device has the feature which is to improve function and correct error by upgrading firmware. You can download upgrade file by connecting to website. Firmware upgrade can be operated when you copy firmware file to root of device which is connected to PC. After completed upgrading, set turn off automatically.

  • Page 43: Icon

    ICON 1. POWER ON 1) DISPLAY ① ANIMATION ② MEMORYINFORMATION ③ FIRMWARE VERSION 2) ETC ① HOLD ON ② NEED TO CHAGE BATTERY ③ CONNECTING USB 2. POWER OFF 1) DISPLAY ① ANMIMATION...
  • Page 44 3. USB CONNECTION 1) FIRMWARE UPGRADE 2) DISPLAY ① USB DOWNLOAD ② USB UPLOAD 4. OTHER ICONS ① BIT RATE (1) VOICE (2) MP3 ② REPEAT (1) NORMAL (2) REPEAT ONE (3) REPEAT ONE ALL (4) REPEAT ALL (5) SHUFFLE ③...
  • Page 45 VOLUME 0 ~ 30 ⑤ EQUALIZER NORMAL CLASSIC ROCK JAZZ LIVE ⑥ KEY (1) PLAY (2) PAUSE (3) REW (REWIND) (4) FF (FAST FORWARD) (5) REC (RECORD) (6) STOP ⑦ SYNC ⑧ POP-UP (1) PAUSE (2) INDEX FULL (3) MEMORY FULL (4) ERASE...

  • Page 46: General Specification

    General Specification MODEL DDR-5000R with 256MB RECORDING TIME SHQ(1060min)/HQ(2120min)/SP(4240min) RECORDING MODE MP3 FORMAT : SHQ(32Kbps) / HQ(16Kbps) / SP(8Kbps) FOLDER A/B/C/D/E/F/G/H (8 FOLDER) Total 1024 Messages with 8 Separate Folder (128 Messages in Each Folder) Automatic Recording System (A-TYPE: ONE INDEX, B-TYPE: +INDEX) FM RECORDING World Wide FM band / Japen FM band / Europe FM band EX-MIC...
