QUICK START GUIDE
710P Series
Ethernet Switch
CCS-710P-12
CCS-710P-16P
Arista Networks
DOC-05297-02
Arista.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 710P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Arista 710P Series

Summary of Contents for Arista 710P Series

  • Page 1 QUICK START GUIDE 710P Series Ethernet Switch CCS-710P-12 CCS-710P-16P Arista Networks DOC-05297-02 Arista.com...
  • Page 2 The trademarks, logos, and service marks ("Marks") displayed in this documentation are the property of Arista Networks in the United States and other countries. Use of the Marks is subject to the Arista Networks Terms of Use Policy, available at www.arista.com/en/terms-of-use. Use of marks belonging to other parties is for...
  • Page 3 Contents Contents Chapter 1: Overview..................1 1.1 Scope..............................1 1.2 Receiving and Inspecting the Equipment..................1 1.3 Installation Process..........................1 1.4 Safety Information..........................2 1.5 Obtaining Technical Assistance......................2 1.6 Specifications............................. 3 Chapter 2: Preparation..................5 2.1 Site Selection.............................5 2.2 Tools and Parts Required for Installation..................6 2.3 Electrostatic Discharge (ESD) Precautions..................6 Chapter 3: Rack Mounting the Switch............
  • Page 4 Chapter 10: Operating Mode Button............30 Appendix A: Regulatory Model Numbers........... 31 Appendix B: Screw Size................32 Appendix C: BSMI Class A EMC Statement..........33 Appendix D: RoHS Information..............34...
  • Page 5 Chapter 1 Overview This guide is for network or security professionals and technicians who need to install the required Arist 710P Series Ethernet Switch. This section discusses the following topics: • Scope • Receiving and Inspecting the Equipment • Installation Process •...
  • Page 6 Refer to the Arista Networks document Safety Information and Translated Safety Warnings at https:// www.arista.com/en/support/product-documentation. Obtaining Technical Assistance Any customer, partner, reseller, or distributor holding a valid Arista Service Contract can obtain technical support in any of the following ways: • Email: support@arista.com...
  • Page 7 Field Notices. • Phone: +1 866-476-0000 or +1 408-547-5502. Specifications This section lists the specifications of the Arista Ethernet Switches described in this guide. Table 1: Switch Specifications (Dimensions and Weights) Device Size (W x H x D) Weight...
  • Page 8 Table 4: Switch Specifications (PoE Power Budget) Device PSU Model PoE Power Budget CCS-710P-12 PWR-150-ADP 110W CCS-710P-12 PWR-280-ADP 240W CCS-710P-16P 90W PoE PD CCS-710P-16P PWR-150-ADP 100W CCS-710P-16P PWR-280-ADP 230W...
  • Page 9 Chapter 2 Preparation This section discusses the initial set up and preparation for installing the switch. • Site Selection • Tools and Parts Required for Installation • Electrostatic Discharge (ESD) Precautions Site Selection Consider the following criteria when selecting a site to install the switch: •...
  • Page 10 Toutes les connexions d'alimentation doivent être enlevées pour hors tension l'appareil. • Other Requirements: Select a site where liquids or objects cannot fall onto the equipment, and foreign objects are not drawn into the ventilation holes. Verify that the following guidelines are met: •...
  • Page 11 Chapter 3 Rack Mounting the Switch This section provides instructions on how to rack mount the switch. This section discusses the following topic: • Wall Mount • L-Bracket Wall Mount (Default) • 3-in-1 Bracket Wall Mount (Optional) • Under Table Mount •...
  • Page 12 3.1.1 L-Bracket Wall Mount (Default) This section provides instructions for wall mounting the switch using an L-Bracket. Figure 3-1: Wall Mounting the Switch using L-Bracket L-Bracket (Left and Right) Screw anchor M4 Screw M4x25mm Flat surface Flat head screw M4x6mm Note: For more information regarding the screw size, refer to Screw Size.
  • Page 13 Rack Mounting the Switch 3.1.2 3-in-1 Bracket Wall Mount (Optional) This section provides instructions for wall mounting the switch using a 3-in-1 mounting bracket. Figure 3-2: 3-in-1 Mounting Bracket Screw anchor M4 3-in-1 bracket Screw M4x25mm Flat surface Cross hole stud...
  • Page 14 Figure 3-3: Wall Mounting the Switch Chassis Flat head screw M4x6mm Cross hole Flat surface 3-in-1 bracket Flat head screw M4x6mm Note: For more information regarding the screw size, refer to Screw Size. 1. Determine the wall mounting position to attach the device. 2.
  • Page 15 Rack Mounting the Switch PSU adapter bracket Cable ties 8. Determine the wall mounting position to attach the PSU adapter bracket. 9. Place the PSU adapter bracket on the wall and mark the mounting holes on the four corners, aligning with the mounting bracket.
  • Page 16 3.2.1 L-Bracket Under Table Mount (Default) This section provides instructions for mounting the switch under the table/desk using an L-Bracket. Figure 3-4: Under Table Mounting the Switch using L-Bracket Flat wooden surface Flat head screw M4x6mm L-Bracket Screw M4x25mm Note: For more information regarding the screw size, refer to Screw Size.
  • Page 17 Rack Mounting the Switch 3.2.2 3-in-1 Bracket Under Table Mount (Optional) This section provides instructions for mounting the switch under the table/desk using a 3-in-1 mounting bracket. Figure 3-5: 3-in-1 Bracket Under Table Mount Flat wooden surface 3-in-1 bracket Screw hole Screw M4x25mm Screw anchor M4 Device...
  • Page 18 Note: For more information regarding the screw size, refer to Screw Size. Note: Ensure that the flat wooden table surface has a minimum thickness of 25mm for under table mounting. 1. Determine the mounting position to attach the switch under the table. 2.
  • Page 19 Rack Mounting the Switch Magnetic Mount (Optional) This section provides instructions for magnetically mounting the switch. Note: Magnetic mounting is applicable to mount only on the metal surfaces. Figure 3-8: Magnetic mount Rubber Magnet Cross hole 3-in-1 bracket Flat head screw M4x6mm Switch facing downwards Note: For more information regarding the screw size, refer to Screw...
  • Page 20 DIN Rail Mount (Optional) This section provides instructions for mounting the switch using a DIN rail. Figure 3-9: DIN Rail Mount Chassis Flat head screw M4x6mm DIN mount bracket DIN rail DIN rail hook Note: For more information regarding the screw size, refer to Screw Size.
  • Page 21 Rack Mounting the Switch PSU adapter bracket Cable ties 6. Position the PSU adapter bracket on the DIN mount bracket, aligning it with the screw holes, and fix it with M4x8mm thread screws. The PSU is attached to the DIN rail. DIN rail Cable ties DIN mount bracket...
  • Page 22 3.6.1 Attaching Mounting Brackets to the Chassis This section describes the steps to attach mounting brackets to the switch chassis. Figure 3-10: Attaching the Mounting Brackets 1RU Rack Device Note: Ensure that there is about 1U rack spacing between the two devices on the rack. 1.
  • Page 23 Rack Mounting the Switch Cable ring Power adapter cable Cable ties Power adapter 4. Connect the power adapter to the switch as shown in the following image: Cable ring Cable ties 5. Position the rack against the rack posts and mount the rack to the equipment rack. Screw M4x8mm Rack posts 6.
  • Page 24 Chapter 4 Grounding the Switch This section discusses the importance of grounding the device to the data center ground. Normally, the functional grounding of the switch is achieved through the input connection. If you would like to do additional grounding, proceed to the following instructions: Figure 4-1: Grounding the Switch Screw M4 (with washer) Solder terminal lug...
  • Page 25 Chapter 5 Configuring the Switch Arista switches ship from the factory in Zero Touch Provisioning (ZTP) mode. ZTP configures the switch without user intervention by downloading a startup configuration file or a boot script from a location specified by a DHCP server. To manually configure a switch, ZTP is bypassed. The initial configuration provides one username (admin) that is accessible only through the console port because it has no password.
  • Page 26 11. When the management port IP address is configured, use this command to access the switch from a host, using the address configured in Step 9. ssh admin@192.0.2.8 Refer to the Arista Networks User Manual for complete switch configuration information. Note: The device configuration does not stream voltage and current data.
  • Page 27 Chapter 6 Status Indicators This section describes the front panel LED status of the device. Figure 6-1: LED Status Indicators...
  • Page 28 Table 5: LED Status LED Name LED State Device Status System Status LED No power or in the midst of a power cycle. Blinking Green The system is powering up. Green The system is operating in a normal initialization sequence. Normal operations. Blue The locator function is active.
  • Page 29 Status Indicators Table 6: Port LED Modes Port LEDs Normal Mode PoE Mode Speed Mode 1GE RJ45 Port link is No PoE Blinking Port LED down Amber (P1 to P12) Green Port link is up Blinking Amber 100M Amber Amber Port is Amber Green...
  • Page 30 Spare SKU Description KIT-CCS-710 Accessory Kit for Arista 710P Series switches KIT-CCS-710-DIN DIN-Rail Mount Kit for Arista 710P Series switches KIT-CCS-710-RM Rack Mount Kit for Arista 710P Series switches KIT-CCS-710-MGN Magnet Mount Kit for Arista 710P Series switches Product Description The following is the list of SKU numbers related to the respective product.
  • Page 31 Chapter 8 Front Panel This section discusses the front panel of the Ethernet Switch. • CCS-710P-12 • CCS-710P-16P CCS-710P-12 The CCS-710P-12 front panel includes the following key components: Figure 8-1: CCS-710P-12 Front Panel System Status LEDs USB port Port LEDs Console port SFP+ ports Mode Button...
  • Page 32 CCS-710P-16P The CCS-710P-16P front panel includes the following key components: Figure 8-2: CCS-710P-16P Front Panel System Status LEDs Ethernet RJ45 ports with 30W PSE Port LEDs USB port 5GE port LEDs Console port SFP+ port LEDs Mode button PoE Ports Mode status LEDs 6A: Uplink 5G Ethernet RJ45 port with 90W PD 6B: Uplink 5G Ethernet RJ45 port...
  • Page 33 Chapter 9 Rear Panel The section discusses the rear panel of the Ethernet Switch. The CCS-710P-12 and CCS-710P-16P rear panels include the following key components: Figure 9-1: CCS-710P-12 and CCS-710P-16P Rear Panel Functional Grounding Point Power Supply Kensington lock hole...
  • Page 34 Chapter 10 Operating Mode Button This section discusses the functionality of the mode button located on the front panel of the switch. Figure 10-1: Mode Button States The mode button port LEDs will transition to different modes as listed below when the user presses the mode button for less than 2 seconds, and the same is indicated by the corresponding mode status LED.
  • Page 35 Appendix A Regulatory Model Numbers This section lists the Regulatory Model Numbers (RMNs) of the Ethernet switches described in this guide. Table 7: Regulatory Model Numbers Regulatory Model Number (RMN) AN1758 CCS-710P-12 AN1786 CCS-710P-16P...
  • Page 36 Appendix B Screw Size This section describes the detailed screw size information required.
  • Page 37 Appendix C BSMI Class A EMC Statement This section provides the Taiwan BSMI Class A Statement information for the switches this guide covers. Figure C-1: Taiwan BSMI Class A EMC Statement...
  • Page 38 Appendix D RoHS Information This section provides the China and Taiwan RoHS information for the switches this guide covers. Figure D-1: China RoHS...
  • Page 39 RoHS Information Figure D-2: Taiwan BSMI RoHS...
