Arista 720XP Series Quick Start Manual
2ru cognitive campus switches
Hide thumbs
Also See for 720XP Series:
- Quick start manual (38 pages) ,
- Quick start manual (34 pages) ,
- Quick start manual (37 pages)
Subscribe to Our Youtube Channel
Related Manuals for Arista 720XP Series
Summary of Contents for Arista 720XP Series
- Page 1 Quick Start Guide 720XP Series 2RU Cognitive Campus Switches CCS-720XP-96ZC2 CCS-720XP-96ZC2-M-S Arista Networks DOC-04208-03 Arista.com...
- Page 2 The trademarks, logos, and service marks ("Marks") displayed in this documentation are the property of Arista Networks in the United States and other countries. Use of the Marks is subject to the Arista Networks Terms of Use Policy, available at www.arista.com/en/terms-of-use. Use of marks belonging to other parties is for...
-
Page 3: Table Of Contents
Contents Contents Chapter 1: Overview..................1 1.1 Scope..............................1 1.2 Receiving and Inspecting the Equipment..................1 1.3 Installation Process..........................1 1.4 Safety Information..........................2 1.5 Obtaining Technical Assistance......................2 1.6 Specifications............................. 3 Chapter 2: Preparation..................5 2.1 Site Selection.............................5 2.2 Tools and Parts Required for Installation..................6 2.3 Electrostatic Discharge (ESD) Precautions..................6 Chapter 3: Rack Mounting the Switch............ - Page 4 Appendix D: Rear Panel................26 Appendix E: Regulatory Model Numbers........... 27 Appendix F: Taiwan RoHS Information............28...
-
Page 5: Chapter 1: Overview
• Obtaining Technical Assistance • Specifications Scope This guide is for properly trained service personnel and technicians who need to install the following Arista Networks Cognitive Campus Switches: CCS-720XP-96ZC2 CCS-720XP-96ZC2-M-S Important: Only qualified personnel should install, service, or replace this equipment. -
Page 6: Safety Information
Obtaining Technical Assistance Any customer, partner, reseller, or distributor holding a valid Arista Service Contract can obtain technical support in any of the following ways: • Email: support@arista.com. This is the easiest way to create a new service request. -
Page 7: Specifications
Overview You can create a support case through the support portal on our website. You may also download the most current software and documentation and view FAQs, Knowledge Base articles, Security Advisories, and Field Notices. • Phone: +1 866-476-0000 or +1 408-547-5502. Important: There are no user-serviceable parts inside. - Page 8 Note: Configurations with less than three PSUs are currently not supported.
-
Page 9: Chapter 2: Preparation
Chapter 2 Preparation This section discusses the following topics: • Site Selection • Tools and Parts Required for Installation • Electrostatic Discharge (ESD) Precautions Site Selection Consider the following criteria when selecting a site to install the switch: • Temperature and Ventilation: For proper ventilation, install the switch with ample airflow to the front and back of the switch. -
Page 10: Tools And Parts Required For Installation
• Power cords can reach from the power outlet to the connector on the rear panel. Important: Remove all power connections to de-energize the unit. Toutes les connexions d'alimentation doivent être enlevées pour hors tension l'appareil. Important: This unit is intended for installation in restricted access areas. Cet appareil est prévu pour une installation dans les zones d'accès restreintes. -
Page 11: Chapter 3: Rack Mounting The Switch
Chapter 3 Rack Mounting the Switch This section discusses the following topics: • Two-Post Rack Mount • Attaching Mounting Brackets to the Chassis • Inserting the Switch into the Rack Two-Post Rack Mount To mount the switch onto a two-post rack, assemble the mounting brackets to the chassis, then attach the brackets to the rack posts. -
Page 12: Attaching Mounting Brackets To The Chassis
Figure 3-2: Improper Bracket Mount Examples for Two-Post Rack Mount 3.1.1 Attaching Mounting Brackets to the Chassis This procedure attaches mounting brackets to the switch chassis (Figure 3-3: Attaching the Mounting Brackets to the Switch Chassis). 1. Align the mounting brackets with the attachment pins to obtain the desired mounting position. 2. - Page 13 Rack Mounting the Switch Figure 3-4: Inserting the Switch into the Rack 2. Select mounting screws that fit your equipment rack. 3. Attach the bracket flanges to the rack posts. After completing the two-post rack mount, proceed to Connecting Power Cables.
-
Page 14: Chapter 4: Cabling The Switch
Chapter 4 Cabling the Switch This section discusses the following topics: • Grounding the Switch • Connecting Power Cables • Connecting Serial and Management Cables Grounding the Switch After mounting the switch into the rack, connect the switch to the data center ground. Important: Grounding wires and grounding lugs (M4 x 0.7) are not supplied. -
Page 15: Ground Adapter Assembly
Cabling the Switch 4.1.2 Ground Adapter Assembly Use the following steps to assemble and attach a grounding assembly to the chassis before mounting it into the rack for models that require the grounding adapter. Figure 4-2: Earth Grounding Adapter Assembly for Models such as DCS-7050SX3-96YC8 shows the exploded and assembled views. -
Page 16: Dc Power Supplies
Installation de cet équipement doit être conformes aux codes électriques locaux et nationaux. Si nécessaire, consulter les organismes de réglementation appropriés et des autorités de contrôle pour assurer la conformité. Lire toutes les instructions d'installation avant de brancher le système à la source d'alimentation. Cet équipement doit être mis à... -
Page 17: Wire And Lug Preparation
Cabling the Switch PWR-521-DC-RED Figure 4-4: DC Power Supply (PWR-521-DC-RED) Note: A disconnect device must be provided as part of the installation. Ensure power is removed from DC circuits before performing any installation actions. Locate the disconnect device, circuit breakers or fuses on DC power lines servicing the circuits. Turn off the power line circuits or remove the fuses. -
Page 18: Connecting A Dc Power Supply To Power Source
2. Prepare the stranded copper wiring for the power supply to be used. Table 5: Wiring, Lug, and Tightening Torques for DC PSU provides wiring, lug, and tightening torque information for the power supplies covered in this guide. Table 5: Wiring, Lug, and Tightening Torques for DC PSU Wire Size(1) Lug Type(1) Tightening Torque... -
Page 19: Connecting Serial And Management Cables
Cabling the Switch Ensure power is removed from DC circuits before performing any installation actions. Locate circuit breakers or fuses on DC power lines servicing the circuits. Turn off the power line circuits or remove the fuses. Wire size must comply with local and national requirements and electrical codes. Use only copper wire. - Page 20 Figure 4-6: Front Panel Ports 2 USB port 3 Console serial port 1 Ethernet management port Connect the front panel ports as follows: • Console (Serial) Port: Connect to a PC with the RJ-45 to DB-9 serial adapter cable. The switch uses the following default settings: •...
-
Page 21: Chapter 5: Configuring The Switch
Chapter 5 Configuring the Switch Arista switches ship from the factory in Zero Touch Provisioning (ZTP) mode. ZTP configures the switch without user intervention by downloading a startup configuration file or a boot script from a location specified by a DHCP server. To manually configure a switch, ZTP is bypassed. The initial configuration provides one username (admin) that is accessible only through the console port because it has no password. - Page 22 When configuring the management port IP address, use this command to access the switch from a host using the address configured in Step 9: ssh admin@192.0.2.8 Refer to the Arista Networks User Manual for complete switch configuration information.
-
Page 23: Appendix A: Status Indicators
Appendix A Status Indicators This section discusses the following topics: • Front Indicators • Rear Status Indicators Front Indicators The system and port status LED indicators are located on the front of the switches. This section discusses the following topics: •... -
Page 24: Port Indicators
Table 7: Switch Indicators LED States LED Name LED State Device Status System Status Blinking Green System powering up. Green All power supplies and fans are operating normally. Blue The locator function is active. A power supply or fan is missing or in a failed state. Fan Status Green All fans are operating normally. -
Page 25: Rear Status Indicators
Status Indicators Rear Status Indicators Fan and power supply modules are accessed from the rear panel. Each fan and power supply module contains an LED that reports the module status. Rear Panel displays the rear panel of all switches covered by this guide. - Page 26 Note: You can narrow the error condition by logging in to the switch to view the specific device state. Refer to the Arista User Manual’s Switch Environment Control chapter under Viewing Environment Status for further information on the show environment commands.
-
Page 27: Appendix B: Parts List
Figure B-1: Two-Post Rack Mount Parts Cables List of provided cables. Quantity Description Power cables: IEC-320/C15-C16, 13 A, 250 V, 2-meter RJ-45 Patch Panel Cable, 2-meter RJ-45 to DB9 Adapter Cable, 2-meter Note: All provided power cables are for use only with Arista products. -
Page 28: Appendix C: Front Panel
Appendix C Front Panel This section displays the front panel of all switches covered by this guide. Figure C-1: CCS-720XP-96ZC2 1 System status LED 5 USB port 9 5G PoE ports 2 Fan status LED 6 Console serial port 10 2.5G PoE ports 3 PSU status LED 7 25G ports 4 Ethernet management port... - Page 29 Front Panel Figure C-2: CCS-720XP-96ZC2-M-S 1 System status LED 5 USB port 9 5G PoE ports 2 Fan status LED 6 Console serial port 10 2.5G PoE ports 3 PSU status LED 7 25G ports 4 Ethernet management port 8 100G ports...
-
Page 30: Rear Panel
Appendix D Rear Panel This section displays the rear panel of all switches this guide covers. Depending on the power supply modules installed, the rear panel on your switch may differ slightly. Figure D-1: All Models 1 Fan Module 1 4 Power Supply Module 1 7 Power Supply Module 4 2 Fan Module 2... -
Page 31: Regulatory Model Numbers
Appendix E Regulatory Model Numbers This section lists the Regulatory Model Numbers (RMNs) for the product models for the switches described in this document. Table 10: Regulatory Model Numbers and Product Numbers Regulatory Model Number (RMN) Product Name(s) AN1733 CCS-720XP-96ZC CCS-720XP-96ZC2-M-S... -
Page 32: Taiwan Rohs Information
Appendix F Taiwan RoHS Information This section provides the Taiwan RoHS information for switches this guide covers. For the Taiwan BSMI RoHS Table, go to https://www.arista.com/assets/data/pdf/AristaBSMIRoHS.pdf.
