- Page 1 POWER WASHER MODEL NO: JETSTAR 1850B PART NO: 7336015 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0425...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Power Washer. This pressure washer is designed for cleaning machines, vehicles, buildings, boats, facades, terraces, gardening tools, etc. by means of a high-pressure water jet (if necessary, with additional cleaning agents). Only use accessories, replacement parts and cleaning agents recommended by CLARKE International.
- Page 3 4. NEVER allow children or untrained personnel to use this machine. 5. NEVER operate the machine with any of the covers removed. 6. NEVER attempt any repairs to this machine. ALWAYS refer to your CLARKE dealer. 7. NEVER supply any liquid other than water to the water inlet.
- Page 4 20. WARNING: Water that has flowed through a system separator (known as a backflow preventer) is considered non-drinkable. SYMBOLS ON THE MACHINE Read the manual Warning: High level of noise when in use. before use. Wear ear protection Wear safety glasses when using this when using this machine.
- Page 5 ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage.
- Page 6 OVERVIEW Main Body of Power Washer Detergent Bottle & Hose Holder Wheels Lance Detergent Bottle Spray Gun Handle 10 Inlet Connector with Filter Cable Holder 11 High Pressure Hose Spray Gun & Lance Holder 12 Bag of Screws & Nozzle Cleaning Tool Parts &...
- Page 7 ASSEMBLY WHEELS 1. Fit the wheels into the wheel slots at the bottom of the main body. 2. Push the wheels into the slots so they sit flush. HANDLE 1. Slide the handle onto the brackets located on top of the main body of the washer.
- Page 8 GUN AND LANCE HOLDER 1. Slide the gun & lance holder on to the bracket on the side of the washer, as shown. CABLE HOLDER 1. Slide the cable holder on to the bracket on the side of the washer, making sure it is on the side that the cable exits the main body of the washer, as shown.
- Page 9 2. Insert the hose into the hose connection port on the underside of the gun, as shown. 3. To release the hose, press the hose release clip in and pull down on the hose. 4. Insert the high pressure hose into the water outlet on the front of the pressure washer and push in until you hear a click, as shown.
- Page 10 SAFETY FEATURES THERMAL SENSOR A thermal sensor protects the motor against overloading. The machine will restart after a few minutes, once the thermal sensor has cooled down. GUN TRIGGER LOCK The gun trigger has a locking device, as shown. When the device is raised and locked into the grooves on the rear of the handle, the gun can not be operated.
- Page 11 • A standard garden hose connector or a reinforced hose with an inner diameter of at least 10 mm available from your CLARKE dealer will be suitable. 4. Connect the supply hose to the water supply. • The water supply must provide a maximum of 5 litres per minute at a maximum of 40°C.
- Page 12 3. Turn the power switch to the ‘ON’ position. 4. Move the trigger locking device to the ‘OFF’ position. • The pressure washer is now ready for use. 5. Make sure that you have a firm footing and are also holding the gun and spray lance firmly.
- Page 13 1. Remove the cap and fill the bottle with a max. of 250ml of detergent. • Only use detergents recommended for use with pressure washers such as the CLARKE listed below, available from your CLARKE dealer. DESCRIPTION SIZE PART NUMBER...
- Page 14 SHUTTING DOWN When you have finished using the pressure washer, follow the procedure shown below to switch off and disconnect the unit. 1. Set the power switch to the ‘OFF’ position. 2. Turn off the water supply at the tap. 3.
- Page 15 MAINTENANCE WARNING: REMOVE THE PLUG FROM THE SOCKET-OUTLET BEFORE CLEANING OR MAINTENANCE AND WHEN REPLACING PARTS CLEANING THE NOZZLE If the nozzle becomes partially clogged with foreign material such as dirt or limescale, excessive pressure may develop and the pump pressure will pulsate. Clean the nozzle immediately as follows: 1.
- Page 16 Fluctuating The pump is drawing in air Check that hoses and connections are pressure airtight Valves are dirty, worn or Contact your nearest CLARKE service sticking centre The water supply is not Increase water pressure, check for sufficient...
- Page 17 Clean the inlet water filter Folded hose Unfold any kinks that maybe in the inlet or outlet hoses The washer Pump fuse and/or trigger Contact your nearest CLARKE service turns on and off out of order centre by itself No water supply...
- Page 18 PRODUCT SPECIFICATIONS Model Number JETSTAR 1850B Part Number 7336015 Voltage and Frequency 230V/50Hz Electrical Insulation Class Input Power @ Rated Load 1600W Input Current @ Rated Load 5.7A Plug Fuse Rating Duty Cycle S1 Continuous IP Rating IPX5 Working Pressure (Outlet)
- Page 19 DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
