We strongly recommend you to read the user guide completely before you install.
HiBoost 10K Smart Link provides 2 options of booster installation,
APP and LCD installation ways are unique methods provided by HiBoost.
1.App assisted installation,
FIRST CHOICE From Page 6~19
It's more convenient and many work could be done by ONE person, and the
most important is that the obtained signal can be very precise.
2. LCD assisted installation,
SECOND CHOICE From Page 20~32
It can achieve the same precise effect as App guidance.
But it may need two people and the installation process is a little cumbersome.
Quick Install Guide
Advertisement
Related Manuals for HiBoost B09LCVM15S
Summary of Contents for HiBoost B09LCVM15S
- Page 1 We strongly recommend you to read the user guide completely before you install. HiBoost 10K Smart Link provides 2 options of booster installation, APP and LCD installation ways are unique methods provided by HiBoost. 1.App assisted installation, FIRST CHOICE From Page 6~19 It’s more convenient and many work could be done by ONE person, and the...
- Page 2 1dB more power is so precious when you suffer from no signals. HiBoost App & LCD signal meters will help you to fine tune the best power and get as much cover of your spaces. Quick Install Guide...
- Page 3 General Working Principle: Before we start any of the two ways, please allow us to spend 3 pages to make you understand how the booster system works for you. ※ Please do spend sometime to read it fully, as it is crucial to get full bars for your rooms. Quick Install Guide...
- Page 4 Working Principle in Formula System Output Power + (Indoor Antenna Gain) (Indoor Cable Loss) (Outside Signal) (Outdoor Cable Loss) + (Booster Gain) + (Outdoor Antenna Gain) Out of the Formula: Outside Signal: To be received by outdoor antenna from cell tower Outdoor Antenna Gain: The gain of outdoor antenna Outdoor Cable Loss: The loss of the outdoor cable Booster...
- Page 5 More notes on how to keep the maximum booster gain. The loop back from the outdoor antenna to the indoor antennas will reduce the gain, so the principle to keep the maximum booster gain is to avoid the loop back from the outdoor antenna to the indoor antennas. Measures can be taken to avoid the loop back 1) Increase the distance between the outdoor and indoor antennas, generally the same vertical distance generates more loss than horizontal, and to follow easily, a Typical Required Distance Between Outdoor and Indoor Antennas Over 30 feet(10 meters) horizontal distance or 13 feet (4 meters) vertical distance.
- Page 6 1 Now let’s start by the APP assisted installation Flow chart of APP Assisted Installation 3. Seek best outside signal and 2. Download “Signalsupervisor” 1. Download 3 Party App install outdoor antenna and connect with booster 4. Fine tune indoor antenna for best coverage and avoid 6.
- Page 7 Step 1: Download the 3rd Party Mobile Apps We are going to use 3 party APPs: 1. To find the cell tower location 2. To test the signal strength and quality There are a variety of resources available online: Opensignal, Cell mapper, Network cell info lite, etc.
- Page 8 Step 2: Download Signal Supervisor APP and connect the booster 1) Search “Signal Supervisor” on Google Play/ App Store, or scan the left QR Code to Download the download. Signalsupervisor App, 2) Register on the Signal Supervisor APP. register ID and booster. 3) Switch on the booster * The Bluetooth/WiFi antenna is built in, there is no need to connect outdoor or indoor antennas at this moment.
- Page 9 Step 3: Look for best outside signal and install outdoor antenna The performance of the booster system is heavily dependent on the successful installation of the outdoor antenna 3.1 Connect the booster with outdoor antenna Put the booster near to the location you would like to install in the future, or a place with power outlet temporarily.
- Page 10 Step 3: Look for best outside signal and install outdoor antenna 3.2 Select the possible location for outdoor antenna. Bring your mobile phone with the APPs and the outdoor antenna to the location where the best outside signal can be found. The outdoor antenna is recommended to be at the four corners or high end of the roof, or attic.
- Page 11 3.3 Use 3rd party APP to locate the tower(s) Now open “Opensignal”, use it to detect the approximate position of the nearby cell tower. Insert your detail address in “Search city” box. (following figure 1) Enter signal dashboard, and click “CELL TOWERS”. Then zoom in map to find best one, it will show a blue line with your place which means your cellphone connected one.
- Page 12 You can also use the “Network Cell Info Lite” to locate the tower and measure the signal strength before & after install. The good point of Network Cell Info Lite is that you can see the signal levels. But it seems to be only available for Android. Network Cell Info Lite Quick Install Guide-APP...
- Page 13 3.3 Use 3rd party APP to locate the tower(s) The signal strength requested by the booster system is as below. Your signal strength is going to be a good indicator of how fast you The reason to test your internet speed is to make sure you'll be can download and stream, but for voice, it’s more like “Can I make a able to stream high-bandwidth movies, like those from Netflix, call, or not?”...
- Page 14 3.4 Look for the best location and direction of outdoor antenna After the tower is located, please pick up outdoor antenna and point to the tower and adjust its direction precisely Watch the signal gauge of Signal Supervisor App as it will show the booster’s best output power when you get the strongest outside signal. Target: Try to get the highest possible output power for each band and try to make 2-3 gauges turn green.
- Page 15 3.5 Fix outdoor antenna 3.6 Reconfirm that the signal on signal gauge is the best! Now install the outdoor antenna firmly Please do take screen shot for future comparison during indoor antenna install. What you are going to be paying attention to here, is the gain values. If you have Interference between your indoor and outdoor antennas, then the booster will lower the gain and these values will decrease.
- Page 16 Step 4: Install the indoor antenna 4.1 Now it’s turn to install the indoor antenna Note: It is better to have two personals at this stage. One can go around to find the best place for indoor antenna. While the other can walk around to make tests all over to make sure every spot is covered with stable and high quality signal.
- Page 17 4.3 Find the proper location for indoor antenna Determine the location according to the antenna’s radiation pattern. The radiation pattern is 80° horizontal and 70° vertical. So try to make sure the space will fall into its radiation pattern. 2) After finding the location, hold it there, and watch the gain and power on the App’s signal gauge, they shall keep the same or very nearby with the screen shot taken during outdoor antenna install.
- Page 18 4.4 Signal Quality test After finding such a location, hold the indoor antenna there and ask the other person to walk back and forth, and use the party app to test the signal strength, voice, and data. We recommend you to test the signal strength, the voice quality and data speed.
- Page 19 Step 5: Install the booster and the cables Mount the signal booster in a dry and cool area, and it shall be easily accessible for maintenance. And run the cables neatly, please do use the water-proof tape to protect all outside connections from the weather Test again the performance after installation done a.
- Page 20 2 Now let’s start by the LCD assisted install Flow chart of LCD Assisted Install 2. Seek best outside signal and 1. Download 3 Party App install outdoor antenna 3. Fine tune indoor antenna 5. Final test and enjoy the for best coverage and avoid 4.
- Page 21 Step 1: Download the 3rd Party Mobile Apps We are going to use 3 party APPs: 1. To find the cell tower location 2. To test the signal strength and quality There are a variety of resources available online: Opensignal, Cell mapper, Network cell info lite, etc.
- Page 22 Step 2: Install the outdoor antenna 2.1 Connect the booster with outdoor antenna Put the booster near to the location you would like to install in the future, or a place with power outlet temporarily. Connect the booster with Bluetooth/WiFi antenna. Switch on the booster.
- Page 23 Step 2: Install outdoor antenna 2.2 Select the possible location for the outdoor antenna. Bring your mobile phone with the 3 party APPs and the outdoor antenna to the location where the best outside signal can be found. The outdoor antenna is recommended to be at the four corners or high end of the roof, or attic. The outdoor antenna needs to maintain a clear line of sight with the cell tower.
- Page 24 3.3 Use 3rd part APP to locate the tower(s) Now open “Opensignal”, use it to detect the approximate position of the nearby cell tower. Insert your detail address in “Search city” box. (following figure 1) Enter signal dashboard, and click “CELL TOWERS”. Then zoom in map to find best one, it will show a blue line with your place which means your cellphone connected one.
- Page 25 You can also use the “Network Cell Info Lite” to locate the tower and measure the signal strength before & after install. The good point of Network Cell Info Lite is that you can see the signal levels. But it seems to be only available for Android. Network Cell Info Lite Quick Install Guide-LCD...
- Page 26 3.3 Use 3rd part APP to locate the tower(s) The signal strength requested by the booster system is as below. Your signal strength is going to be a good indicator of how fast you The reason to test your internet speed is to make sure you'll be can download and stream, but for voice, it’s more like “Can I make a able to stream high-bandwidth movies, like those from Netflix, call, or not?”...
- Page 27 2.4 Look for the best location and direction of outdoor antenna Now pick up the outdoor antenna and point to above cell tower and adjust its position precisely, ask your partner to watch the LCD signal gauge to get a strongest possible output signal. You can either look at the signal meter value, 12dBm is the best Notes: The output power level in the signal meter is the level for each of the two indoor antennas.
- Page 28 2.5 Fix outdoor antenna 2.6 Reconfirm that the signal on LCD signal meter is the best! Now install the outdoor antenna firmly take photo of LCD signal meter for future comparison during indoor antenna install. The connector of the cable connection part must be glued with black waterproof glue to prevent long-term signal drop and reduce signal loss! Quick Install Guide-LCD...
- Page 29 Step 3: Install the indoor antenna 3.1 Now it’s turn to install the indoor antenna Note: It is better to have two personals at this stage. One can go around to find the best place for indoor antenna. While the other can walk around to make tests all over to make sure every spot is covered with stable and high quality signal.
- Page 30 3.3 Find the proper location for indoor antenna Determine the location according to the antenna’s radiation pattern. The radiation pattern is 80° horizontal and 70° vertical. So try to make sure the space will fall into its radiation pattern. 2) After finding the location, hold it there, and ask the other person to compare the gain and power on LCD signal meter, they shall keep the same or very nearby with the photo taken during outdoor antenna install.
- Page 31 3.4 Signal Quality test After finding such a location, hold the indoor antenna there and ask the other person to walk back and forth, and use the party app to test the signal strength, voice, and data. We recommend you to test the signal strength, the voice quality and data speed.
- Page 32 Step 4: Install the booster and the cables Mount the signal booster in a dry and cool area, and it shall be easily accessible for maintenance. And run the cables neatly, please do use the water-proof tape to protect all outside connections from the weather Test again the performance after installation done a.
