REFRIGERATION

RC10.4S.70, RC10.4T.70, RC10.4S.90, RC10.4T.90, RC10.4P.100, RC10.4M.90,

RCS10.5S, RCS10.5T, RCS10.5XS, RCS10.5XT, RCL10.4E, RCL10.4ES, RCL10.4ET,

RCD10.5S, RCD10.5T, RCD10.5XS, RCD10.5XT

Compressor refrigerator

Installation Manual.................................................... 2

10-SERIES

Need help?

Do you have a question about the 10 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Dometic 10 Series

Page 1 REFRIGERATION 10-SERIES RC10.4S.70, RC10.4T.70, RC10.4S.90, RC10.4T.90, RC10.4P.100, RC10.4M.90, RCS10.5S, RCS10.5T, RCS10.5XS, RCS10.5XT, RCL10.4E, RCL10.4ES, RCL10.4ET, RCD10.5S, RCD10.5T, RCD10.5XS, RCD10.5XT Compressor refrigerator Installation Manual............ 2...
Page 2 This product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com.
Page 3 EN The refrigerant in the refrigerant circuit is highly ﬂammable and in the event of a leakage combustible gases could build up if the device is in a small room. In the event of any damage to the refrigerant circuit: •...
Page 4 • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product speciﬁcations. Installation The mechanical and electrical installation and setup of the device must be performed by a qualiﬁed...
Page 5 EN • The refrigerator can be easily removed from the vehicle • Do not install the refrigerator in the rear of recreational vehicles with the door facing the direction of travel. NOTE Exception: In motorhomes, the RC10.4 models can be installed with the door facing the direction of travel, provided it is installed behind the drivers seat or passenger seat.
Page 6 EN RC10.4P.100 RC10.4M.90 Refrigerator height (A) 900 mm 901 mm Refrigerator width (B) 420 mm 420 mm Refrigerator depth (C) 655 mm 485 mm (excluding control knob, 5 mm) Recess height (H) 907 mm 908 mm Recess width (W) 425 mm 425 mm Recess depth (D) 657 mm 487 mm RCD10.5(S)(T) RCD10.5X(S)(T) Refrigerator height (A) 1282 mm 1282 mm Refrigerator width (B)
Page 7 EN 5.1.2 Preparing the installation  When installing the refrigerator, note the following: • Park the vehicle horizontally to ensure that the ﬂoor is solid and level. • If the compressor refrigerator replaces an absorption unit, ensure that the external ventilation grilles are fully closed, otherwise there is a risk that the compressor will not run at low ambient temperatures (approx.
Page 8 EN Compressor unit Duct Width 185 mm 190 mm Depth 396 mm 400 mm Mounting the compressor unit NOTICE! Damage hazard Lay the suction pipe in such a way that it is not damaged (e.g. by sharp edges or strong bends). Observe the minimum bending radius of the suction pipe ( ≥ 30 mm). 1.
Page 9 EN Variant 2: Connect the condensation hose directly to the fastening provided on the ventilation grille (1).  5.1.5 Connecting the power supply NOTICE! Damage hazard To avoid voltage loss and therefore a drop in performance, the cable should be kept as short as possible and should not be interrupted if possible.
Page 10 For the current EU declaration of conformity for your device please refer to the respective product page on dometic.com or contact the manufacturer directly (see dometic.com/dealer). Further product information can be accessed via QR code on the energy label or via eprel.ec.europa.eu.
Page 11 EN ...
Page 12 EN ...
Page 13 EN  RC10.4(S)(T).70 RC10.4(S)(T).90 Connection voltage 12 V Capacity: Gross capacity 62 L 86 L Refrigerator compart- 54.5 L 75.5 L ment Frozen compartment 7.5 L 7.5 L Total net capacity 62 L 83 L Excluding frozen com- partment: Gross capacity 69 L 90 L Net capacity 64 L 85 L Power consumption 42 W Energy consumption 0.45 kWh/ 24 h...
Page 14 EN RC10.4(S)(T).70 RC10.4(S)(T).90 QUIET mode 39 dB(A) 39 dB(A) Dimensions (H x W x D) 821 × 420 × 450 mm 975 × 420 × 485 mm Weight 19.5 kg 21.4 kg Maximum weight per 3 kg door shelf Maximum weight per 7.5 kg door Inspection/certification RC10.4P.100 RC10.4M.90 Connection voltage 12 V Capacity: Gross capacity 94 L 86 L...
Page 15 EN RC10.4P.100 RC10.4M.90 Weight 21 kg 20.4 kg Maximum weight per 3 kg door shelf Maximum weight per 7.5 kg door Inspection/certification RCD10.5(S)(T) RCD10.5X(S)(T) Connection voltage 12 V Capacity: Gross capacity 94 L 86 L Refrigerator compart- 81 L 75.5 L ment Frozen compartment 9 L 7.5 L Total net capacity 90 L 83 L Excluding frozen com-...
Page 16 EN RCD10.5(S)(T) RCD10.5X(S)(T) Inspection/certification RCL10.4(S)(T) RCL10.4E(S)(T) Connection voltage 12 V Capacity: Gross capacity 133 L 154 L Refrigerator compart- 116 L 131 L ment Frozen compartment 12 L 18 L Total net capacity 128 L 149 L Excluding frozen com- partment: Gross capacity 139 L 157 L Net capacity 134 L 152 L Power consumption 54 W 57 W...
Page 17 EN RCS10.5(S)(T) RCS10.5X(S)(T) Capacity: Gross capacity 78 L 92 L Refrigerator compart- 69.1 L 80.3 L ment Frozen compartment 9.2 L 12.1 L Total net capacity 78 L 92 L Excluding frozen com- partment: Gross capacity 83 L 98 L Net capacity 83 L 98 L Power consumption 5.9 A 5.5 A Energy consumption 0.42 kWh/ 24 h 0.43 kWh/ 24 h PERFORMANCE mode...
