VT100 Body Camera Quick Start
Guide
ED-006-012-AA
© 2024 Motorola Solutions, Inc. All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the VT100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Motorola solutions VT100

  • Page 1 VT100 Body Camera Quick Start Guide ED-006-012-AA © 2024 Motorola Solutions, Inc. All Rights Reserved.
  • Page 2 English VT100 Body Camera Overview BACK Familiarise yourself with the buttons and functions on your body camera. FRONT Attachment Micro Point for Clip USB Port Lens Press to Record Button & LED Slot for Custom ID Card Microphone...
  • Page 3 NOTE: The VT100 is designed to function on standby for up to six months. It is necessary to fully charge the device before first use. To charge your VT100, you need either the VT100 variant of the Dock or a USB charging cable. USB Charging Cable...
  • Page 4 Using the VT100 A solid blue light on the back-right LED indicates that the VT100 is connected to the Wi-Fi. NOTE: If your VT100 has not been configured by your The recording LED on the back-left of the camera as VideoManager Admin...
  • Page 5 English To stop recording, press and hold either of the ● buttons on the back of your VT100 for one second. Result: STOPPED The LED on the front switches off. If your VT100 RECORDING (No LED) is configured to live stream, the back-right LED...
  • Page 6 English Mounting Options The VT100 can be attached to most uniforms and items of clothing by using one of the robust clips which can be purchased from Motorola Solutions. The following mounting options are available: Rotatable long alligator clip ●...
  • Page 7 Detaching the VT100 From a Rotatable Long Alligator Clip Pull the lip of the attachment plate away from the body of your VT100 and firmly pull the attachment out of the rails.
  • Page 8 3. Slide the VT100 into the Klick Fast dock upside down so that the serial number of the camera is pointing towards the ceiling. 4. When the stud is firmly attached to the dock, rotate the VT100 by twisting it until it is the right way up.
  • Page 9 English Mounting the VT100 Using a Detaching the VT100 From a Sports Camera Pillar Sports Camera Pillar (VT-100- FIX-SPORT) Pinch the two metal clips on the back of the stud together, and slide the stud, along with the sports Additionally, you need: camera pillar, upwards out of the attachment rail.
  • Page 10 2. To detach an epaulette mount from your uniform, 1. Attach your VT100 to the mount by pulling the metal slide the mount upwards slightly so that the hook clip on the back of the stud towards the mount, and detaches from your epaulette’s button.
  • Page 11 5. Put the lanyard on and adjust length to suit using the break points. The Motorola Solutions lanyard (AC-LANYARD-05) is a long piece of sturdy polyester ribbon, with a split ring at each end and a phone strap attached to each split ring. The lanyard has five break points for added safety allowing for quick release if pulled on.
  • Page 12 English Maintenance and Care Tips ALWAYS NEVER Use compressed air to Always take a few minutes to ensure your camera is clean the camera. Com‐ working correctly before you begin any assignments. pressed air can dam‐ Performing the following basic tasks ensures that your age the camera’s micro‐...
  • Page 13 This device must accept any interference received, ● including interference that may cause undesired operation. Changes or modifications made to this device, not ● expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment.
  • Page 14 1. This device may not cause harmful interference, and Per FCC CRF 47 Part 2 Section 2.1077(a) Responsible party Name: Motorola Solutions, Inc. Address: 2000 Progress Pkway, Schaumburg, Il. 60196 Phone Number: 1-800-927-2744 Hereby declares that the product:...
  • Page 15 English 2. This device must accept any interference received, NOTE: including interference that may cause undesired This equipment has been tested and found to comply operation. with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 16 English For Country Code Selection Usage (WLAN Devices) NOTE: The product does not have a country code selection feature. Per FCC regulations, all Wi-Fi products marketed in US must be fixed to US operation channels only.
  • Page 17 Federal Communications Commission of the U.S. Government. For body worn operation, this device has been tested and meets the FCC RF exposure guideline for use with a Motorola Solutions,Inc. approved accessories sold with this device. For information on product details, brochures, user manuals, and approved accessories, refer to motorolasolutions.com.
