Prestige APS57TM Quick Installation Manual

APS 57 TM
Remote Start
System Layout
1 3 5
2 4 6
1 Yellow Starter Output (+)
2 Green Igni�on 2 Output (+)
3 Red Ba�ery 12V Input (+)
4 Red/White Ba�ery 12V Input (+)
5 Purple Accessory Output (+)
6 Blue Igni�on Input / Output (+)
Replacement Part #4120467
1 3
2 4
1 White Parking Light (30) Output
2 White/Red Parking Light (87) Input
3 Yellow/Black Igni�on Output For Alarm (+)
4 Black Ground Input (-)
Replacement Part #4120463
1 2 3 4
1 White
2 Black
3 Blue
4 Red
Accessory Sold Seperatly
For Complete Installation Guide and Technical Support Visit www.voxxuniversity.com. Or Call 1-800-225-6074
P
P
P
Data RX
Ground (-)
Data TX
Ba�ery 12V (+)
Replacement Part #4120465
Replacement Part #183BP
FLCART Dock
Replacement Part #4361009
1 2 3 4 5 6
1 Pink Ba�ery 12V (+)
2 Green Data RX
3 Black Ground (-)
4 Red Valet Switch
5 Blue LED (-)
6 Empty Empty
Replacement Part #4180070
14 Green/Orange Tach Input
13 Black/Yellow Pulse During Crank Output (-)
12 Green/Yellow Glow Plug Input (+)
11 Black/Red Pulse A�er Shutdown Output (-)
10 Dk. Blue Trunk Output (-)
13 14
9 Black/Blue Factory Disarm Output (-)
11 12
9 10
8 Brown/Black Brake Input (+)
7 8
7 Black/Lt. Green Factory Arm Output (-)
5 6
3 4 6 Dk. Blue/Black External Ac�va�on Input (-)
1 2
5 Lt. Blue Remote Start Status Output (-)
4 Green Unlock Output (-)
3 Gray/Black Hood Input (-)
2 Red Lock Output (-)
1 Black/White Horn Output (-)
4 Red Ba�ery 12V (+)
1
3 Blue Data TX
2
2 Black Ground (-)
3
1 White Data RX
4
4
4 Red Ba�ery 12V (+)
3 Black Ground (-)
3
2 White Data RX
2
1 Blue Data TX
1
19 20
17 18
15 16
This Harness is included with the FLCART.
13 14
11 12 For Wire Informa�on and Diagram Please Refer to Vehicle Specific
FlashLogic Install Guide.
9 10
7 8 Visit www.FlashLogic.com for More Informa�on.
5 6
3 4
1 2
2025 Voxx Electronics. All Rights Reserved.
Replacement Part #4120476
Accessory Sold Seperatly
Accessory Sold Seperatly
