Prestige APS57Z Quick Installation Manual

APS 57 Z
Remote Start
System Layout
1 3 5
2 4 6
1 Yellow Starter Output (+)
2 Green
Ignition 2 Output (+)
3 Red
Battery 12V Input (+)
4 Red/White
Battery 12V Input (+)
5 Purple
Accessory Output (+)
6 Blue
Ignition Input / Output (+)
Replacement Part #4120467
1 White
Parking Light (30) Output
2 White/Red
Parking Light (87) Input
3 Yellow/Black
Ignition Output For Alarm (+)
4 Black Ground Input (-)
Replacement Part #4120463
1 3
2 4
P
P
P
Replacement Part #183BP
Replacement Part #4360847
Replacement Part #4180070
6
6 Empty
Empty
5
5 Blue LED (-)
4 4 Red Valet Switch
3 Black Ground (-)
3
2 Green
Data RX
2
1 Pink
Battery 12V (+)
1
4
4 Red Battery 12V (+)
3 3 Black Ground (-)
2 White Data RX
2
1
Blue Data TX
1
4
4 Red
Battery 12V (+)
3 3 Blue
Data TX
2
Black Ground (-)
2
1
White Data RX
1
14 Green/Orange Tach Input
13 Black/Yellow Pulse During Crank Output (-)
12 Green/Yellow
Glow Plug Input (+)
11 Black/Red
Pulse After Shutdown Output (-)
13 14 10 Dk. Blue
Trunk Output (-)
11 12
9 Black/Blue
Factory Disarm Output (-)
9 10
8 Brown/Black
Brake Input (+)
7 8
7 Black/Lt. Green
Factory Arm Output (-)
5 6
6 Dk. Blue/Black
External Activation Input (-)
3 4
5 Lt. Blue Remote Start Status Output (-)
1 2
4 Green Unlock Output (-)
3 Gray/Black Hood Input (-)
2 Red
Lock Output (-)
1 Black/White
Horn Output (-)
2018 Voxx Electronics. All Rights Reserved.
Replacement Part #4120465
Not Included
Not Included
Replacement Part #4120476
