ULTRA SERIES | ULTRAMD33

Installation & Operation Instructions

The Santa Fe UltraMD33 is a built-in dehumidification

solution that can be conveniently installed inside

standard wall framing. The Santa Fe UltraMD33 provides

the ultimate in:

+ Comfort

+ Health

+ Property Protection

800.533.7533 | Santa-Fe-Products.com

Santa-Fe-Products.com | 800.533.7533

Serial Number

Install Date

Sold By

Patent: thermastor.com/patents

* Previously the Ultra Aire MD33.

Santa Fe ULTRAMD33 Installation & Operation Instructions

TS-2091 07/24 Rev A
