ULTRA SERIES | ULTRA70
Installation Instructions
The Santa Fe Ultra70 is a ventilating dehumidifier
that integrates with the heating and cooling system
to provide the ultimate in comfort, health and property
protection through:
+ Dehumidification
+ Outdoor Air Ventilation (Optional)
+ MERV-13 Air Filtration
800.533.7533 | Santa-Fe-Products.com
Santa-Fe-Products.com | 800.533.7533
Serial Number
Install Date
Sold By
Patent: thermastor.com/patents
* Previously the Ultra Aire 70H.
Santa Fe ULTRA70 Installation & Operation Instructions
1
TS-2082 07/24 Rev A
Advertisement
Table of Contents
Related Manuals for Santa Fe ULTRA Series
Summary of Contents for Santa Fe ULTRA Series
- Page 1 ULTRA SERIES | ULTRA70 Installation Instructions The Santa Fe Ultra70 is a ventilating dehumidifier Serial Number that integrates with the heating and cooling system to provide the ultimate in comfort, health and property Install Date protection through: + Dehumidification Sold By...
-
Page 2: Table Of Contents
Warranty ..................28 FOR REPAIR & TECH SUPPORT: 1-800-533-7533 (follow prompts) or CONTACT US AT: service@santa-fe-products.com Santa Fe is committed to manufacturing quality products. To maintain our standards, product specifications may change without notice. 4201 Lien Road, Madison, WI 53704 (800) 533-7533 Thermastor.com | Santa-Fe-Products.com... -
Page 3: Safety Instructions
PROPERTY DAMAGE. Read the installation, operation and maintenance instructions carefully before installing and operating this device. Proper adherence to these instructions is essential to obtain maximum benefit from the Santa Fe Whole House Ventilating Dehumidifier. WARNING! 120 VOLTS MAY CAUSE SERIOUS INJURY FROM ELECTRIC SHOCK. DISCONNECT ELECTRICAL POWER BEFORE STARTING INSTALLATION OR SERVICING, AND LEAVE POWER DISCONNECTED UNTIL INSTALLATION OR SERVICE IS COMPLETED. -
Page 4: Assembly & Registrations
8” Round Duct Collars (2) 3. Register warranty at santa-fe-products.com 4. Read all remaining steps and warnings before continuing. REGISTRATIONS THE SANTA FE ULTRA70 CONFORMS TO UNIFIED STANDARD UL 60335-2-40 AND CSA STANDARD C22.2.60335-2-40. Brand Name Individual Basic Model... -
Page 5: Dehumidifier Set Up
(for example an operating gas appliance) or other POTENTIAL IGNITION SOURCES (for example an operating electric heater, hot surfaces). A flame-producing device may be installed in the same space if the device is provided with an effective flame arrest. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions... -
Page 6: Attaching Duct Collars
8" Supply Air Outlet 8" Supply Air Outlet 8" Supply Air Outlet Front View Rear View Front View Rear View Front View Rear View Front View Rear View Top View Top View Santa Fe ULTRA70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... -
Page 7: Electrical Requirements
Consult local electrical codes for any further information. Santa Fe offers a variety of control devices for use with the Santa Fe Ultra70. The controls are to be located remotely from the dehumidifier and placed in the space to be conditioned. Low voltage (24 Volt) controls can be used with the Santa Fe Ultra70 and MUST be connected with low voltage (18-22 gauge) thermostat wire. -
Page 8: Drain Installation
Pitch of drain should be 1" per 10'. An optional condensate pump kit is available for use with the Santa Fe Ultra70 and may be installed if lift is required to dispose of condensate. Condensate is automatically pumped to a remote location when the water level in the pump’s reservoir rises to close the float switch. -
Page 9: Ducting To Hvac Systems
All flexible ducting connected to the Santa Fe Ultra70 should be UL listed. • A short piece of flexible ducting on all Santa Fe Ultra70 duct connections is recommended to reduce noise and vibration transmitted to rigid ductwork in the structure. -
Page 10: Recommended Hvac System Installations
Install a dedicated 8" air return for the Santa Fe Ultra70 from a central area of the structure. • Duct the supply of the Santa Fe Ultra70 to the supply of the HVAC system with a backdraft damper. • If the existing system has multiple returns, instead of installing a dedicated return to the Santa Fe Ultra70, it is possible to select one to disconnect from the existing HVAC system and use it for the dedicated Santa Fe Ultra70 return. - Page 11 HVAC Supply Ultra Series Indoor HVAC Return Air Return DEH 3000 control Backdraft Damper Dry Air to Basement Motorized Damper Optional Optional Outdoor Duct Tee Air Intake & Gravity Damper 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions...
-
Page 12: Alternative Hvac System Installation
DUCTING TO HVAC SYSTEMS 2. Alternative HVAC System Installation If the Recommended Dedicated Ultra Series Return to HVAC Supply Installation is not possible, there are several alternative installation options available. • DO NOT locate return in a bathroom or kitchen. -
Page 13: No Existing Ductwork Installation
Ultra70 should be installed in a central location. Install a 6” insulated duct from outside, teeing into the 8” return duct of the Ultra Series Dehumidifier to provide outdoor air ventilation (optional). - Page 14 Where outlet space is restricted, the outlet duct collar is optional or vertical flow through may be preferred. Central Return to HVAC Supply Duct the supply of the Ultra Series Dehumidifier to the supply of the existing HVAC system with a backdraft HVAC damper.
- Page 15 Control should be placed in a central location or the onboard control can be used for this installation. a. Central Return to HVAC Return HVAC Duct the supply of the Ultra Series Supply Dehumidifier to the return side of the existing HVAC system.
-
Page 16: Outdoor Air Ventilation
Outdoor air may be brought into the structure by connecting an insulated duct from outside the structure to a tee located in the inlet duct of the Santa Fe Ultra70. A ventilation control is needed to program the time and frequency that the unit introduces outside air. -
Page 17: Determine Ventilation Requirements
Option 2: Calculating Airflow Requirement Using Table 4.1 from ASHRAE 62.2-2019 Ventilation Air Requirements, CFM Number of Bedrooms Floor Area <500 501-1000 1001-1500 1501-2000 2001-2500 2501-3000 3001-3500 3501-4000 4001-4500 4501-5000 Table 4.1 from ASHRAE 62.2-2019 Record the required CFM ____________ 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions... -
Page 18: Controls
If the Santa Fe Ultra70 is located outside of the area where humidity control is desired, consider using a remote wired humidity controller that is located in the area where humidity control is desired. In this configuration the built in dehumidastat should be set to off. - Page 19 Make contact between 24V and FAN terminals Power HVAC Accessory Connect the accessory to the COM and 24V terminals NOTE: 18 gauge wire needed between the Santa Fe Ultra70 dehumidifier and the external control. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions...
-
Page 20: Air Filtration
AIR FILTRATION The Santa Fe Ultra70 is equipped with a MERV-13 (Dimensions: 0.75” x 9.00” x 11.38”) air filter. The filter should be checked and replaced every three to six months. Operating the unit with a dirty filter will reduce dehumidifier capacity and efficiency. -
Page 21: Merv Rating Chart
Standing Dust <20% 65-70% Spray Paint Dust Textile Fibers Electrostatic - Self Charging Woven Panel <20% <65% Window A/C Units Carpet Fibers Filter Table Data Source: United States Environmental Protection Agency 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions... -
Page 22: Service
A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere. Santa Fe ULTRA70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... - Page 23 Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions...
-
Page 24: Charging Procedures
• Prior to recharging the system, it shall be pressure-tested with the appropriate purging gas. The system shall be leak-tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site. Santa Fe ULTRA70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... -
Page 25: Refrigerant Recovery
Only electric heating to the compressor body shall be employed to accelerate this process. When oil is drained from a system, it shall be carried out safely. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions... -
Page 26: Troubleshooting Procedure
2. Obstruction prevents fan 10. If the problem persists, then the control is fan is being called impeller rotation. most likely faulty. for. 3. Defective fan. 4. Defective fan relay. Santa Fe ULTRA70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... -
Page 27: Refrigerant Charging
Refrigerant Charging WARNING! SERVICING THE SANTA FE ULTRA70 WITH ITS HIGH PRESSURE REFRIGERANT SYSTEM AND HIGH VOLTAGE CIRCUITRY PRESENTS A HEALTH HAZARD WHICH COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY DAMAGE. SERVICE MUST BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN. -
Page 28: Warranty
Effective January 1, 2024 Limited Warranty. Therma-Stor, LLC (“Therma-Stor”) warrants as follows: (i) Santa Fe dehumidifiers (“Product”) will be free of material defects in workmanship or materials for a period of 5 years (“Five-Year Warranty”) following the date of initial purchase of such Product by an original customer purchasing from Therma-Stor or an authorized reseller (“Customer”);... - Page 29 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions...
- Page 30 Santa Fe ULTRA70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533...
- Page 31 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA70 Installation & Operation Instructions...
-
Page 32: Warranty Registration Card
WARRANTY REGISTRATION CARD IMPORTANT WARRANTY INFORMATION - DO NOT DISCARD REGISTER YOUR PRODUCT. SERIAL NUMBER PART NUMBER www.thermastor.com/registration Register your product using the serial number and part number above at www.thermastor.com/registration This is important Warranty Information. Please DO NOT DISCARD! Santa-Fe-Products.com 1.800.533.7533...
