User Manual
Luminescent Dissolved Oxygen Probe: Model LDO10101,
LDO10103, LDO10105, LDO10110, LDO10115 or LDO10130
Safety information
Precautionary labels
Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12
August of 2005. In conformity with European local and national regulations (EU Directive 2002/98/EC), European
electrical equipment users must now return old or end-of-life equipment to the Producer for disposal at no charge to
the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return end-of-life
equipment, producer-supplied electrical accessories, and all auxillary items for proper disposal.
Specifications
Specifications
Probe type
Dissolved oxygen range
Dissolved oxygen accuracy
% saturation resolution
Stabilization time
Temperature resolution
Temperature accuracy
Pressure resolution
Pressure accuracy
Operating temperature range
Storage temperature range
Minimum sample depth
Dimensions (standard)
Dimensions (rugged)
Cable connection
Product overview
Read all labels and tags attached to the instrument. Personal injury or damage to the
instrument could occur if not observed.
Note: Specifications are subject to change without notice.
Details
Luminescent dissolved oxygen (LDO) probe
0.1 to 20.0 mg/L (ppm) 1 to 200% saturation
±0.1 mg/L for 0 to 8 mg/L
±0.2 mg/L for greater than 8 mg/L
0.1%
T90% at 10 seconds (when stirred)
0.1 °C (0.18 °F)
±0.3 °C (±0.54 °F)
1 hPa
±0.8%
0 to 50 °C (32 to 122 °F)
0 to 40 °C (32 to 104 °F)
25 mm (0.984 in.)
Diameter: 15 mm (0.59 in.)
Length: 103 mm (4.1 in.)
Total length: 200 mm (7.9 in.)
Cable length: 1 or 3 m (3.28 or 9.84 ft)
Diameter: 15 mm (0.59 in.)
Length: 16 mm (0.63 in.)
Total length: 220 mm (8.7 in.)
Cable length: 5, 10, 15 or 30 meter (16.40, 32.81, 49.21 or 98.42 ft)
M12 digital output and connector compatible with HQd meters
The LDO101 series probe is a luminescent dissolved oxygen probe
LDO10105, LDO10110, LDO10115 or LDO10130 rugged probe is available with a 5, 10, 15
DOC022.53.80021
(Figure
1). The
1
Advertisement
Related Manuals for Hach LDO101 Series
Summary of Contents for Hach LDO101 Series
- Page 1 Cable connection M12 digital output and connector compatible with HQd meters Product overview The LDO101 series probe is a luminescent dissolved oxygen probe (Figure 1). The LDO10105, LDO10110, LDO10115 or LDO10130 rugged probe is available with a 5, 10, 15...
- Page 2 or 30 m (16.40, 32.81, 49.21 or 98.42 ft) cable. The LDO10101 or LDO10103 standard probe is available with a 1 or 3 m (3.28 or 9.84 ft) cable and is intended for laboratory use. The probe measures the dissolved oxygen concentration in wastewater, drinking water and general applications.
- Page 3 Calibration Before calibration: The probe must have the correct service-life time stamp. Set the date and time in the meter before the probe is attached. It is not necessary to recalibrate when moving a calibrated probe from one HQd meter to another if the additional meter is configured to use the same calibration options.
- Page 4 6. Put a stopper in 7. Remove the Read Done Store 8. Push 9. Push 10. Push the bottle and stopper. Carefully The display shows view the calibration accept the shake the bottle dry the probe cap "Stabilizing" and a summary.
- Page 5 LDO101 probe and one CDC401 conductivity cell (set to Salinity parameter). The value obtained by the CDC401 conductivity cell automatically adjusts the salinity value for the LDO101 series probe. Salinity units are represented as parts per thousand (ppt) or (º/ºº).
- Page 6 Figure 2 Salinity value out of range Advanced operation Parameter-specific settings can be changed through the Full Access Options menu. Details about menu navigation, available options and how to change them are given in the screens, tables and procedures throughout this section. The settings that can be changed are shown in Table Table 1 Parameter-specific settings...
- Page 7 • User Calibration—100% (allows user calibration) • Default 1. Make sure a probe is connected to the meter. 2. Push and select LDO101 Settings. 3. Select Modify Current Settings. 4. Select Units. Select mg/L (default) or %. 5. Select Measurement Options and update the settings: Option Description Resolution...
- Page 8 3. Select Modify Current Settings. 4. Select Calibration Options and update the settings: Option Description Calibration • User—100% (water-saturated air (100%) calibration) • User—100% with 0 (water-saturated air (100%) calibration with 0 point) • User—mg/L (calibration with a specified dissolved oxygen concentration (mg/L) solution) •...
- Page 9 Remove the shroud 1. Loosen and remove the locking ring (Figure 2. Slide the shroud and locking ring off the probe. Figure 3 Probe exploded view Shroud Probe lens Locking ridges (8x) Cap seal Locking rib Temperature sensor Locking ring 10 Locking groove Probe cap 11 Locking ribs (4x)
- Page 10 Probe not supported Software not updated Update the HQd software to the newest revision at http:// www.hach.com/SoftwareDownloads. Refer to the HQd Series meter manual for specific instructions for the meter model. HQd meter does not support Contact a Technical Support Representative.
- Page 11 Message or symptom Possible cause Action Out of range Probe cap exposed to direct Install the protective shroud. sunlight Slope out of range Probe not prepared for sample Let the probe reach equilibrium in a water-saturated air environment and do the calibration again. Calibration method settings Make sure that the calibration standards in the method are correct.
- Page 12 DOC022.53.80021...
- Page 14 Tel. +49 (0) 2 11 52 88-320 SWITZERLAND Fax (970) 669-2932 Fax +49 (0) 2 11 52 88-210 Tel. +41 22 594 6400 orders@hach.com info@hach-lange.de Fax +41 22 594 6499 www.hach.com www.hach-lange.de © HACH COMPANY, 2010. All rights reserved. Printed in the U.S.A. 11/2010, Edition 1...
