108" LED Video Wall
U S E R M A N U A L
SKU: DGV108NVB
V1.1
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Advertisement
Table of Contents
Related Manuals for Displays2go DGV108NVB
Summary of Contents for Displays2go DGV108NVB
- Page 1 108” LED Video Wall U S E R M A N U A L SKU: DGV108NVB V1.1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F C O N T E N TS BEFORE USE Safety and Warnings Packing List Product Diagram OPERATION Controller Interface Diagram Controller Power Display Media with ViPlex Express Download ViPlex Express Log Into ViPlex Express Create New Solution Publish Solution Unit Connection Methods... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance digital signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 • Verify that the device is properly installed before connecting it to power. • Do not remove the seal from the device body without consulting Displays2go first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
- Page 7 Manual may be slightly different from actual operation, and the latter is applicable. See the Installation Guide for details and instructions on installing the LED Video Wall. NOTE: PROFESSIONAL INSTALLATION REQUIRED. If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388.
-
Page 8: Packing List
Packing List PART QTY. Controller Controller Power Cable Connector LED Cabinet LED Module Wall Bracket Power Main Cable Ethernet Main Cable RGB Cable Air Suction tool Intermediate Wall Bracket *Quantity includes spare parts. HARDWARE QTY. M8*50 Expansion Screw M8*16 Threaded Post (tooth stick) M8 Hexagonal cylindrical head screw M8*25 Hex Screw M8*12 Hex Screw... -
Page 9: Product Diagram
Product Diagram FRONT VIEW Dowel Pin Hole Network Cable Hole Side Lock Hole Power Cable Hole Dowel Pin INNER CABINET VIEW (REAR) Main Power Supply LED Video Receiving Card Spare Power Supply (optional) Spare LED Video Receiving Card (optional) Network Interface Power Interface Spare Network Interface (optional) -
Page 10: Operation
O P E R AT I O N Controller Interface Diagram Power Socket USB-B Ethernet (optional hardwiring/daisy-chaining) Audio On/Off Switch HDMI (optional external media players) IP Address Information Sticker NOTE: Download the ViPlex Express Async Mode User Manual for details on using an external media player with this device. -
Page 11: Display Media With Viplex Express 1
Display Media with ViPlex Express To display content, you first need to create and publish a content playlist, known as a ‘solution’ in Viplex Express software. ViPlex Express is a program for creating, editing, and displaying content on your LED video wall. DOWNLOAD VIPLEX EXPRESS 1. -
Page 12: Create New Solution
CREATE NEW SOLUTION NOTE: The ViPlex appearance may vary from the screenshots included in this manual. Refer to the official ViPlex user manual for the most up-to-date visuals and instructions. 1. In the Solutions tab, click New the top left corner. Select Regular Scale. The Solution Information window appears. -
Page 13: Publish Solution
PUBLISH SOLUTION Publish your solution by clicking the green Publish icon. Once published, playlists can be shared to the unit via USB or network connection. P U B L I S H V I A U S B 1. Insert a USB into your PC. In ViPlex Express Solutions tab, select solution, then click the USB Playback button to open the USB Playback window. -
Page 14: Unit Connection Methods
UNIT CONNECTION METHODS C O N N E C T W I R E L E SS LY 1. Open Wi-Fi settings on your PC and find the unit Wi-Fi network. The Wi-Fi name is ‘AP’ followed by 8 digits. 2. -
Page 15: Maintenance
M A I N T E N A N C E Requirements and Warnings NOTE: PROFESSIONAL MAINTENANCE STRONGLY RECOMMENDED. To avoid product failure due to improper operation, please strictly follow the instructions below for safe use and maintenance. SAFE MAINTENANCE INSTRUCTIONS •... - Page 16 S C R E E N M A I N T E N A N C E • The maintenance of the product should be carried out by professionals. • Always wear ESD gloves when touching the LED modules and LED cabinet interior. •...
-
Page 17: Reference
R E F E R E N C E Technical Specifications LED Size 600mm×337.5mm×27.2mm Module Size 150mm×337.5mm Pixel Pitch 1.8mm Resolution 320*180 Brightness 600 nit PANEL Contrast ≥4000:1 Response ≤0. 1 Refresh Rate 3840 Viewing Angle 160°/140° Color Temperature (K) 3000K~10000K adjustable Viewable Area 0.2025 m²... - Page 18 Ethernet (RJ45) Wi-Fi INTERFACES Net Weight 192 lbs (87kg) Gross Weight 230.4 lbs (104kg) Unit Dimensions 96.4” x 48.72” x 2.5” STRUCTURE Package Weight 265lbs (120kg) Package Dimensions ≈ 59” x 29” x 41” Shell Material Die-cast aluminum Shell Color Black...
-
Page 19: Troubleshooting Guide
Professional maintenance strongly recommended! Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance. Call 844-221-3388 or email info@displays2go.com... -
Page 20: Names And Contents Of Toxic And Hazardous
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 21: Fcc Compliance Notice
FCC Compliance Notice Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
