32", 43", 55" Wall-Mounted
Touch Monitor - Android 11 OS
U S E R M A N U A L
SKU: DH043TLB
FCC ID: 2ASCB-DH043TLB
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
V1.1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Displays2go DH043TLB
Summary of Contents for Displays2go DH043TLB
- Page 1 U S E R M A N U A L SKU: DH043TLB V1.1 FCC ID: 2ASCB-DH043TLB This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F C O N T E N TS BEFORE USE Safety and Warnings Packing List Assembly OPERATION Power On/Off Parts Diagram Remote Control Settings Android Quick Start Guide DIVIEX Upload Media Playlist Settings REFERENCE Technical Specifications Cleaning and Maintenance Troubleshooting Guide Names and Contents of Toxic and Hazardous... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance digital signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 The technical specifications printed herein and on the packaging are subject to change without prior notice. The Manual may be slightly different from actual operation, and the latter is applicable. If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388.
-
Page 7: Packing List
Packing List Name Quantity HARDWARE PACKAGE Quantity Digital Signage Drywall Screws and Anchors Remote Control Washers Power Cord VESA Mounting Bracket User Manual Wi-Fi Antenna Assembly TOOLS NEEDED: Drill, bubble leveler, measuring tape. NOTE: Two people recommended for safe installation. NOTE: The hardware bag includes 4 additional slotted screws that are not needed for installation. -
Page 8: Operation
O P E R AT I O N Power On/Off • Start up by inserting the power cord into unit and connecting to outlet. Flip power switch to ON. • Power on or off the screen, press the power button on the remote control. •... - Page 9 43” MONITOR Speakers Remote Sensor Interface Panel I N T E R FAC E PA N E L WI-FI RJ45 TYPE-C TF CARD AUDIO USB 3.0 USB 2.0 ON/OFF POWER PORT (ETHERNET) SIM CARD 55” MONITOR Speakers Remote Sensor Interface Panel I N T E R FAC E PA N E L WI-FI RJ45...
-
Page 10: Remote Control
Remote Control To control the unit, aim the remote control directly at the remote sensor, located on the left side of the unit. The Remote Sensor indicator light on the monitor flashes when receiving a remote signal. For best performance, bring the remote control close to the sensor and avoid placing objects between the remote control and the sensor or exposing the sensor window to direct sunlight. -
Page 11: Settings 1
Settings Once turned on, the unit automatically displays the home screen, which includes the navigation bar and the App Drawer. NOTE: The navigation bar can be minimized by swiping down. To restore the navigation bar, swipe upward from the bottom of the screen. -
Page 12: Diviex
DiViEX The DiViEX Slideshow App comes pre-installed on this digital product for convenient content management. There are 2 methods for uploading media: saving media files to internal storage, or creating a specific folder on a USB, then inserting into unit. After, open the app to launch a slideshow or adjust picture settings, add filters and stickers, queue music and more! SUPPORTED FILE FORMATS AVI, MPEG, WMV, MKV, FLV, MP4, MOV, MPG, RA, RM, RMVB, DAT, ASF,... -
Page 13: Playlist Settings
PLAYLIST SETTINGS Edit the overall playlist settings in the Settings tab. Once settings are adjusted, click PLAY or adjust further in the Edit or Music tab. Enable or disable automatic settings. A. AUTOMATIC SETTINGS Auto-Boot: Automatically launch DiViEX when unit is powered on Auto-Play: Automatically play slideshow when DiViEX opens B. - Page 14 E D I T Tweak each photo individually in the Edit tab. A. PHOTOS Images/Video thumbnails in sequential order. Drag to rearrange. B. EDIT TOOLS Crop, Add Text, Add Filter, Add Sticker, Add Frame This white bar shows tool options for each of the Edit tools. Choose aspect ratios C.
-
Page 15: Reference
R E F E R E N C E Technical Specifications SPECIFICATION 32” 43” 55” PANEL LCD Size 32” 43” 55” Light Source LED backlight Resolution 1920 x 1080 1920 x 1080 3840 x 2160 Brightness 400cd/m Contrast 1200: 1 Response Pixel Pitch 0.63 (H) x 0.63 (V) mm... -
Page 16: Cleaning And Maintenance
SPECIFICATION 32” 43” 55” MP3, WMA, AC3, FLAC, APE, WAV, EAAC+, MP2 dec, Vorbis, BSAC, MPA, Supported Audio Files Speakers 2x 5W RTC (Real-Time Clock) Schedule Power On/Off System Update USB Compatible App Installation Support download and installation Bluetooth Frequency Signway Wi-Fi Generation Wi-Fi 6 (Compatible with Wi-Fi 5) -
Page 17: Troubleshooting Guide
Troubleshooting Guide ISSUE PROBABLE CAUSE SOLUTION • Check that the unit is plugged into wall outlet. • Unit not plugged into wall • Confirm that the power cord is connected to outlet the terminal on the back of the unit. •... - Page 18 • Check that file has successfully transferred to USB and USB APPS NOT is functioning. • App is defective WORKING • Contact Displays2go support. • Android board is defective NOTE: Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment.
-
Page 19: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 20: Fcc Compliance Notice
FCC Compliance Notice Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
