80" Floor
Standing dvLED
Poster - 2.5mm
Pixel Pitch
U S E R M A N U A L
SKU: DF080NVB2
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Display Stuff Better.
V2.1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Displays2go DF080NVB2
Summary of Contents for Displays2go DF080NVB2
- Page 1 Poster - 2.5mm Pixel Pitch U S E R M A N U A L SKU: DF080NVB2 V2.1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F C O N T E N TS Before Use Safety and Warnings Packing List Description of Parts Assembly Operation Power On/Off IP Address Connect Multiple Units Display Media with ViPlex Express Unit Connection Methods Reference Technical Specifications Cleaning and Maintenance... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance Digital Signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 CAUTION • Do not let children climb onto the Digital Signage. • Keep the small parts away from children to prevent them from swallowing. • If the Digital Signage won’t be used for a long time, please turn it off and pull out the power plug. •...
-
Page 7: Packing List
Wi-Fi Antenna Power Cable User Manual HDMI Cable Floor-Standing Base USB Drive Base Brackets Base Hardware Package Description of Parts If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388. -
Page 8: Assembly
Assembly NOTE: Three people required for safe assembly of product. Tools required: Phillips screwdriver. 1. Assemble the product on a level and clean surface. Cover the area with soft cloth to prevent any damage. 2. Attach 1 upright bracket to the base with 2 flathead screws and a Phillips screwdriver. Repeat for other bracket. 3. -
Page 9: Operation
O P E R AT I O N Power On/Off Power on by inserting the power cord into unit and connecting to outlet. Turn screen on with I/O switch. After a brief pause, the LED screen lights up and the IP address is active. Load the playlist to display content (see next page). NOTE : We recommend using a surge protector or power strip with internal circuit breaker to prevent potential damages to the product. -
Page 10: Display Media With Viplex Express
Click the Nova Cloud tab, then, scroll to ViPlex Express. Download and install either the ViPlex Express x32 or x64 software. You may also download the Studio Mode User Manual here or on the Displays2go product page for more details on how to operate the software. NOTE : Most modern computers are compatible with x64 software. - Page 11 Log Into ViPlex Express 1. Open ViPlex Express application after powering the LED poster on. The IP addresses of all units appear listed in the Screen Management tab. Choose an available unit from the list, then click Connect. 2. Enter the username and password then click OK. Initial Username: admin Initial Password: 123456 Create New Solution...
- Page 12 Publish Solution Publish your solution by clicking the green Publish icon. Once published, playlists can be shared to the unit via USB or network connection. Connect via PC Connect via Phone IP Address, Ethernet, or USB ViPlex Handy mobile app Create, edit, and publish playlists Display playlists only P U B L I S H V I A U S B...
-
Page 13: Unit Connection Methods
Unit Connection Methods C O N N E C T W I R E L E SS LY 1. Open Wi-Fi settings on your PC and find the unit IP address. The unit’s IP address is “P2.5-posterleddisplay-” followed by the product ID number, which can be found on the Wi-Fi information sticker. 2. -
Page 14: Reference
R E F E R E N C E Technical Specifications LED Size 80‘’ Light Source GOB LED Aspect Ratio 16:5.3 Light Source LED Diode Display Resolution 256 x 768 Brightness (cd/m 800 nits Contrast 6500:1 PANEL Response Pixel Pitch 2.5mm Refresh Rate 1,920 Hz... -
Page 15: Cleaning And Maintenance
Wi-Fi Frequency Dual-Band (2.4Ghz, 5Ghz) Bluetooth Wi-Fi Antenna Internal HDMI IN x1, OUT x1 PORTS 3.0 x1 Ethernet (LAN) Audio Net Weight 102lbs (46kg) IP Rating IP 30 STRUCTURE Unit Dimensions 80’’ x 2’’x 25’’ (203cm x 5cm x 64cm) Shell Material Steel/Aluminum Shell Color... -
Page 16: Troubleshooting Guide
Troubleshooting Guide NOTE: Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. Entire Screen Is Blank PROBABLE CAUSE • Abnormal electrical power supply of display • Display power not turned on •... - Page 17 Screen is Mostly Blank PROBABLE CAUSE • Poor connection of board power cable • Board input or output signal faulty SOLUTION • Use magnet tool to open display from the front. Check connection of power cable to board. Check signal input cable connection to board. If connections are intact, cables may be faulty.
- Page 18 Disordered or Repeating Images PROBABLE CAUSE • Setting error SOLUTION • Reload display configuration files. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance. 844-221-3388 info@displays2go.com...
-
Page 19: Names And Contents Of Toxic And Hazardous
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 20: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
