- Page 1 Deadlift/Lunge Model 718LD Owner’s Manual V 1.0 - 06.2023 www.tkostrength.com...
- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 3 Safety Read this owner’s manual carefully before assembling or using TKO equipment. WARNING: Serious injury could occur if these safety precautions are not observed Safety Precautions Before beginning any exercise program, consult your personal physician. Evaluate appropriate for your particular age and condition.
- Page 4 Product Diagram Maximum Weight Limit: 150 KG / 330 lbs.
- Page 5 Instructions Tools Required...
- Page 6 Exploded Diagram...
- Page 7 Parts List NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Mounting Frame End Cover φ76*10 Erection Aluminum Head φ25 Inclined Connecting Frame End Cap φ50*8 Left Arm Force Rack Aluminum Ring φ25 Right Arm Force Rack Aluminum Ring φ25 Connecting Frame End Cap φ60*φ12.5*10.6...
- Page 8 Measurement Guide...
- Page 9 Assembly Instruction...
- Page 10 Assembly STEP 1 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Mounting Frame Foam Bracket Erection Socket Head Cap Screw M12*30 Inclined Connecting Frame Flat Washer φ13*φ24*1.5 Limit Frame Note：Hand Tighten Bolts and Nylon Lock Nuts.
- Page 11 Assembly STEP 2 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Left Arm Force Rack Pull The Handle Right Arm Force Rack Socket Head Cap Screw M12*100 Connecting Frame Nylon Lock Nut M12 Left Connecting Rod Frame Flat Washer φ13*φ24*1.5 Note：Hand Tighten Bolts and Nylon Lock Nuts.
- Page 12 Assembly STEP 3 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Swing Tube Aluminum Ring φ25 Counterweight Frame End Cap φ60*φ12.5*10.6 Barbell Bar Cirelip Outer Sheath Socket Head Cap Screw M12*30 Inner Cushion Flat Head Cap Screw M12*35 Rubber Pad Flat Head Cap Screw M10*30 Leatherwear Foam Flat Washer φ13*φ24*1.5 Note：Hand Tighten Bolts and Nylon Lock Nuts.
- Page 13 Maintenance Schedule...
- Page 14 General Maintenance Information...
