- Page 1 Linear Leg Press Model 712LP Owner’s Manual V 1.0 - 06.2023 www.tkostrength.com...
- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 3 Safety Read this owner’s manual carefully before assembling or using TKO equipment. WARNING: Serious injury could occur if these safety precautions are not observed Safety Precautions Before beginning any exercise program, consult your personal physician. Evaluate appropriate for your particular age and condition.
-
Page 4: Product Diagram
Product Diagram Maximum Weight Limit: 200 KG / 440 lbs. - Page 5 Instructions Tools Required...
-
Page 6: Exploded Diagram
Exploded Diagram... -
Page 7: Parts List
Parts List NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED ITEM NO. ITEM NO. DESCRIPTION DESCRIPTION Shaft φ 25.4×131 Bottom Frame Left Stand Cirelip Right Stand Arm Force Pad Slide Frame Auxiliary Pad Middle Connection Frame Seat Pad Aluminum Ring φ 25 Upper Connecting Frame Aluminum head φ... -
Page 8: Measurement Guide
Measurement Guide... -
Page 9: Assembly Instruction
Assembly Instruction... - Page 10 Assembly STEP 1 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Bottom Frame Socket Head Cap Screw M12×30 Slide Frame Button Head Cap Screw M8×25 Middle Connection Frame Fl at Washer φ 13×φ 24×1.5 Guide Fl at Washer φ 9×φ 16×1.6 Roller Rack Note：Hand Tighten Bolts and Nylon Lock Nuts.
- Page 11 Assembly Assembly STEP 2 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Bottom Frame Rubber pad Left Stand Socket Head Cap Screw M16×90 Right Stand Socket Head Cap Screw M12×30 Middle Connection Frame Nylon Lock Nut M12 Upper Connecting Frame Fl at Washer φ 13×φ 24×1.5 Guide Fl at Washer φ...
- Page 12 Assembly STEP 3 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Roller Rack Sleeve Sliding Frame Cirelip Pedal Rack Socket Head Cap Screw M12×30 Short Connecting Frame Socket Head Cap Screw M10×70 Pedal Frame Nylon Lock Nut M10 Barbell Lever Fl at Washer φ 13×φ 24×1.5 Counterweight Pole Frame Fl at Washer φ...
- Page 13 Assembly STEP 4 DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. Bottom Frame Socket Head Cap Screw M12×130 Front Shelf Socket Head Cap Screw M12×30 Back Cushion Frame Socket Head Cap Screw M8×25 Swing Frame Fl at Washer φ 13×φ 24×1.5 Left Handle Rack Fl at Washer φ...
-
Page 14: Maintenance Schedule
Maintenance Schedule... -
Page 15: General Maintenance Information
General Maintenance Information...
