TKO 711SM Owner's Manual

Squat
Hide thumbs

Advertisement

Table of Contents

Squat
Model 711SM
Owner's Manual
V 1.0 - 06.2023
www.tkostrength.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 711SM and is the answer not in the manual?

Questions and answers

Related Manuals for TKO 711SM

Summary of Contents for TKO 711SM

  • Page 1 Squat Model 711SM Owner’s Manual V 1.0 - 06.2023 www.tkostrength.com...
  • Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 3 Safety Read this owner’s manual carefully before assembling or using TKO equipment. WARNING: Serious injury could occur if these safety precautions are not observed Safety Precautions Before beginning any exercise program, consult your personal physician. Evaluate appropriate for your particular age and condition.

  • Page 4: Product Diagram

    Product Diagram Maximum Weight Limit: 200 KG / 440 lbs.
  • Page 5 Instructions Tools Required...

  • Page 6: Exploded Diagram

    Exploded Diagram...

  • Page 7: Parts List

    Parts List NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED Item No. Description Item No. Description Bottom Cross Frame Assembly Shoulder Pad Frame Left Bottom Cross frame End Cap φ76 Rubber Foot Spacer Adjustable Stopper Flat Head Cap Screw M6×16 End Cap Socket Head Cap Screw M10×25 Cross Recess Head Screw M5×60...

  • Page 8: Measurement Guide

    Measurement Guide...

  • Page 9: Assembly Instruction

    Assembly Instruction...
  • Page 10 Assembly STEP 1 Item No. Description Item No. Description Bottom Cross Frame Assembly Nylon Lock Nut M12 Base Frame Assembly Flat Washer φ13×φ24×1.5 Foot Plate Assembly Flat Washer φ13×φ44×2 Socket Head Cap Screw M12×145 Note：Hand Tighten Bolts and Nylon Lock Nuts.
  • Page 11 Assembly STEP 2 Item No. Description Item No. Description Main Frame Limit Frame Assembly Limit Support Frame Assembly Socket Head Cap Screw M12×30 Arm Frame Assembly Flat Washer φ13×φ24×1.5 Note：Hand Tighten Bolts and Nylon Lock Nuts.
  • Page 12 Assembly STEP 3 Item No. Description Item No. Description Weight Horn Support Frame Assembly Rubber Sleeve Shoulder Pad Frame Assembly Left Snap Spring Shoulder Pad Frame Assembly Right Socket Head Cap Screw M12×100 Long Weight Horn Assembly Socket Head Cap Screw M12×30 Weight Horn Assembly Flat Head Cap Screw M12×35 Weight Horn End Cover...
  • Page 13 Assembly STEP 4 Item No. Description Item No. Description Shoulder Pad Flat Washer φ9×φ16×1.6 Soket Head Cap Screw M8×30 Note：Hand Tighten Bolts and Nylon Lock Nuts. 22 22...

  • Page 14: Maintenance Schedule

    Maintenance Schedule...

  • Page 15: General Maintenance Information

    General Maintenance Information...
