DIVAR IP all‑in‑one 7000 2U

DIP‑7380‑00N | DIP‑7384‑8HD | DIP‑7388‑8HD | DIP‑738C‑8HD

Installation manual

Need help?

Do you have a question about the DIVAR IP all-in-one 7000 2U and is the answer not in the manual?

Questions and answers

Summary of Contents for Bosch DIVAR IP all-in-one 7000 2U

Page 1 DIVAR IP all‑in‑one 7000 2U DIP‑7380‑00N | DIP‑7384‑8HD | DIP‑7388‑8HD | DIP‑738C‑8HD Installation manual...
Page 3 DIVAR IP all-in-one 7000 2U Table of contents | en Table of contents Safety Safety message explanation General safety precautions Electrical safety precautions ESD precautions Operating precautions Notices Cybersecurity precautions Compliance Software precautions 1.9.1 Use latest software 1.9.2 OSS information...
Page 4 | Table of contents DIVAR IP all-in-one 7000 2U 10.2 Removing power from the system 10.3 Removing the chassis cover 10.4 Identifying a faulty SSD drive 10.5 Installing a SSD hard drive into a rear drive bay 10.5.1 Removing a hard drive carrier from a rear hard drive bay 10.5.2...
Page 5 DIVAR IP all-in-one 7000 2U Safety | en Safety Observe the safety precautions in this chapter. Safety message explanation Warning! Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Caution! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Page 6 | Safety DIVAR IP all-in-one 7000 2U Warning! Interruption of mains supply: Voltage is applied as soon as the mains plug is inserted into the mains socket. However, for devices with a mains switch, the device is only ready for operation when the mains switch (ON/OFF) is in the ON position.
Page 7 DIVAR IP all-in-one 7000 2U Safety | en – Never spill liquid of any kind on the device. – Take precautions to protect the device from power and lightning surges. – Unless qualified, do not attempt to service a damaged device yourself. Refer all servicing to qualified service personnel.
Page 8 SELV circuits. – If safe operation of the unit cannot be ensured, remove it from service and secure it to prevent unauthorized operation. In such cases, have the unit checked by Bosch Security Systems. –...
Page 9 Notice! Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of losing information, we recommend multiple, redundant recording systems, and a procedure to back up all analog and digital information.
Page 10 | Safety DIVAR IP all-in-one 7000 2U Disposal Your Bosch product has been developed and manufactured using high-quality materials and components that can be reused. This symbol means that electronic and electrical devices that have reached the end of their working life must be disposed of separately from household waste.
Page 11 Limit local network access to trusted devices only. Details are described in the following documents which are available in the online product catalog: Network Authentication 802.1X – Cybersecurity guidebook for Bosch IP video products – – For access through public networks use only the secure (encrypted) communication channels .
Page 12 Bosch assumes no liability whatsoever for any damage caused by operating its products with outdated software components. You can find the latest software and available upgrade packages in the Bosch Security and Safety Systems download store under: https://downloadstore.boschsecurity.com/ 1.9.2 OSS information Bosch uses Open Source Software in the DIVAR IP all-in-one products.
Page 13 DIVAR IP all-in-one 7000 2U Safety | en You can find the licenses of the used Open Source Software components on the system drive under: C:\license txt\ The licenses of Open Source Software components used in any further software installed on...
Page 14 | About this manual DIVAR IP all-in-one 7000 2U About this manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the chassis. Installation and maintenance should be performed by experienced and qualified technicians only.
Page 15 DIVAR IP all-in-one 7000 2U System overview | en System overview Chassis components This chapter describes the most common components included with your chassis. For more information, see the installation instructions detailed later in this manual. Component Description Hard drives The chassis includes 8 hard drive bays for SATA hard drives.
Page 16 | System overview DIVAR IP all-in-one 7000 2U Front view: 2 USB 2.0 ports Power failure LED Information LED NIC1 and NIC2 LEDs HDD (drive activity) LED Power LED Reset button Power button Hard drive carrier LEDs Rear view: 10 11...
Page 17 DIVAR IP all-in-one 7000 2U System overview | en Control panel elements The control panel located on the front of the chassis features power buttons and status monitoring LEDs. Control panel buttons Button Description The power button is used to apply or remove power from the power supply to the system.
Page 18 | System overview DIVAR IP all-in-one 7000 2U Description This LED indicates activity on the HDDs or peripheral drives when flashing. This LED indicates that power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.
Page 19 DIVAR IP all-in-one 7000 2U Preparing for installation | en Preparing for installation Read this section in its entirety before you begin the installation. Choosing the installation location – Place the system near at least one grounded power outlet. –...
Page 20 | Preparing for installation DIVAR IP all-in-one 7000 2U – Always keep the rack’s front door and all panels and components on the system closed when not servicing to maintain proper cooling. Installation considerations Ambient operating temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room.
Page 21 DIVAR IP all-in-one 7000 2U Rack installation | en Rack installation This section provides information on installing the chassis into a rack unit. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. Also refer to the installation instructions that came with the rack unit you are using.
Page 22 | Rack installation DIVAR IP all-in-one 7000 2U Installing the inner rails on the chassis The chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack.
Page 23 DIVAR IP all-in-one 7000 2U Rack installation | en Locking Tabs Both chassis rails have a locking tab, which serves two functions. The first is to lock the system into place when installed and pushed fully into the rack, which is its normal position.
Page 24 | Rack installation DIVAR IP all-in-one 7000 2U Installing the chassis in a Telco type rack Notice! Do not use a two post "Telco" type rack. To install the chassis in a Telco type rack: Determine how far the chassis will extend out the front of the rack.
Page 25 DIVAR IP all-in-one 7000 2U Installing a SATA hard drive | en Installing a SATA hard drive The unit has hot-swappable hard drives, which can be removed without turning off the system. The hard drives are mounted in hard drive carriers to simplify their installation and removal from the chassis.
Page 26 SATA hard drive Notice! Bosch recommends using the respective Bosch hard disk drives. The hard disk drives as one of the critical component are carefully selected by Bosch based on available failure rates. Hard disk drives other then the delivered by Bosch are not supported.
Page 27 DIVAR IP all-in-one 7000 2U Installing a SATA hard drive | en Bosch Security Systems B.V. 2023-09 | V03 | DOC Installation manual...
Page 28 Plug the power cord from the power supply unit into a high-quality power strip that offers protection from electrical noise and power surges. Bosch recommends to use an uninterruptible power supply (UPS). Push the power button on the control panel to turn on the unit.
Page 29 DIVAR IP all-in-one 7000 2U System setup | en System setup The DIVAR IP all-in-one 7000 systems are based on the operating system Microsoft Windows Server IoT 2019 for Storage Standard. The operating system provides an user interface for initial server configuration, unified storage appliance management, simplified setup and storage management, and support for Microsoft iSCSI Software Target.
Page 30 | System setup DIVAR IP all-in-one 7000 2U – iSCSI storage expansion for a BVMS system, which runs on a different hardware. Notice! Recorded video streams need to be configured in a way that the maximum bandwidth of the system (BVMS /VRM base system plus iSCSI storage expansions) is not exceeded.
Page 31 DIVAR IP all-in-one 7000 2U System setup | en The system automatically scans the local drive and any connected external storage media for the installation file BoschAppliance_Setup_DSC_[software version].exe, which is located in a folder with the following structure: Drive root\BoschAppliance\. The scan might take some time.
Page 32 Before operating the device for the first time, make sure that you install the latest applicable release of your software version. You can find the latest software and available upgrade packages in the Bosch Security and Safety Systems download store under: https:// downloadstore.boschsecurity.com/.
Page 33 DIVAR IP all-in-one 7000 2U System setup | en Notice! For further details, refer to the VRM documentation. Choosing operation mode iSCSI storage To operate the DIVAR IP all-in-one system as an iSCSI storage expansion: On the DIVAR IP - System setup page, select the operation mode iSCSI storage and the desired iSCSI storage version that you want to install, then click Next.
Page 34 | System setup DIVAR IP all-in-one 7000 2U Enter user name and password, and then click Login. – User name: BVRAdmin – Password: as it was set during the initial operating system setup process In the MegaRAID Storage Manager main window, click the tab Physical.
Page 35 The initial password is unique for each unit. You can find it on the label at the rear of the unit, below the IPMI port. Bosch strongly recommends to change the initial password during the IPMI configuration, and to store the new password at a secure location.
Page 36 | Troubleshooting DIVAR IP all-in-one 7000 2U Troubleshooting Overheating Problem Solution An overheating condition has occurred. – Make sure that no cables obstruct the airflow in the system. – Make sure that all fans are present and The system status LED is continuously operating normally.
Page 37 DIVAR IP all-in-one 7000 2U Maintenance | en Maintenance This chapter covers the steps required to install components and perform maintenance on the chassis. Notice! Installation should only be carried out by qualified customer service personnel in accordance with the applicable electrical regulations.
Page 38 | Maintenance DIVAR IP all-in-one 7000 2U Fixing screws Release tabs Chassis cover To remove the chassis cover: Disconnect the power supply, lay the chassis on a flat surface. Remove the two screws on each side of the cover, which secure the cover to the chassis.
Page 39 DIVAR IP all-in-one 7000 2U Maintenance | en 10.5 Installing a SSD hard drive into a rear drive bay The unit features two hot-swappable hard drives on the rear side which can be removed without powering down the system. The hard drives are mounted in hard drive carriers to simplify their installation and removal from the chassis.
Page 40 DIVAR IP all-in-one 7000 2U Notice! Bosch recommends using the respective Bosch hard disk drives. The hard disk drives as one of the critical component are carefully selected by Bosch based on available failure rates. Hard disk drives other then the delivered by Bosch are not supported.
Page 41 DIVAR IP all-in-one 7000 2U Maintenance | en DVD-ROM Front port panel To replace the DVD-ROM drive: Turn off the unit and if necessary, remove the unit from the rack. Remove the chassis cover. Unplug the drives power and data cables from the motherboard and/or backplane.
Page 42 | Maintenance DIVAR IP all-in-one 7000 2U 10.9 Installing the air shroud The air shroud does not require screws for its installation. Notice! If a 16 DIMM (13.68" x 13") motherboard is used, it is necessary to use the optional MCP-310-82502-0N air shroud.
Page 43 DIVAR IP all-in-one 7000 2U Maintenance | en To replace a system fan: If necessary, open the chassis while the power is running to determine which fan has failed. Note: Never run the system for an extended period of time with the chassis open.
Page 44 The power supply can be replaced without turning off the system if a redundant power supply is available. Replacement units can be ordered directly from Bosch RMA desk. To replace the power supply: Unplug the AC power cord of the failed power supply.
Page 45 The storage equipment is shipped with an original manufacturer Service and Support agreement. The Bosch Technical Support is the Single Point of Contact in case of failure but the Service and Support obligations are fulfilled by the manufacturer or a partner.
Page 46 For more information, software downloads, and documentation, go to the respective product page in the product catalog: http://www.boschsecurity.com You can find the latest software and available upgrade packages in the Bosch Security and Safety Systems download store under: https://downloadstore.boschsecurity.com/ 11.2...
Page 48 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2023 Building solutions for a better life. 202309021212...
