Emergency Stop Control
Control de Parada de Emergencia
Controle de Parada de Emergência
CPW22
Installation, Configuration and Operation Guide
Guía de Instalación, Configuración y Operación
Guia de Instalação, Configuração e Operação
English / Español / Português
15308927
Advertisement
Table of Contents
Related Manuals for WEG CPW22
Summary of Contents for WEG CPW22
- Page 1 Motors | Automation | Energy | Transmission & Distribution | Coatings Emergency Stop Control Control de Parada de Emergencia Controle de Parada de Emergência CPW22 Installation, Configuration and Operation Guide Guía de Instalación, Configuración y Operación Guia de Instalação, Configuração e Operação English / Español / Português...
-
Page 2: Safety Instructions
The CPW22 is a safety switching device for emergency stop control, with three mechanically guided relay outputs, which can quickly and safely stop the moving parts of a machine or system in the event of danger. Applications for the CPW22 include single or double channel emergency stop circuits, with continuous monitoring and with manual or automatic start. -
Page 3: Specifications
Weight ± 0.180 Kg Fixation 35 mm DIN rail 7 MOUNTING The CPW22 is intended for installation in control cabinets with a minimum degree of protection of IP54, mounted on a 35 mm DIN rail. According to Figure A.7. NOTE! -
Page 4: Appendix A - Figures
OSSD 2 OSSD 1 OSSD 2 OSSD 1 K2** K2** 13 23 33 41 13 23 33 41 CPW22 CPW22 14 24 34 14 24 34 24 V 24 V Figure A.2: Dual channel OSSD input device with manual start (*automatic start jumper S12 Figure A.2: Dual channel OSSD input device with manual start (*automatic start jumper S12... - Page 5 Monitored manual start Automatic start Arranque manual monitoreado Arranque automático Disparo manual monitorado Disparo automático Figure A.5: Start configuration Figura A.5: Configuración de arranque Figura A.5: Configuração de disparo Monitored feedback with Monitored feedback with manual start automatic start Realimentación monitoreada Realimentación monitoreada con arranque manual con arranque automático...
