  • Page 1 Instruction Manual truction Manual Instruction Manual Instruction Manual IDM19 Pocket Digital Multimeter M19 Pocket Digital Multimeter IDM19 Pocket Digital Multimeter IDM19 Pocket Digital Multimeter RANGE HOLD RANGE HOLD Ω Ω DC/AC DC/AC Ω Ω VOLT VOLT AUTO POWER OFF AUTO POWER OFF...

  • Page 2: Safety Information

    SAFETY INFORMATION Read and understand this Instruction Manual completely before using this instrument. Failure to observe the warnings and cautions in this Instruction Manual may result in injury or death, or damage to the instrument and other equipment or property. If this instrument is used in a manner not specified in these instructions, the protection provided by the instrument may be impaired.

  • Page 3: Operation

    the finger guards on the probes. • Wear suitable Personal Protective Equipment when working around or near Hazardous Live conductors which could be accessible. • Disconnect the circuit power and discharge all high- voltage capacitors before making resistance, continuity, or diode measurements. •...
  • Page 4 each range in sequence from the lowest to highest range. Hold the button for 2 seconds to return to the Autorange Mode. Data-hold Feature Press the [HOLD] button to toggle the Data-hold mode on and off. In the data-hold mode, the "H" symbol appears on the LCD, the display freezes and the last reading is held on the display.
  • Page 5 ohms/continuity mode. The symbols will appear on the LCD. 3. Touch the probes to the test points in the circuit. The value indicated on the LCD is the measured value of resistance in Ohms, with true decimal point and annunciator indications (KOhms or MOhms).

  • Page 6: Specifications

    position to turn the instrument on. The auto power off position to turn the instrument on. The auto power off feature is now disabled. When the instrument is next feature is now disabled. When the instrument is next turned off, the auto Power-off is reset to on. turned off, the auto Power-off is reset to on.
  • Page 7 Range Resolution ACCURACY Input Impedance Overload Protection 100M Ω Ω Ω Ω 340mV 100µV ± 2.0% rdg + 2 dgts 10M Ω Ω Ω Ω 3.4V ± 1.0% rdg + 2 dgts 10mV 9.1M Ω Ω Ω Ω 340V 100mV ±...

  • Page 8: Maintenance

    MAINTENANCE Cleaning the instrument. Periodically wipe the case with a damp cloth and detergent. Do not use abrasives or solvents. Battery replacement When the " " symbol appears on the LCD display, replace the batteries. WARNING Disconnect the test probes from the circuit before removing the battery cover.
