- Page 1 Powerwall Battery User Manual Product Name: 2.6/5/7/8/9/10/14/15kwh Powerwall Battery Model B-LFP48-52/100/156/174/200/280/300PW Version V2.7...
-
Page 2: Table Of Contents
Content 1. Safety Precautions ...........................1 1.1 Note Before Installation ......................1 1.2 During Operation ........................2 2. System Application Introduction ....................2 2.1 PV Self-use Surplus Power to Grid ..................2 2.2 Peak Shaving and Valley Filling ...................2 2.3 Standby Power Supply ......................3 3. -
Page 3: Safety Precautions
1.Safety Precautions It is very important and necessary to read the user manual carefully before installing or using the battery. Failure to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, or may damage the battery and the whole system. -
Page 4: During Operation
battery in series; It is prohibited to connect the battery with different type of battery; Please ensure the electrical parameters of battery system are compatible to inverter; Keep the battery away from fire or water. 1.2 During Operation If the battery system needs to be moved or repaired, the power must be cut off first and the battery is completely shutdown;... -
Page 5: Standby Power Supply
energy expenditure. 2.3 Standby Power Supply In some extreme weather (such as tornadoes, typhoons, hail), or substation operation failure, power supply will be interrupted. If the energy storage system is installed, the user can still enjoy sufficient power guarantee under this situation. Figure1．... -
Page 6: Product Specification
3.Product Specification Item General Parameter 51.2V Nominal Voltage Rated Capacity(Ah)(typical) 51.2V Cell Model（LFP-3.2V） 52Ah 100Ah 52Ah 86Ah 100Ah 280Ah 100Ah 16S2P 16S2P 16S1P 16S3P Pack configuration 16S1P 16S1P 16S3P Rate power(Wh) 2,662 5120 7987 8806 10240 14336 15360 Charging Voltage 54/54.6V 54.5V Float charge Voltage... -
Page 7: Battery Drawing
4.Battery Drawing 51.2V 100Ah 51.2V 200Ah 51.2V 174Ah Product size :540*490*147mm Product size :820*490*147mm Product size :780*490*147mm 51.2V 200Ah 51.2V 280Ah 51.2V 300Ah Product size :820*490*147mm Product size :800*392*235mm Product size :950*600*190mm... -
Page 8: Interface Description
4.1.Interface Description Figure2．Interface Definition Description Table1.Battery Pack Frontpanel Port Definition Illustration Silk-screen Remark Battery positive post positive output Battery negative post negative output Reset button RESET Reset battery Dial switch Address setting, range 2~15 pin3 to pin4 often open, closed with low power alarm Dry connection Pin1 to pin2 often open, closed when... -
Page 9: Led Display Definition
Running indicator light After startup, the LED blinks green Alarm indicator light The fault is displayed in red Capacity indicator light Refer to Table 2 Breaker ON/OFF Battery string output is enabled 4.2 LED Display Definition Definition Specification Criteria POWER Light System no abnormal, always bright RUN Light See Table 2, Table 4... - Page 10 Discharge Undervoltage Stop discharging protection Temperature, overcurrent, top discharging short circuit, reverse connection, failure protection Invalid Stop charge/discharging Normal Table 3 Description of capacity indicators Status Charge Discharge Capacity indicator ● ● ● ● ● ● ● ● ● ● ●...
-
Page 11: Battery Connection And Communication Instructions
4.3 Battery Connection and Communication Instructions RS485：With a dual RS485 interface to check PACK information, with a default baud rate of 9600bps. To communicate with the monitoring equipment through the RS485, the monitoring equipment as the host, according to the address polling data, address setting range of 2~15. - Page 12 Set as subordinate Pack19 Set as subordinate Pack20 Set as subordinate Pack21 Set as subordinate Pack22 Set as subordinate Pack23 Set as subordinate Pack24 Set as subordinate Pack25 Set as subordinate Pack26 Set as subordinate Pack27 Set as subordinate Pack28 Set as subordinate Pack29 Set as subordinate Pack30 Set as subordinate Pack31...
-
Page 13: Interface Diagram
Set as subordinate Pack62 Set as subordinate Pack63 Note: large parallel groups (> 3000A current limit) The CAN bus hexadecimal message format used by the Victron GX controller cannot accept charge current limits (CCL) and discharge current limits (DCL) greater than 3000. -
Page 14: Display Rendering
RS485B-8P8C RS485B-8P8C RJ45 RJ45 RS485-B 9,16 RS485- Parallel RS485-A 10,15 RS485- communication 11,14 12,13 RS485A port CAN port RJ45 RJ45 External RS485-B1 1,2,3,6,8 communication RS485-A1 CAN-L CAN-H RS232 RJ11 RJ11 RJ11 Communication with host computer 4.5 Display rendering Main menu page After BMS is activated, will show the welcome screen, press the “MENU”... - Page 15 in the figure below： Protocol selection function （You can switch protocols through the display screen to quickly match inverters of different brands） When the cursor “》 ” is point to” Battery Status” ，press “ENTER” key will enter the page of “Battery Status”，As shown in the figure below：...
-
Page 16: Battery Installation Instructions
Parameter Settings Screen can not set parameters Baud Rate：9600 ,Can not be set. Key description SW1----MENU，SW2----ENTER，SW3----DOWN， SW4----ESC. Each item is “》”or“--”as a beginning，among them“》”shows the current cursor position，press “DOWN” key can move the cursor position；with“》”end of the project， the content of the said project has not shown, press“ENTER”key can enter the corresponding page. -
Page 17: Installation Tools
ambient temperature is outside the operating range, battery will protect itself by shutting down. The battery optimal operate temperature is 25°C to 55°C. Frequent exposure to severe operating condition would exacerbate the performance and lifetime of the battery. 5.2 Installation Tools To install the battery pack, those following tools are probably required: Space requirements: Observe the minimum clearance of the walls, other batteries or objects shown in the figure below to ensure adequate heat dissipation. -
Page 18: Installing Battery Strings In Parallel
Underside Side Front Step 1: install the wall mounted bracket to the wall; Place the bracket on the wall, mark the position of the six holes and remove it; Drill holes with a hole depth above 60mm to ensure sufficient strength to support the battery pack;... - Page 19 5.3.2 2pack---1 Inverter. Pack 1 is slave ; pack 2 is master;Negative and Positive power cable has the same length. 5.5.3 3pack---1 Inverter. Pack 1 ,2 is slave ; pack 3 is master.more pack are parallel,one pack is master,other are slave.Negative and Positive power cable has the same.
-
Page 20: Appendix1
Note: when a single unit is used, the inverter uses the battery as the main machine to communicate; when multiple batteries are used in parallel, the batteries inside are connected in parallel through the RS485B hardware interface, RS485A/CANBUS communicates with the inverter. 6.Appendix1 When the equipment manufacturer confirms that it is necessary, it can authorize to provide the customer with the host software and operating instructions. -
Page 21: Appendix2
Figure 8 7.Appendix2 Multi Inverter protocol support. Default setting: CANBUS - Victron, RS485-DEYE. Protocol NO Type Inverter Pylon PYLON CAN LV V1.3-2019.03.01 DEYE/Sun PYLON CAN LV V1.3-2019.03.01 synk Growatt CAN LV Growatt V1.09-2020.10.22 Victron Victron CAN 2021.01.07 Luxpowertek CAN Luxpower V1.0-2020.02.11 SMA CAN V2.0 GoodWe CAN Inverter LV... - Page 22 Studer STUDER CAN V1.02-2018.06.14 Sofar SofarSolar CAN inverter V6 Ginlong/ GINLONG CAN LV V1.0-2019.12.28 Solis TBB CAN V1.05-2021.04.20 TBB_LITH TBB CAN V1.1-2021.10.21 Daneng DANENG CAN V10-2022.10.10 Aiswei AISWEI CAN V1.0 SAJ CAN V1.9-2022.06.30 MUST MUST CAN V2.0.2-2021.06.02 Megarevo PYLON CAN LV V1.3-2019.03.01 PYLON RS485 LV-BPB Pylon V3.5-2019.08.07...
- Page 23 Remark： - Please ask your sales team to provide password for host computer software administration enter. - Different inverters the pin assignment are not the same, please contact inverter supplier for detailed RJ45 cables of pin assignment. Connector pin configurations for the above-mentioned inverter manufacturers are listed below:...
-
Page 25: Appendix3
8.Appendix3 Abnormal Situation Addressing 1.What if the battery pack does not work properly after power on? A: The most direct way is to connect to the upper computer, through the upper computer to find the fault phenomenon, causes can be roughly analyzed from the upper computer interface prompt alarm, protection, fault and other information, it can also provide necessary reference for further testing. - Page 26 2) Confirm that the host computer software selects correct COM port (view device manager); 3) Confirm whether the RS232 communication line is fully inserted into the corresponding communication interface of the battery pack. 3.Under what circumstances will RS485 fail to paralleling batteries communication? A: The possibility of failure of parallel batteries communication is as follows: first ensure whether the parallel RS485 communication port has been connected, and then make sure that the address dialing position of the battery pack is correct, and make sure that the RS485 terminal Plug-in in...
- Page 27 quality problems within the specified operation range; we may replace the relevant parts, if we fail to maintain it, so as to achieve the purpose of sustainable use without performance reduction; our after-sales service personnel will propose the specific maintenance and troubleshooting methods. In case of any questions, please contact us.
