  • Page 1 PowerLine-5 Wall Mounted LFP Energy Storage Battery System OPERATING INSTRUCTION BSL NEW ENERGY TECHNOLOGY CO., LTD...
  • Page 2: Table Of Contents

    CONTENTS NOTICE ....................................3 1 Summary ..................................... 4 1.1 Main Characteristic ............................4 1.2 Operating Environment ..........................4 1.3 Main Technical Specification ......................... 5 2 Description of Product ..............................5 2.1 Appearance ................................. 5 2.2 The Sketch Map and Introduction of The Panel .................. 6 3 Operating Principle of The System .........................
  • Page 3: Notice

    NOTICE The purchased products, services and features are stipulated by the contract made between BSL   NEW ENERGY TECHNOLOGY CO., LTD and the customer. All or part of the products, services and   features described in this document may not be within the purchase scope or the usage scope. Unless  ...
  • Page 4: Summary

    1 Summary The integrated LFP battery pack PowerLine 5 is a household energy storage battery system developed by BSL NEW ENERGY TECHNOLOGY CO., LTD, which is characterized by ultra-thin, light weight, self maintenance and management, convenience, energy efficiency and environmental protection, and maximum support for 16 groups of parallel use;...
  • Page 5: Main Technical Specification

    1.3 Main Technical Specification Table1-1 Main Technical Specification Item Specification Remarks Nominal Capacity 100Ah Nominal Voltage 51.2V Limited Charge Voltage 58.4V Final Discharge Voltage 42.4V Maximum Charge Current 100A Recommended Continuous Charging Current Maximum Continuous Discharge 100A Current Dimensions (W * H * D) 670*540*90mm Installation Method Wall Mounted...
  • Page 6: The Sketch Map And Introduction Of The Panel

    2.2 The Sketch Map and Introduction of The Panel ⑪ ⑫ ⑬ ① ② ④ ⑤ ⑥ ⑧ ③ ⑦ ⑨ ⑩ Introduction of The Panel ①Handle ②Positive ③RS485 ④RS232 ⑤CAN/485 of inverter ⑥Dry contact ⑦Dial switch ⑧Reset ⑨Negative ⑩GND ⑪SOC ⑫Warning ⑬Run...
  • Page 7 2.2.3 RS485 Communication It has two RS485 interfaces. The two interfaces form an independent serial port, which is a serial port physically. The definition of the interface is shown in Figure 2-3.By setting different dialing addresses for multiple battery packs, it can realize cascade communication , as shown in Figure 2-4. Figure 2-3 RS485 Definition of communication interface RS485 Pin definition Signal...
  • Page 8 2.2.4 Dialing Addresse The dialing adopts BCD code format, the dial up is ON and the dial down is OFF. Four bits are used as the address settings. The dial 1 is low, Dial 4 is high, as shown in Figure 2-5. When it is in the stand-alone operation mode, all dial addresses are OFF;...
  • Page 9 Table2-2 LED Fleshing mode Normal/ Power indicator LED Description Status Alarm/Pr otection ● ● ● ● ● ● ● ● ● Power- Dormant Normal Flesh1 Stand State Standb Indicating according quantity of electricity Alarm Flesh1 Flesh3 Under voltage Maximum indication Normal Indicating according quantity of LED Flesh(Flesh2),...
  • Page 10: Operating Principle Of The System

    Table2-4 Description of capacity indication Status Charging Discharging Indication of capacity L5● L4● L3● L2● L1● L5● L4● L3● L2● L1● 0~20% 闪 2 20~40% 闪 2 Capacity 40~60% 闪 2 (%) 60~80% 闪 2 80~100% 闪 2 LED● Flesh(Flesh 3) 3 Operating Principle of The System The working principle of the system is as shown in the figure below.
  • Page 11: Installation Preparation

    (3)Personal safety: a、Insulated tools and gloves shall be used during installation, and all conductors containing metal materials should be strictly prohibited from contacting the battery pack. b、Avoid falling and collision of battery pack during installation. c、Except for the maintenance engineers who have received professional training, it is prohibited to remove the battery components for battery maintenance.
  • Page 12: Installation Instructions

    Table4-1 List of tools for installation (recommended tools, provided by the customer) Tool Specification Remark Insert with M6/M8 Electric screwdriver Test Wrench Torque wrench Positive and negative Wrench pole wires, terminals Positive and negative Sleeve pole wires, terminals Lock the lid lock cross screwdriver Cut tie Diagonal pliers...
  • Page 13: Maintenance

    Figure 4-1 Parallel installation diagram 4-2 installation diagram M6 Expansion bolt Fixing bracket ② ③ ① Figure 4-2 installation diagram Installation Installation Instructions sequence Prepare support, expansion bolt, wall mounted ① battery and impact drill Place the support against the wall, make hole ②...
  • Page 14 5 Maintenance 5.1 Routine Maintenance The battery pack shall be watched by professionals during charging,meanwhile ensure that the (1) plug and socket are in good contact, the charging equipment works normally, and all connection points of the battery pack are in good contact. In case of abnormality, power off immediately and charge only after repair;...
  • Page 15: Regular Mantenance

    SOC information are normal and record them 5.2 Regular maintenance (1)Check the voltage data of the BMS upper computer and the actual battery voltage value to ensure the accuracy of the BMS voltage collection. If they are inconsistent, they should be calibrated. The error between the collected voltage and the actual battery voltage should not exceed 5mV (once a month);...
  • Page 16: Trouble Shooting

    From the second year, the on-site capacity will be determined every three months. If the historical alarm information is displayed through RS485 Frequent overcharge and overdischarge of a certain electric core indicates that the electric core has touched the charging protection point and discharge protection point for a long time.
  • Page 17: Packing、Shipping、Storage

    Packing、Shipping、Storage ( 1)The battery pack shall be packaged as a whole to ensure that the product is free from any harmful gas, chemical pollution, moisture and mechanical damage during handling, transportation and storage; The packing box has been marked with: product name, model and specification, date of manufacture, quantity, batch number, etc (2)...
