Lithium Iron Phosphate Battery (LiFePO4)
DANGER
FIRST TO USE, READ AND UNDERSTAND PRODUCT SAFETY INFORMATION.
IMPORTANT: PLEASE READ BEFORE FIRST USE
Failure to follow the instructions may result in ELECTRICAL SHOCK, EXPLOSION, or FIRE, which may result in
SERIOUS INJURY, DEATH, DAMAGE TO DEVICE or PROPERTY. Do not discard this information.
Tel:+86-752-2819469
Lithium Battery User Manual
Email:info@bsl-battery.com
WISDOM INDUSTRIAL POWER Co.,LTD
www.lithium-battery-factory.com
- 1 -
Advertisement
Related Manuals for BSLBATT B-LFP12-100
Summary of Contents for BSLBATT B-LFP12-100
- Page 1 WISDOM INDUSTRIAL POWER Co.,LTD Lithium Battery User Manual Lithium Iron Phosphate Battery (LiFePO4) DANGER FIRST TO USE, READ AND UNDERSTAND PRODUCT SAFETY INFORMATION. IMPORTANT: PLEASE READ BEFORE FIRST USE Failure to follow the instructions may result in ELECTRICAL SHOCK, EXPLOSION, or FIRE, which may result in SERIOUS INJURY, DEATH, DAMAGE TO DEVICE or PROPERTY.
- Page 2 Connecting up your BSLBATT battery When connecting to the BSLBATT using the nuts and washers provided. Please connect the Positive (+) connection first before connecting the Negative (-) connection. Disconnections is the reverse process, Negative (-) first, Positive (+) last.
- Page 3 WISDOM INDUSTRIAL POWER Co.,LTD Battery basic informations: 项目 常用参数 备注 序号 Item General Parameter Remark 型号 B-LFP12-100 12.8V100AH B-LFP12-75 12.8V75AH （Model） 单体电池外壳材质 Prismatic LiFEPo4 cell Casing material for cell type 标称容量（0.2C A） 100Ah 75Ah Standard capacity（0.2C A） 额定电压 工作电压：3.20V 12.8V 12.8V...
- Page 4 (Recommend 0℃～45℃) Storage BMS (Battery management system): BSLBATT Lithium batteries are all equipped with an internal or external Battery Management System, which protect against the following potential damaging situations: Charging Lithium Battery Informations: To make sure your BSLBATT LiFePo4 batteries proving maximum use/service life, please follow below charge instructions.
- Page 5 * Charge current must be reduced at temperatures ≥0°C. See details in Charge Temperature section. ** For optimum life, charge at recommended rate. Some models are specially designed to allow for higher current, please contact BSLBATT Team if need any other support.
-
Page 6: Bluetooth Function
How to storage Lithium battery? BSLBATT battery has an extremely low rate of self-discharge but if you intend not to use the battery for an extended period of time please fully charge it prior to storage. It is recommended to re-charge the BSLBATT battery once every 6 months. -
Page 7: Warranty Claims
WISDOM INDUSTRIAL POWER Co.,LTD A BSLBATT battery is supplied with 3-5 years limited warranty from the date of purchase (please keep your proof of purchase) or 2000 battery cycles, whichever comes first. Note a full battery cycle is determined by a fully discharged BSLBATT (down to 10% of its gross capacity) and charged to 100%. - Page 8 ★ degrees C). ★ Avoid using BSLBATT in damp or wet conditions but if you do need to use it in these conditions consider using and all-weather enclosure (not included in package). ★ Observe the correct polarity otherwise permanent damage could be caused - the battery casing is marked with + and -.
- Page 9 This means that these batteries may not be disposed of with household waste. Disposal of a used or damaged BSLBATT battery must be done at a certified recycling location. There are many of these nationwide - please contact us for help if necessary.
-
Page 10: Battery Test
WISDOM INDUSTRIAL POWER Co.,LTD Battery Test Battery Safety Test 1- Test Conditions Temperature: 20±5℃ Relative Humidity(RH): 45% ~75% Atmosphere Pressure: 86kPa ~106kPa All tests are based on UL1973-2013 and IEC62619:2017. 2-Tests Item Description Non-compliant Test Result Overcharge Test E, F, C, V, S, L, R, P Pass Short Circuit Test E, F, C, V, S, L, R, P...
