- Page 1 UPS Energy Storage Battery User Manual Product Name: 256V 25.6kWh / 512V 51.2kWh battery Model H V P A C K 2 5 6 / 5 1 2 V Version V1.0...
-
Page 2: Table Of Contents
Content 1. Safety Precautions ..............................1 1.1 Note Before Installation ..........................1 1.2 During Operation............................2 2. System Application Introduction .......................... 2 2.1 PV Self-use Surplus Power to Grid ......................2 2.2 Peak Shaving and Valley Filling ......................... 2 2.3 Standby Power Supply ..........................2 3. -
Page 3: Safety Precautions
1.Safety Precautions It is very important and necessary to read the user manual carefully before installing or using the battery. Failure to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, or may damage the battery and the whole system. -
Page 4: During Operation
1.2 During Operation If the system needs to be moved or repaired, the power must be cut off first and the battery is completely shut down; It is prohibited to connect the system with different type of battery. In case of fire, only dry powder fire extinguisher can be used, liquid fire extinguishers are prohibited. -
Page 5: Product Specification
3.Product Specification UPS B23 UPS B51 General Parameter 256V Nominal Voltage 512.5 512V Rated Capacity (Ah) 512V Cell Brand (LFP-3.2V) EVE100AH EVE100AH System configuration 160S1 80S1P 160S1P Battery single box number 160S1P Rate power 51.2kW 25.6kWh Charge Cut-off Voltage 278.4V 556.8 Discharge Cut-off Voltage 216V... -
Page 6: Battery Drawing
4.Battery Drawing UPS B23 UPS B51 Product size :476*660*1110mm Product size :476*660*1855mm 5.System Installation Instructions 5.1 Installation location Make sure that the installation location meets the following conditions: The building is designed to withstand earthquakes. Far away from the sea to avoid salt water and humidity. ... -
Page 7: Installation Tools
Temperature and humidity stay at a constant level. Minimal dust and dirt in the area. No corrosive gases present, including ammonia and acid vapor. Battery are IPX4 waterproof, so the system could be installed indoor. If the ambient temperature is outside the operating range, battery will protect itself by shutting down. -
Page 8: Installation Steps
5.3Installation steps Step 1: When receiving the product, first check whether all parts are complete, if not, please report to the Dealer. Step 2: Choose a suitable installation location and require the system pack to be placed at a safe. Step 3: Turn clockwise the DC circuit breaker. -
Page 9: Appendix2
7.Appendix2 Abnormal Situation Addressing 1. What if the system does not work properly after power on? A: The most direct way is to check the LCD Displaying of the inverter, through the LCD Displaying to find the fault phenomenon, causes can be roughly analyzed from the LCD Displaying interface prompt alarm, protection, fault, and other information, it can also provide necessary reference for further testing. - Page 10 We will not be liable for the accidents resulting from operation breaking this specification and user manual. We will not send separate notice, provided that the contents of this specification are changed due to improvement of product quality or technological upgrading, provided that you want to understand the latest information of this product, please contact us.
