Installation Instructions
Original Instructions
FLEX 5000 Analog 8-channel RTD/Thermocouple Safety Input Modules
Catalog Numbers 5094-IRT8S, 5094-IRT8SXT
Topic
Summary of Changes
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Updated template
Updated trademarks
Updated UK and European Hazardous Location Approval
Updated IEC Hazardous Location Approval
Updated Special Conditions for Safe Use
Updated Module Specifications
Product Overview
The 5094-IRT8S and 5094-IRT8SXT analog 8-channel RTD/Thermocouple safety input modules offer differential, thermocouple, and RTD input channels (four isolated groups of two
non-isolated) that can operate in a wide range of applications. The modules can operate in multiple-input ranges based on the input type that is connected to the modules.
FLEX 5000® I/O modules use the Producer/Consumer communication model. The Producer/Consumer communication model is an intelligent data exchange between modules and
other system devices in which each module produces data without first being polled.
The 5094-IRT8S and 5094-IRT8SXT modules can be used with GuardLogix® 5580 and Compact GuardLogix 5380 safety controllers in applications up to SIL 3, PLe, Cat. 4. The
modules are configured with the Studio 5000 Logix Designer® application.
These safety modules are type-approved and certified for use in safety applications up to and including SIL 3 per IEC 61508, suitable for use in safety applications up to and
including SIL Class 3 per IEC 62061, and up to and including Performance Level PLe (Category 4) per ISO 13849-1.
For more information about which Logix 5000® controllers and Logix Designer application versions are compatible with FLEX 5000 I/O modules, and for safety application
requirements, see the publications that are listed in
Page
4
4
5
6
6
7
8
8
10
10
10
11
11
Additional Resources on page
11.
Page
throughout
1
3
3
3
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Allen-Bradley FLEX 5000 5094-IRT8S and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockwell Automation Allen-Bradley FLEX 5000 5094-IRT8S

  • Page 1: Table Of Contents

    Installation Instructions Original Instructions FLEX 5000 Analog 8-channel RTD/Thermocouple Safety Input Modules Catalog Numbers 5094-IRT8S, 5094-IRT8SXT Topic Page About the Module Install a FLEX 5000 I/O System Required Components Install the Module Install the End Cap Wire the Terminal Base Disconnect Wires from the Terminal Base Wiring Diagrams Power the System...
