UG187: BGM113 Blue Gecko Module
Wireless Starter Kit User's Guide
A Wireless Starter Kit with the BRD4301A Radio Board is an ex-
cellent starting point to get familiar with the BGM113 Blue Gecko
Module. It also provides the necessary tools for developing a Sili-
con Labs wireless application.
BRD4301A contains the BGM113 Module, and it is a plug-in board for the Wireless Start-
er Kit Mainboard.
The Wireless Starter Kit Mainboard contains an on-board J-Link debugger with a Packet
Trace Interface and a virtual COM port, enabling application development and debugging
the attached radio board as well as external hardware. The mainboard also contains
sensors and peripherals for easy demonstration of some of the BGM113's many capabili-
ties.
This document describes how to use the BRD4301A Radio Board together with a Wire-
less Starter Kit Mainboard.
silabs.com | Building a more connected world.
BRD4301A RADIO BOARD FEATURES
• BGM113 Blue Gecko Module with 256 kB
Flash and 32 kB RAM, with integrated chip
antenna, RF matching network, crystals
and decoupling (BGM113A256V1).
WIRELESS STK MAINBOARD FEATURES
• Advanced Energy Monitor
• Packet Trace Interface
• Virtual COM Port
• SEGGER J-Link on-board debugger
• External device debugging
• Ethernet and USB connectivity
• Silicon Labs Si7021 Relative Humidity and
Temperature sensor
• Low Power 128x128 pixel Memory LCD
• User LEDs / Pushbuttons
• 20-pin 2.54 mm EXP header
• Breakout pads for Module I/O
• CR2032 coin cell battery support
SOFTWARE SUPPORT
• Simplicity Studio™
• Energy Profiler
• Network Analyzer
• iOS and Android applications
ORDERING INFORMATION
• SLWRB4301A
Rev. 2.01
