- Page 1 Anleitung EX-1112HMS 12-Port USB 3.2 Gen 1 Metall HUB mit 15KV ESD Überspannungsschutz 12-Port USB 3.2 Gen 1 Metal HUB with 15KV ESD Surge Protection Vers. 1.1 / 31.03.22 Manual...
-
Page 2: Table Of Contents
Layout, Connections & Jumper Settings ··························································· 10-11 Layout ·······················································································································10 Connections ·········································································································· 10-11 Jumper Settings ··········································································································11 Hardware Installation ························································································· 12 Driver Installation ······························································································ 13 Cleaning ········································································································· 13 Technical Information ························································································ 14 Technical Drawing ···························································································· 14 © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 3: Beschreibung
Bevor Sie den EX-1112HMS an Ihren PC anschließen, überprüfen Sie bitte zuerst den Inhalt der Lieferung: • EX-1112HMS • USB 3.2 Gen 1 Kabel (EX-K1504) • DIN-Rail Kit (EX-6096) • Wandmontagehalterung • Bedienungsanleitung © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 4: Aufbau, Anschlüsse & Jumper Einstellungen
Ihre Hardware zerstört werden!!! GND (Ground) +7V - 24V USB 3.2 Gen 1 A-Buchse: GND_DRAIN StdB_SSTX+ StdB_SSTX + Achtung! StdB_SSTX - StdB_SSTX - Stecker niemals umgekehrt oder mit Gewalt einstecken. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 5: Jumper Einstellungen
Dafür müssen Sie zu erst das Gehäuse mit den vier Schrauben auf den Seiten öff- nen. Nun müssen Sie den Jumper JP1 von ENA (Enable) auf DIS (Disable) setzen. Siehe nach- folgende Abbildung. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 6: Hardware Installation
Hub‘s an und stecken Sie den Netzstecker des Netzteils in eine Steckdose. 5. Verbinden Sie nun das andere Ende (A-Anschluss) des mitgelieferten USB 3.2 Gen 1 Kabels mit der A-Buchse an Ihrem PC. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 7: Treiber Installation
Sie die Verschmutzung mit leichtem Druck. Im Bereich der Anschlüsse bitte darauf Achten, dass keine Fasern des Tuchs in der Buchse hinterlassen werden. Verwenden Sie bitte zu Reinigung in keinem Fall ein feuchtes oder nasses Tuch! © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 8: Technische Daten
0° bis 55° Celsius Lagertemperatur: -20° bis 85° Celsius Rel. Luftfeuchtigkeit: 5% bis 95% Stromversorgung: +7 bis +24 Volt Abmessung: 132,50 x 65,00 x 48,20 mm Gewicht: 1000g 8. Technische Zeichnung © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 9: Description
Before you connect the EX-1112HMS to your PC, you should first check the contents of the deliv- ery: • EX-1112HMS • USB 3.2 Gen 1 Cable (EX-K1504) • DIN-Rail Kit (EX-6096) • Wall Mounting Bracket • Manual © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 10: Layout, Connections & Jumper Settings
Hardware!!! GND (Ground) +7V - 24V USB 3.2 Gen 1 A-Port: GND_DRAIN StdB_SSTX+ StdB_SSTX + StdB_SSTX - StdB_SSTX - Attention! Never plug in with force or in wrong direction. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 11: Jumper Settings
For this you open the case with the four screws on both sides. Then you must set the jumper JP1 from ENA (Enable) to DIS (Disable). See the following picture. © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 12: Hardware Installation
3. Connect the optional power supply to the Terminal Block at the Hub. 4. Now connect the other end from the USB 3.2 Gen 1 cable (A-Plug) to the USB A-Port at your © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 13: Driver Installation
For cleaning please use only a dry fluff less cloth and remove the dirt with gently pressure. In the area of the connectors please make sure that no fibres from the cloth remain in the connectors. Attention! Never use a moist or wet cloth for cleaning! © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved... -
Page 14: Technical Information
32° to 131°Fahrenheit Storage Temperature: -40° to 185°Fahrenheit Rel. Humidity: 5% to 95% Power: +7 to +24 Volt Size: 132,50 x 65,00 x 48,20 mm Weight: 1000g 8. Technical Drawing © Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved...
