File Transfer Dialogs

Send Configuration Files dialog window

The Send Configuration Files dialog window allows you to see the current settings for sending files,
change and set the connection method and send the file.
Click to
set the
communications
settings
Device ID
number
The status
of the file
transfer
FIG. 33 Send Configuration Files Dialog Window
KeypadBuilder v2.1
Current communication settings
Communication Settings - The display field shows you the current communication setting
for KeypadBuilder.
The Communication Settings... button launches the Communication Settings dialog
window.
Device ID - Type the Device ID number for the currently targeted device.
Send File Options - Click the box to include the information sent to the device.
Configuration File - This is the file that sets the button functionality, channel
assignments, and menu behaviors
Font File - If the font used in menu display is not already loaded on the device, it is
necessary to include this file in the send.
Glyph File - If you selected Complex Script menu items and created glyphs, you
need to check this box to include them in the download file.
Send File - Click this button after the communications have been set to send the selected files
to the targeted device.
Done - Click this button after you have received indication of a successful send in the Transfer
Status field. Done closes the dialog window.
Program Reference
The files to be sent to
the master.
