List box Button Properties Dialog Window

The List box Button Properties dialog window is accessible when a list box button is selected in Page
Navigation Window, then Project > Button Items Properties. This dialog window sets and edits the
properties for the list box button. Any settings established in the list box button properties populates
down to each item contained in the list box.
Word Wrap is generally useful with fonts sizes 8 pt. or less.
New tables require a unique table name and table port and address. See Working With Function Codes
for more information on ports and addresses.
Existing tables requires a selection from the list provided.
Dynamic tables require the port and address for the dynamic table.
Click OK to confirm or Cancel to exit without changes.
Feedback for list box buttons is always "momentary."
108
Move Down - Moves the selected button line down the keypad page, below the button before
it.
Button Name - This is the name of the button as it will appear in the Page Navigation
Window. By default, KeypadBuilder names these buttons incrementally, e.g., Button 1. It is a
good design practice to give your buttons names that apply to the function they serve.
Description - This text field is for describing the button in some detail. Providing information
in this field is helpful not only to yourself but to anyone else that works with the project file at
a later date.
Addressing - The addressing for the selected button. Set the Port and Code for both the
Address and Channel.
Font - The font is the currently selected font, style and point size. Clicking on the (...)
launches the Choose Font Dialog Window.
Word Wrap - When checked, the text will wrap to the next line. Be certain your display area
supports your selected font attributes.
Justification - The text is displayed on the keypad device as either Left, Center or Right. Click
the radio button next to the desired selection to select.
List box Data Source:
Create New Table - Creates a new static table.
Use Existing Table - Uses one of the preexisting tables within the KeypadBuilder
project file.
Specify a Dynamic Table - Assigns a dynamic table to display within the list box
button.
