Mio Attaché Configuration Modules
LCD Configuration
The LCD Configuration module controls what menu items are shown and how they are displayed in
devices equipped with an LCD.
LCD Display; number of lines and font type
FIG. 24
LCD Configuration Dialog Window
LCD Display Resolution
The Display Resolution is the maximum number of lines and type of font family that can be displayed at
one time on your selected device. Click on a font family to select. Only one font family can be used on a
device. If you change the font, you need to include the font information when sending the configuration
file. See the Send Configuration Files dialog window section on page 81.
Dynamic Text
Dynamic Text is information sent from the master and displayed on the device, i.e., time or temperature.
Selecting No Lines for line allocation will cause the device to have lines of displayed menu (text) and no
dynamic information. All lines can be allocated for either menu or dynamic. Regardless of the display
arrangement, the items must be contiguous; the menu items and dynamic items must be grouped
together.
Align
The align feature allows you to decide which, menu or dynamic, items are displayed first. Top places the
dynamic items at the top of the list and Bottom puts them at the bottom.
60
Dynamic line alignment
Dynamic text line allocation
Display
line
selection
Line display
justification
Dynamic
line
visibility
and level
assignment
Dynamic
line level
style
Sleep
Screen
Display
Options
KeypadBuilder v2.1
