Connection of the pneumatic switching facility ..............27 Connection of the position switches ................27 Compressed air connection ................... 28 Setup ............................31 Operation of SHLD 1 ...................... 31 7 Maintenance and fault rectification ..................34 Cleaning ......................... 34 Maintenance ........................34 Test of the switching mechanism ..................35 Tightness test .........................
Page 3
Contents Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2018-11-21 SHLD 1 • Source holder...
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, tip, note This symbol indicates helpful additional information.
Time: Stay as short a time as possible in radiation exposed areas. Distance: Your distance to the source should be as large as possible. The local dose rate of the radiation decreases in proportion to the square of the distance to the radiation source. SHLD 1 • Source holder...
We are at your disposal for further information concerning radiation protection and regulations in other countries. Appropriate use When in operating mode, the source container SHLD 1 described in this document contains a radiactive source for radiometric level, interface, switching and density measurement. The source container shields the radiation off from the surroundings and only allows it to exit, practically unhindered, in the direction of measurement.
This information is only valid for USA and Canada. Hence the follow- ing text is only available in the English language. Installations in the US shall comply with the relevant requirements of the National Electrical Code (ANSI/NFPA 70). SHLD 1 • Source holder...
With these instruments, the corresponding approval documents must be observed. These documents are part of the scope of delivery or can be downloaded from "www.vega.com", "Instrument search (serial number)" as well as via "Downloads" and "Approvals".
Article number - Documentation • Note: "Highly radioactive source" (if necessary) The serial number allows you to access the delivery data of the instru- ment via "www.vega.com", "VEGA Tools" and "Instrument search". Note: The local dose rate stated on the type label at a defined distance is safety-oriented and includes production-related fluctuations of the emitters as well as tolerances of the measuring instruments. There can thus be deviations in the local dose rate calculated with the speci- fied attenuation factors. See also "Principle of operation/Source".
Page 10
3 Product description Fig. 2: Versions SHLD 1 (Overview) Version A: Standard version Version B: with position switch Version C: with Interlock safety switch Version D: Heavy Duty version Version E: version with pneumatic switching mechanism Version F: version with pneumatic switching mechanism and position switch...
Page 11
3 Product description Type labels Fig. 3: Position of the type labels Type label - Source Type label - Source holder Shipping information USA (optional) Warning USA (optional) SHLD 1 • Source holder...
Page 12
Go to "www.vega.com", "Search". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •...
Cs-137. The radioactive source in the source container emits gamma rays. The SHLD 1 is mounted on the vessel, the pipeline or on a conveyor belt/spiral conveyor directly opposite the sensor. The source container shields the environment against gamma radia- tion and protects the radioactive source against mechanical damage or chemical influences. In case of large measuring ranges (e.g. with...
Check the condition of this seal and record the intactness. Transport must be carried out in due consideration of the notes on the Transport transport packaging. Nonobservance of these instructions can cause damage to the device. SHLD 1 • Source holder...
Use the lug of the source holder for transport on a crane hook. Use a suitable lifting tackle (shackle, snap hook, etc.) to fasten the source holder to the crane hook. Keep in mind that the source holder will tilt sidewards while lifting. SHLD 1 • Source holder...
Shipment Transport regulations Radioactive sources are subject to strict regulations. Therefore, when shipping the sources, we are bound to the respective regulations of the country where they will be used. SHLD 1 • Source holder...
Transport of the loaded source holder is carried out by a company authorized by us, with official approval for such transports. The transport is carried out in a type A packaging (source holder SHLD 1 with outer packaging of sheet steel) in compliance with the European and international convention on the transport of dangerous goods (ADR and DGR/IATA regulations).
Keep the weight of the source holder in mind when mounting (up to 100 kg or 220 lbs) • Depending on the version, the centre of gravity of SHLD 1 can vary. Keep this in mind during crane transport on the lug Mounting with a crane Warning: Check the hoisting equipment for sufficient lifting capacity, approx.
The radiation must be directed exactly towards the detector mounted on the op- posite side. The source holder SHLD 1 should be mounted as close as possible to the vessel. However, with large measuring ranges and small vessel diameters, a gap can often not be avoided.
Page 20
The source holder SHLD 1 should be mounted as close as possible to the vessel. However, with large measuring ranges and small vessel diameters, a gap can often not be avoided.
Page 21
You can find the required mounting accessories in chapter "Technical data". The source holder SHLD 1 should be mounted as close as possible to the vessel. However, with large measuring ranges and small vessel diameters, a gap can often not be avoided.
Page 22
Vertical pipeline, diameter 50 … 600 mm (1.97 … 23.62 in) For pipe diameters 50 … 600 mm (1.97 … 23.62 in), a straight radia- tion path is possible. The radiometric sensor can be mounted either horizontally or vertically. SHLD 1 • Source holder...
Page 23
Source holder (SHLD 1) Radiometric sensor (MINITRAC) Radiated area Mounting bracket Avoiding stray radiation - Vertical pipeline, diameter 50 … 600 mm (1.97 … 23.62 in) When mounting the radiometric sensor horizontally, the optional lead shielding is recommended in order to avoid influence from secondary radiation sources. SHLD 1 • Source holder...
Page 24
Mounting bracket Horizontal pipeline On a horizontal pipeline, the radiation should be directed horizontally to avoid interference from air pockets. Fig. 14: Measurement setup on a horizontal pipeline Source holder (SHLD 1) Radiated area Detector (MINITRAC) SHLD 1 • Source holder...
Measurement of the local dose rate After mounting, i.e. as soon as the radioactive emitter is mounted in the source holder, the local dose rate in the area of the source holder and the detector must be measured in µSv/h. SHLD 1 • Source holder...
Page 26
"Radioactive". The responsible radiation safety officer can allow access after having checked the safety measures with switched-off source holder. If work must be carried out in and on the vessel, it is absolutely neces- sary to switch off the radiation on the source holder. SHLD 1 • Source holder...
Connect the position switches according to the following diagrams. Take note of the general installation regulations. As a rule, connect SHLD 1 to vessel ground (PA), or in case of plastic vessels, to the next ground potential. Inside the housing there is a ground terminal.
Lower position switch for switch position "OFF" (terminals 4 to 6) Ground terminal Connection terminals Compressed air connection These instructions apply to source holders SHLD 1, versions with pneumatic switching mechanism. Note: The pneumatic switching mechanism may only be put into operation after the source holder is mounted.
Page 29
5 Connection of the pneumatic switching facility Fig. 18: Connection of the pneumatic lines to SHLD 1 - version with pneumatic switching mechanism Padlock for securing the switch position "OFF" Ventilation filter Indication of the switching position Threaded hole for connection of the compressed air (optionally with con-...
Page 30
Apart from the safety hole there is another laterally displace hole in which the locking bolt can be inserted for safe retention. Attach the required padlock to the locking bolt so that it does not get lost. SHLD 1 • Source holder...
3. Turn the operating lever 90° clockwise up to the stop. "ON" (1) will then appear in the position recess of the operating lever. 4. Secure the operating lever in position "ON" (1). SHLD 1 • Source holder...
Page 32
The safety switch itself must be provided by the customer. The safety bolt of the interlock switch must have a diameter of 16 mm (e.g. Superior Interlock type B-4003). The mounting plate has the following holes: SHLD 1 • Source holder...
Page 33
6 Setup 116 mm (4.57") 63,5 mm 53 mm (2.50") (2.08") 19 mm (0.75") ø 8,25 mm (0.32") Fig. 21: Drilling template of the interlock safety switch A Mounting plate for the interlock safety switch SHLD 1 • Source holder...
Warning: Take note of all safety instructions in this operating instructions manual when cleaning. Maintenance If used properly and if the specified ambient and operating conditions are maintained, SHLD 1 requires no special maintenance. Inspection Along with the regular inspections of the system, we recommend the following checks: • Visual check for corrosion on the housing, the weld joints, the outer parts of the source holder, the lock, the lock washers •...
In case of corrosion: Follow the instructions in chapter "Mainte- nance/Measures in case of corrosion". Tightness test The tightness of the source capsule must be checked at regular inter- vals. The frequency of the tightness test (wipe test) must correspond to the specifications of the authorities or the handling permit. SHLD 1 • Source holder...
Page 36
Take wipe samples from at least the following locations: • On the groove beneath the cover plate • On the lower edge of the mounting surface • Along the groove between operating lever and housing • On the groove beneath the bearing flange SHLD 1 • Source holder...
24 hour service hotline For help with urgent technical problems, call the VEGA service hotline number +49 1805 858550. The hotline is manned 7 days a week round-the-clock. Since we offer this service worldwide, the support is only available in the English language.
Page 38
Pass all necessary information immediately on to the responsible authority local and national authorities • After a thorough investigation of the situation on site, the respon- sible radiation safety officer must agree, together with the local authorities, on appropriate corrective measures for the existing problem Note: National regulations can prescribe deviating procedures and notifica- tion requirements. SHLD 1 • Source holder...
If a return in your country is not possible, contact the respective sales partner to decide on further action. The destination airport for a possible return shipment is Frankfurt a.M., Germany. The following conditions must be fulfilled before a return shipment: SHLD 1 • Source holder...
Page 40
• The return shipment must be carried out with type-tested type A packaging according to IATA regulations. This can be ordered from your sales partner. The source holder SHLD 1 is suitable for a return shipment. • Label the package in accordance with the applicable IATA regula- tions and probable deviating national regulations.
Ʋ Outer housing 316L, with PUR texture paint RAL 1003 Ʋ Tightness of the source insert Silicone Ʋ Shielding material Lead Ʋ Source capsule holder 316L Ʋ Manual switching mechanism 316L Ʋ Pneumatic switching mechanism 316L SHLD 1 • Source holder...
Page 42
9 Supplement Materials - Standard instrument version Fig. 23: Materials SHLD 1 - Standard version Position Component Material Type label - Source 316L Cover plate 316L O-ring (beneath the cover plate) Housing 316L Bearing flange 316L Operating lever 316L Screw 316L...
Page 43
9 Supplement Materials - Instrument version with position switch Fig. 24: Materials SHLD 1 - Version with position switch Position Component Material Type label - Source 316L Cover plate 316L O-ring (beneath the cover plate) Housing 316L Mounting plate 316L...
Page 44
9 Supplement Materials - Instrument version with Interlock safety switch Fig. 25: Materials SHLD 1 - Version with Interlock safety switch Position Component Material Type label - Source 316L Cover plate 316L O-ring (beneath the cover plate) Housing 316L Mounting plate...
Page 45
9 Supplement Materials - Instrument version Heavy Duty Fig. 26: Materials SHLD 1 - Version Heavy Duty Position Component Material Type label - Source 316L Cover plate 316L O-ring (beneath the cover plate) Housing 316L Bearing flange 316L Operating lever with sliding ring (Heavy...
Page 46
9 Supplement Materials - Housing version with pneumatic switching mechanism Fig. 27: Materials SHLD 1 - Version with pneumatic switching mechanism Position Component Material Type label - Source 316L Cover plate 316L O-ring Housing 316L Bearing flange 316L Screw 316L Locking bolt...
Page 47
Screw (torx with safety pin) 316L Grooved pin 316L Materials - Instrument version with pneumatic switching mechanism and position switches Fig. 28: Materials SHLD 1 - Version with pneumatic switching mechanism and position switches Position Component Material Type label - Source...
Page 48
3.7 GBq (100 mCi) Ambient conditions Ambient pressure Atmospheric pressure Ambient temperature (flange temperature) Ʋ SHLD 1 with manual switching -50 … +105 °C (-58 … +221 °F) mechanism Ʋ SHLD 1 with pneumatic switching -12 … +105 °C (+10 … +221 °F) mechanism Ʋ...
Instruments with approvals can have different technical specifications depending on the version. For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com, "Instrument search (serial number)" as well as in the download area. Dimensions SHLD 1, version - standard ø...
Page 50
SHLD 1, version with position switch 163 mm (6.40") 180 mm 178 mm (7.09") (7.00") Fig. 30: Source holder SHLD 1, version with position switch Features • Operating lever for manual switching "ON"/"OFF" • Safety bolt for securing the switching position •...
Page 51
SHLD 1, version with Interlock safety switch ø 116 mm (4.57") 178 mm 180 mm (7.00") (7.09") Fig. 31: Source holder SHLD 1, version with Interlock safety switch Features • Operating lever for manual switching "ON"/"OFF" • Safety bolt for securing the switching position •...
Page 52
9 Supplement SHLD 1, Heavy Duty version 180 mm 178 mm (7.09") (7.00") Fig. 32: Source holder SHLD 1, Heavy Duty version Features • Greater protection against dust and moisture • Robust operating lever for manual switching "ON"/"OFF" • Padlock for securing the switch position "ON" or "OFF"...
Page 53
SHLD 1, version with pneumatic switching mechanism 111 mm (4.37") 178 mm 180 mm (7.00") (7.09") Fig. 33: Source holder SHLD 1, version with pneumatic switching mechanism Features • Pneumatic switching "ON"/"OFF" • Padlock for securing the switch position "OFF" SHLD 1 • Source holder...
Page 54
SHLD 1, version with pneumatic switching mechanism and position switches 178 mm 180 mm (7.00") (7.09") Fig. 34: Source holder SHLD 1, version with pneumatic switching mechanism and position switch Features • Pneumatic switching "ON"/"OFF" • Padlock for securing the switch position "OFF"...
Page 55
(0.44") 180 mm 152,4 mm (7.09") (6") Fig. 35: Beam exit channel (e.g. standard version) SHLD 1, free height for source exchange 180 mm (7.09") 300 mm (11.81") Fig. 36: Free height above the source holder for exchanging the source...
Page 56
Mounting brackets KV 31, for pipes from 50 … 220 mm (1.97 … 8.66 in) for 30° diagonal irradiation Fig. 37: Mounting brackets for diagonal mounting on pipes from 50 … 220 mm (1.97 … 8.66 in) SHLD 1 • Source holder...
Page 57
Mounting brackets KV 31, for pipes from 50 … 600 mm (1.97 … 23.62 in) Fig. 38: Measurement setup on a pipeline with a diameter of 50 … 600 mm (1.97 … 23.62 in), detector mounted vertically Source holder (SHLD 1) Radiometric sensor (MINITRAC) Radiated area Mounting bracket SHLD 1 • Source holder...
Page 58
Mounting brackets KV 31, for pipes from 50 … 600 mm (1.97 … 23.62 in) Fig. 39: Measurement setup on a pipeline with a diameter of 50 … 600 mm (1.97 … 23.62 in), detector mounting horizontal Source holder (SHLD 1) Radiometric sensor (MINITRAC) Radiated area Mounting bracket SHLD 1 • Source holder...
Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.
