Page 3 Programming Manual Series: CFW-11 Language: English Document: 0899.5620 / 09 Software Version: 6.0X Publication Date: 11/2019...
Page 4 Summary of Reviews The table below describes all reviews made to this manual. Version Review Description V1.1X First edition V1.3X R01 and R02 General review V2.0X General review V3.1X R04 and R05 General review V5.7X R06, R07 and R08 General review New software version V6.0X V6.0X Inclusion of new parameters: P0174, P0177 and P0362...
Page 5: Table Of Contents
Summary QUICK PARAMETER REFERENCE, FAULTS AND ALARMS ....0-1 1 SAFETY INSTRUCTIONS ..............1-1 1.1 SAFETY WARNINGS IN THIS MANUAL ............1-1 1.2 SAFETY WARNINGS ON THE PRODUCT ............1-1 1.3 PRELIMINARY RECOMMENDATIONS ............1-2 2 GENERAL INFORMATION ............... 2-1 2.1 ABOUT THIS MANUAL ................
Page 6 Summary 10 VVW CONTROL ................. 10-1 10.1 VVW CONTROL [25] ................10-3 10.2 MOTOR DATA [43] .................. 10-3 10.3 VVW CONTROL MODE START-UP ............10-5 11 VECTOR CONTROL ..............11-1 11.1 SENSORLESS CONTROL AND WITH ENCODER ........11-1 11.2 I/F MODE (SENSORLESS)................. 11-5 11.3 SELF-TUNING ..................
Page 7 Summary 13 DIGITAL AND ANALOG INPUTS AND OUTPUTS ......13-1 13.1 I/O CONFIGURATION [07] ..............13-1 13.1.1 Analog Inputs [38] ................. 13-1 13.1.2 Analog Outputs [39] ............... 13-6 13.1.3 Digital Inputs [40] ................ 13-12 13.1.4 Digital Outputs / Relays [41] ............13-20 13.2 LOCAL AND REMOTE COMMAND ............
Page 8 Summary 20 PID REGULATOR [46] ..............20-1 20.1 DESCRIPTION AND DEFINITIONS ............20-1 20.2 COMMISSIONING ................... 20-3 20.3 SLEEP MODE ................... 20-8 20.4 MONITORING MODE SCREENS .............. 20-8 20.5 CONNECTION OF A 2-WIRE TRANSDUCER ..........20-9 20.6 PARAMETERS ................... 20-9 20.7 ACADEMIC PID ..................
Page 9: Quick Parameter Reference, Faults And Alarms
Quick Parameter Reference, Faults and Alarms QUICK PARAMETER REFERENCE, FAULTS AND ALARMS User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0000 Access to Parameters 0 to 9999 P0001 Speed Reference 0 to 18000 rpm 16-1 P0002 Motor Speed 0 to 18000 rpm 16-1 P0003...
Page 10 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0030 IGBTs Temperature U -20.0 to 150.0 °C 09, 45 16-6 P0031 IGBTs Temperature V -20.0 to 150.0 °C 09, 45 16-6 P0032 IGBTs Temperature W -20.0 to 150.0 °C 09, 45...
Page 11 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0092 Speed At Last Fault 0 to 18000 rpm 16-14 P0093 Reference Last Fault 0 to 18000 rpm 16-14 P0094 Frequency Last Fault 0.0 to 1020.0 Hz 16-14 P0095...
Page 12 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0151 DC Regul. Level V/f 339 to 400 V 400 V (P0296=0) V/f and VVW 9-12 585 to 800 V 800 V (P0296=1) 585 to 800 V 800 V (P0296=2) 585 to 800 V...
Page 13 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0185 DC Link Regul. Level 339 to 400 V 400 V (P0296=0) Vector 11-31 585 to 800 V 800 V (P0296=1) 585 to 800 V 800 V (P0296=2) 585 to 800 V 800 V (P0296=3)
Page 14 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0205 Read Parameter Sel. 1 0 = Not selected 1 = Speed Refer. # 2 = Motor Speed # 3 = MotorCurrent # 4 = DC Link Volt # 5 = Motor Freq.
Page 15 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0220 LOC/REM Selection Src 0 = Always LOC 31, 32, 33, 13-33 1 = Always REM 2 = LR Key LOC 3 = LR Key REM 4 = DIx 5 = Serial/USB LOC 6 = Serial/USB REM...
Page 16 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0229 Stop Mode Selection 0 = Ramp to Stop 31, 32, 33, 13-36 1 = Coast to Stop 2 = Fast Stop 3 = By Ramp with Iq* 4 = Fast Stop with Iq* P0230 Dead Zone (AIs)
Page 17 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0251 AO1 Function 0 = Speed Ref. 13-7 1 = Total Ref. 2 = Real Speed 3 = Torque Cur.Ref 4 = Torque Current 5 = Output Current 6 = Process Var.
Page 18 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0257 AO3 Function 0 = Speed Ref. 13-8 1 = Total Ref. 2 = Real Speed 3 = Torque Cur.Ref 4 = Torque Current 5 = Output Current 6 = Process Var.
Page 19 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0259 AO3 Signal Type 0 = 0 to 20 mA 13-11 1 = 4 to 20 mA 2 = 20 to 0 mA 3 = 20 to 4 mA 4 = 0 to 10 V 5 = 10 to 0 V...
Page 20 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0267 DI5 Function See options in P0266 20, 31, 32, 13-13 33, 34, 36, 37, 40, 44, 45, 46 P0268 DI6 Function See options in P0266 20, 31, 32, 13-13 33, 34, 36,...
Page 21 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0276 DO2 Function (RL2) 0 = Not Used 13-21 1 = N* > Nx 2 = N > Nx 3 = N < Ny 4 = N = N* 5 = Zero Speed 6 = Is >...
Page 22 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0278 DO4 Function 0 = Not Used 13-21 1 = N* > Nx 2 = N > Nx 3 = N < Ny 4 = N = N* 5 = Zero Speed 6 = Is >...
Page 23 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0295 ND/HD VFD Rated Curr. 0 = 3.6 A / 3.6 A 09, 42 1 = 5 A / 5 A 2 = 6 A / 5 A 3 = 7 A / 5.5 A 4 = 7 A / 7 A 5 = 10 A / 8 A...
Page 24 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting 81 = 100 A / 85 A 82 = 107 A / 90 A 83 = 108 A / 95 A 84 = 125 A / 107 A 85 = 130 A / 108 A 86 = 150 A / 122 A 87 = 147 A / 127 A...
Page 25 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0316 Serial Interf. Status 0 = Off 09, 113 17-1 1 = On 2 = Watchdog Error P0317 Oriented Start-up 0 = No 1 = Yes P0318 Copy Function MemCard...
Page 26 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0351 Motor Overtemp. Conf. 0 = Off 15-11 1 = Fault/Alarm 2 = Fault 3 = Alarm P0352 Fan Control Config. 0 = HS-OFF,Int-OFF 15-12 1 = HS-ON,Int-ON 2 = HS-CT,Int-CT...
Page 27 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0383 Sensor 4 F/A Conf. 0 = Off 15-19 1 = Fault/Al./Cab. 2 = Fault/Cable 3 = Alarm/Cable 4 = Fault/Alarm 5 = Fault 6 = Alarm 7 = Alarm Cable P0384...
Page 28 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0404 Motor Rated Power 0 = 0.33hp 0.25kW Motor 05, 43, 94 10-4 max-ND 1 = 0.5hp 0.37kW 2 = 0.75hp 0.55kW 3 = 1hp 0.75kW 4 = 1.5hp 1.1kW 5 = 2hp 1.5kW 6 = 3hp 2.2kW...
Page 29 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting 0 to 1.25xI P0410 Magnetization Current V/f, VVW 05, 43, 94 11-14 nom-ND nom-ND and Vector 0.00 to 99.99 mH P0411 Leakage Inductance 0.00 mH CFG and 05, 43, 94...
Page 30 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0552 Trigger Condition 0 = P0550* = P0551 19-2 1 = P0550* <>P0551 2 = P0550* > P0551 3 = P0550* < P0551 4 = Alarm 5 = Fault 6 = DIx...
Page 31 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0682 Serial/USB Control Bit 0 = Ramp Enable 09, 111 17-1 Bit 1 = General Enable Bit 2 = Run Forward Bit 3 = JOG Enable Bit 4 = Remote Bit 5 = 2nd Ramp Bit 6 = Reserved...
Page 32 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0719 DNet Network Status 0 = Offline 09, 112 17-2 1 = OnLine,NotConn 2 = OnLine,Conn 3 = Conn.Timed-out 4 = Link Failure 5 = Auto-Baud P0720 DNet Master Status...
Page 33 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0740 Profibus Comm. Status 0 = Disabled 09, 115 1 = Access Error 2 = Offline 3 = Config.Error 4 = Param.Error 5 = Clear Mode 6 = Online P0741 Profibus Data Profile...
Page 34 Gateway 4 0 to 255 17-3 P0853 Station Name 0 to 255 17-3 P0854 Compatible mode 0 = Modbus WEG 0 = Modbus WEG 17-4 1 = Modbus Anybus P0918 Profibus Address 1 to 126 17-5 P0922 Profibus Teleg. Sel.
Page 35 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P0967 Control Word PROFIdrive Bit 0 = ON 09, 115 17-5 Bit 1 = No Coast Stop Bit 2 = No Quick Stop Bit 3 = Enable Operation Bit 4 = Enable Ramp Generator...
Page 36 Quick Parameter Reference, Faults and Alarms User Parameter Function Adjustable Range Factory Setting Properties Groups Pag. Setting P1039 SoftPLC Parameter 30 -32768 to 32767 18-1 P1040 SoftPLC Parameter 31 -32768 to 32767 18-1 P1041 SoftPLC Parameter 32 -32768 to 32767 18-1 P1042 SoftPLC Parameter 33...
Page 37 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes F006 Mains voltage imbalance too high or phase missing Phase missing at the inverter's input power supply. Imbalance or in the input power supply. Input voltage imbalance >5 %. Input Phase Loss Note: For the Frame Size E: - If the motor is unloaded or operating with reduced...
Page 38 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes A050 A high temperature alarm was detected by the NTC Surrounding air temperature is too high and output current IGBT High Temperature U temperature sensors located on the IGBTs. is too high for further information on the maximum ambient Note: temperature, refer to the user manual.
Page 39 Alarm that indicates an access error to the Defective, unrecognized, or improperly installed Anybus-CC Anybus Access Error Anybus-CC communication module. module. Conflict with a WEG option board. A133 Alarm indicating that the power supply was not Broken or loose cable. CAN Not Powered connected to the CAN controller.
Page 40 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes A139 It indicates an interruption in the communication Verify whether the network master is correctly configured Offline Profibus DP between the Profibus DP network master and the and operating normally. Interface inverter.
Page 41 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes F183 Overtemperature related to the IGBTs overload Surrounding air temperature too high. IGBT Overload + protection. Operation with frequencies < 10 Hz under overload. Temperature F185 It indicates fault at the pre-charge Contactor. Pre-charge contactor defect.
Page 42 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes F238 Refer to the Profibus DP communication manual. Profibus DP Interface in Clear Mode F239 Offline Profibus DP Interface F240 Profibus DP Module Access Error A300 High temperature alarm measured with the High ambient temperature and high output current.
Page 43 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes F322 Overtemperature fault measured with the temperature High ambient temperature and high output current. (10) Overtemperature at IGBT sensor (NTC) of the book 3 V phase IGBT. Blocked or defective fan. V B3 Fins of the book heatsink too dirty, impairing the air flow.
Page 44 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes A357 Overload alarm at book 2 V phase IGBT. High current at the inverter output (see figure 8.1 of the (10) High Load at IGBT V B2 CFW-11M user's manual). F358 Overload fault at book 2 V phase IGBT.
Page 45 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes A391 Phase V book 1current unbalance alarm. Bad electric connection between the DC bus and the (10) Current Unbalance at It indicates a 20 % unbalance in the current power unit. Phase V B1 distribution between this phase and the smallest Bad electric connection between the power unit output...
Page 46 Quick Parameter Reference, Faults and Alarms Fault/Alarm Description Possible Causes A402 Phase U book 5 current unbalance alarm. Bad electric connection between the DC bus and the (10) Current Unbalance at It indicates a 20 % unbalance in the current power unit.
Page 47 - To reduce the switching frequency (P0297). - Installation of output reactance between the motor and the inverter. (15) Manual available for download on the website: www.weg.net. NOTE! The range from P0750 to P0799 is destined to the SoftPLC applicative user faults and alarms.
Page 48 Quick Parameter Reference, Faults and Alarms 0-40...
Page 49: Safety Instructions
Safety Instructions 1 SAFETY INSTRUCTIONS This Manual contains the information necessary for the correct use of the CFW-11 frequency inverter. It has been developed to be used by qualified personnel with suitable training or technical qualification for operating this type of equipment. 1.1 SAFETY WARNINGS IN THIS MANUAL The following safety warnings are used in this manual: DANGER!
Page 50: Preliminary Recommendations
If necessary, touch the grounded metallic frame before or use an adequate grounded wrist strap. Do not perform any high pot tests with the inverter! If it is necessary consult WEG. NOTE! Frequency Inverter may interfere with other electronic equipment. In order to reduce these effects, take the precautions recommended in the chapter 3 - Installation and Connections, of the user's manual.
Page 51: General Information
General Information 2 GENERAL INFORMATION 2.1 ABOUT THIS MANUAL This manual presents the necessary information for the configuration of all of the functions and parameters of the CFW-11 frequency inverter. This manual must be used together with the CFW-11 user's manual. The text intents to supply additional information to facilitate the use and programming of the CFW-11 in specific applications.
Page 52 General Information PTC: It’s a resistor whose resistance value in ohms increases proportionally to the increase of the temperature; it is used as a temperature sensor in motors. NTC: It’s a resistor whose resistance value in ohms decreases proportionally to the temperature increase; it is used as a temperature sensor in power modules.
Page 53: Numerical Representation
General Information l/s: liters per second. kg: kilogram = 1000 gram. kHz: kilohertz = 1000 Hz. mA: milliamp = 0.001 Amp. min: minute. ms: millisecond = 0.001 second. Nm: newton meter; torque measurement unit. rms: "Root Mean Square"; effective value. rpm: revolutions per minute: speed measurement unit.
Page 54 General Information...
Page 55: About The Cfw-11
About the CFW-11 3 ABOUT THE CFW-11 3.1 ABOUT THE CFW-11 The CFW-11 is a high performance Frequency Inverter that makes it possible the control of speed and torque of three-phase AC induction motors. The principal characteristic of this product is the "Vectrue" technology, which presents the following advantages: Scalar Control (V/f), VVW or vector control programmable in the same product.
Page 56 About the CFW-11  = DC link connection = Dynamic braking resistor connection  Pre- charge Power Motor Supply Capacitor Three-phase IGBT inverter Bank rectifier RFI filter DC LINK Feedbacks: - voltage - current POWER CONTROL Power supplies for electronics and for interface SuperDrive G2 software between power and control WLP software...
Page 57 About the CFW-11 A – Mounting Supports (for surface mounting) B – Heatsink C – Top cover D – Fan with fixing support E – COMM 2 module (Anybus) F – Accessory board module G – FLASH memory module H – Front cover I –...
Page 58 About the CFW-11...
Page 59: Keypad (Hmi)
Keypad (HMI) 4 KEYPAD (HMI) 4.1 KEYPAD (HMI) Through the keypad (HMI) it is possible to command the inverter, visualize and adjust all the parameters. It presents a navigation manner similar to the one used in cell phones, with options to access the parameters sequentially or by means of groups (menu).
Page 60 Keypad (HMI) Cover Cover for battery access Remove the cover Press the cover and rotate it counterclockwise Remove the battery with the help HMI without the battery Install the new battery positioning it of a screwdriver positioned in first at the left side the right side Press the battery for its insertion Put the cover back and rotate it clockwise...
Page 61: Programming Basic Instructions
Programming Basic Instructions 5 PROGRAMMING BASIC INSTRUCTIONS 5.1 PARAMETER STRUCTURE When the right "soft key" in the monitoring mode ("Menu") is pressed, the first 4 parameter groups are showed on the display. An example of the parameter group structure is presented in the Table 5.1 on page 5-1.
Page 62: Groups Accessed In The Option Menu In The Monitoring Mode
Programming Basic Instructions 5.2 GROUPS ACCESSED IN THE OPTION MENU IN THE MONITORING MODE In the monitoring mode access the groups of the option "Menu" by pressing the right "soft key". Table 5.2 - Parameter groups accessed in the option menu of the monitoring mode Group Contained parameters or groups ALL PARAMETERS...
Page 63: Password Setting In P0000
Programming Basic Instructions 5.3 PASSWORD SETTING IN P0000 P0000 – Access to Parameters Adjustable 0 to 9999 Factory Range: Setting: Properties: Access groups 00 ALL PARAMETERS via HMI: In order to be able to change the content of the parameters, it is necessary to set correctly the password in P0000, as indicated below.
Page 64: Hmi [30]
Programming Basic Instructions 5.4 HMI [30] In the group "30 HMI" are the parameters related to the presentation of information on the keypad (HMI) display. See next the detailed description of the possible settings for those parameters. P0193 – Day of the Week Adjustable 0 = Sunday Factory...
Page 65 Programming Basic Instructions P0200 – Password Adjustable 0 = Off Factory Range: 1 = On Setting: 2 = Change Password Properties: Access groups 01 PARAMETER GROUPS via HMI: 30 HMI Description: It allows changing the password and/or setting its status, configuring it as active or inactive. For more details on each option, refer to the Table 5.3 on page 5-5 described next.
Page 66 Programming Basic Instructions P0205 – Reading Parameter Selection 1 P0206 – Reading Parameter Selection 2 P0207 – Reading Parameter Selection 3 Adjustable 0 = Not selected Factory P0205 = 2 1 = Speed Reference # Range: Setting: P0206 = 3 2 = Motor Speed # P0207 = 5 3 = Motor Current #...
Page 67 Programming Basic Instructions P0208 – Reference Scale Factor Adjustable 1 to 18000 Factory 1800 Range: Setting: (1500) P0212 – Reference Decimal Point Adjustable 0 = wxyz Factory Range: 1 = wxy.z Setting: 2 = wx.yz 3 = w.xyz Properties: Access groups 01 PARAMETER GROUPS via HMI: 30 HMI...
Page 68 Programming Basic Instructions P0209 – Reference Engineering Unit 1 P0210 – Reference Engineering Unit 2 P0211 – Reference Engineering Unit 3 Adjustable 32 to 127 Factory P0209 = 114 (r) Range: Setting: P0210 = 112 (p) P0211 = 109 (m) Properties: Access groups 01 PARAMETER GROUPS...
Page 69: Date And Time Setting
Programming Basic Instructions P0216 – HMI Display Contrast Adjustable 0 to 37 Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 30 HMI Description: It allows setting the keypad (HMI) display contrast level. Higher values configure a higher contrast level. 5.5 DATE AND TIME SETTING Seq.
Page 70: Display Indications In The Monitoring Mode Settings
Programming Basic Instructions 5.6 DISPLAY INDICATIONS IN THE MONITORING MODE SETTINGS Every time the inverter is powered the display goes to the Monitoring Mode. In order to make it easier the reading of the motor main parameters, the keypad (HMI) display can be configured to show them in 3 different modes. Content of the 3 parameters in numerical form: Selection of the parameters via P0205, P0206 and P0207.
Page 71 Programming Basic Instructions Seq. Action/Result Display Indication Seq. Action/Result Display Indication - Monitoring Mode. Ready 0rpm - Press until Ready 0rpm - Press "Menu" P0205 selecting the option (right "soft key"). "[11] Speed Refer. –". Read Parameter Sel. 1 [011] Speed Refer. - - Press "Save".
Page 72: Incompatibility Between Parameters
Programming Basic Instructions 5.7 INCOMPATIBILITY BETWEEN PARAMETERS If any of the combinations listed below occur, the CFW-11 goes to the "Config" state. Two or more DIx (P0263...P0270) programmed for (4 = FWD Run). Two or more DIx (P0263...P0270) programmed for (5 = REV Run). Two or more DIx (P0263...P0270) programmed for (6 = 3-Wire Start).
Page 73 Programming Basic Instructions 25) [P0221 or P0222 programmed for (7 = E.P .)] AND [without DIx (P0263...P0270) programmed for (11 = Increase E.P .) OR without DIx (P0263...P0270) programmed for (12 = Decrease E.P .)]. 26) [P0221 and P0222 not programmed for (7 = E.P .)] AND [with DIx (P0263...P0270) programmed for (11 = Increase E.P .) OR with DIx (P0263...P0270) programmed for (12 = Decrease E.P .)].
Page 74 Programming Basic Instructions 5-14...
Page 75: Inverter Model And Accessories Identification
(HMI). The figures below show examples of those labels. 7890355877722 CFW11 model MOD.: BRCFW110242T4SZ Maximum environment temperature WEG part number MAT.: 11270533 MAX. TA: 45°C (113°F) Serial Number OP .: 1234567890 SERIAL#: 1234567890 Inverter net weight Manufacturing date (Day-month-year)
Page 76: Inverter Data [42]
Inverter Model and Accessories Identification 6.1 INVERTER DATA [42] In this group are the parameters related to the inverter information and characteristics, such as inverter model, accessories identified by the control circuit, software version, switching frequency, etc. P0023 – Software Version Adjustable 0.00 to 655.35 Factory...
Page 77 Inverter Model and Accessories Identification Table 6.1 - CFW-11 accessory identification codes Identification Code Name Description Slot P0027 P0028 Module with 2 14-bit analog inputs, 2 digital inputs, 2 14-bit analog IOA-01 FD-- ---- outputs in voltage or current, 2 open collector digital outputs Module with 2 isolated analog inputs, 2 digital inputs, 2 isolated analog IOB-01 FA--...
Page 78: Parameter Groups
Inverter Model and Accessories Identification Table 6.4 - Example of the two first characters of the code showed in P0028 for PROFIBUS DP-05 and FLASH memory module P0029 – Power Hardware Configuration Adjustable Bit 0 to 5 = Rated Current Factory Range: Bit 6 and 7 = Rated Voltage...
Page 79 Inverter Model and Accessories Identification Table 6.6 - Current codification for the parameter P0029 Bits Bits Frame Size Voltage Current 2 A* 6 A* 7 A* 10 A 10 A 13 A 16 A 24 A 200... 240 V 28 A 33.5 A 45 A 54 A...
Page 80 Inverter Model and Accessories Identification Bits Bits Frame Size Voltage Current 53 A 63 A 80 A 107 A 125 A 150 A 170 A 216 A 289 A 315 A 365 A 435 A 427 A 2.9 A 4.2 A 8.5 A 11 A 15 A...
Page 81 Inverter Model and Accessories Identification P0295 – ND/HD VFD Rated Current Adjustable 0 = 3.6 A / 3.6 A Factory Range: 1 = 5 A / 5 A Setting: 2 = 6 A / 5 A 3 = 7 A / 5.5 A 4 = 7 A / 7 A 5 = 10 A / 8 A 6 = 10 A / 10 A...
Page 82 Inverter Model and Accessories Identification 63 = 11 A / 9 A 64 = 12 A / 10 A 65 = 15 A / 13 A 66 = 17 A / 17 A 67 = 20 A / 17 A 68 = 22 A / 19 A 69 = 24 A / 21 A 70 = 27 A / 22 A...
Page 83 Inverter Model and Accessories Identification P0296 – Line Rated Voltage Adjustable 0 = 200... 240 V Factory According to Range: 1 = 380 V Setting: the inverter 2 = 400 / 415 V model 3 = 440 / 460 V 4 = 480 V 5 = 500 / 525 V 6 = 550 / 575 V...
Page 84 Inverter Model and Accessories Identification P0297 – Switching Frequency Adjustable 0 = 1.25 kHz Factory According to Range: 1 = 2.5 kHz Setting: inverter model 2 = 5.0 kHz 3 = 10.0 kHz 4 = 2.0 kHz Properties: Access groups 01 PARAMETER GROUPS via HMI: 42 Inverter Data...
Page 85: Starting-Up And Settings
Starting-up and Settings 7 STARTING-UP AND SETTINGS In order to start-up in the several types of controls, beginning from the factory settings, consult the following sections: Section 10.3 VVW CONTROL MODE START-UP on page 10-5. Section 11.9 START-UP IN THE VECTOR MODES SENSORLESS AND WITH ENCODER on page 11-32.
Page 86 Starting-up and Settings Table 7.1 - Parameter P0204 options P0204 Action 0, 1 Not Used: no action Reset P0045: resets the enabled fan hour counter Reset P0043: resets the enabled hours counter Reset P0044: resets the kWh counter Load 60 Hz: loads the 60 Hz factory settings into the inverter parameters Load 50 Hz: loads the 50 Hz factory settings into the inverter parameters Load User 1: loads the User 1 parameters into the current inverter parameters Load User 2: loads the User 2 parameters into the current inverter parameters...
Page 87: Oriented Start-Up
Starting-up and Settings P0317 - Oriented Start-up Adjustable 0 = No Factory Range: 1 = Yes Setting: Properties: Access groups 02 ORIENTED START-UP via HMI: Description: When this parameter is changed to “1”, the Oriented Start-up routine starts. The CFW11 goes into the “CONF” state, which is indicated on the HMI.
Page 88 Starting-up and Settings NOTE! Valid for P0318 = 1. When the inverter is powered and the memory module is present, the current parameter contents are compared with the contents of the parameters saved in the MMF and, in case they are different, the keypad (HMI) will exhibit the message "Flash Mem.Module with different parameters", after 3 seconds the message is replaced by the parameter P0318 menu.
Page 89 Starting-up and Settings From that moment on the Inverters A and B will have the parameters with the same contents. Notes:  In case that inverters A and B are not from the same model, verify the values of P0296 (Line Rated Voltage) and P0297 (Switching Frequency) at the Inverter B.
Page 90 Starting-up and Settings...
Page 91: Available Control Types
(programmable); it allows multimotor operation.  VVW: Voltage Vector WEG; it allows a static speed control more accurate than the V/f mode; it adjusts itself automatically to the line variations, and also to the load variations, however it does not present fast dynamic response.
Page 92 Available Control Types...
Page 93: Scalar Control (V/F)
Scalar Control (V/f) 9 SCALAR CONTROL (V/F) It consists of a simple control based on a curve that links output voltage and frequency. The inverter operates as a voltage source, generating frequency and voltage values according to that curve. It is possible to adjust this curve to standard 50 Hz or 60 Hz motors or to special ones through the adjustable V/f curve.
Page 94: V/F Control [23]
Scalar Control (V/f) 9.1 V/F CONTROL [23] P0136 – Manual Torque Boost Adjustable 0 to 9 Factory According Range: Setting: to inverter model Properties: Access groups 01 PARAMETER GROUPS via HMI: 23 V/f Control Description: It acts at low speeds, increasing the inverter output voltage in order to compensate the voltage drop across the motor stator resistance, with the purpose of keeping the torque constant.
Page 95 Scalar Control (V/f) P0007 P0136 Voltage Applied to Speed Reference I x R the Motor P0137 Active Output Automatic Current I x R P0139 Figure 9.3 - Torque Boost block diagram Output Voltage Nominal 1/2 Nominal Compensation Zone Speed nom/2 Figure 9.4 - Effect of P0137 on the V/f curve (P0202 = 0…2) P0138 –...
Page 96 Scalar Control (V/f) Total Reference (Refer to Figure 9.1 on page 9-1) Speed ∆ F Output Slip Compensation Active Current P0139 P0138 Figure 9.5 - Slip compensation block diagram Output Voltage ∆V (function of the motor load) ∆F Speed Figure 9.6 - V/f curve with slip compensation For the adjustment of the parameter P0138 to compensate the motor slip: 1) Run the motor with no load at approximately half the working speed.
Page 97 (P0320 = 1 or 2). P0202 – Type of Control Adjustable 0=V/f 60 Hz Factory Range: 1=V/f 50 Hz Setting: 2=V/f Adjustable 3=Sensorless 4=Encoder 5=VVW (Voltage Vector WEG) 6=Encoder PM 7=Sensorless PM Properties: Access groups 01 PARAMETER GROUPS via HMI: 23 V/f Control...
Page 98: Adjustable V/F Curve [24]
Scalar Control (V/f) Description: In order to get an overview of the control types, as well as orientation to choose the most suitable type for the application, refer to the Chapter 8 AVAILABLE CONTROL TYPES on page 8-1. For the V/f mode, select P0202 = 0, 1 or 2: Parameter P0202 setting for the V/f mode:  P0202 = 0 for motors with rated frequency = 60 Hz.
Page 99 Scalar Control (V/f) P0145 – Field Weakening Speed P0146 – Intermediate Speed Adjustable 0 to 18000 rpm Factory P0145 = 1800 rpm Range: Setting: P0146 = 900 rpm Properties: Adj and CFG Access groups 01 PARAMETER GROUPS via HMI: 24 Adjust. V/f Curve Description: This function allows the adjustment of the curve that links output voltage and frequency by means of parameters, as presented by the...
Page 100: V/F Current Limitation [26]
Scalar Control (V/f) 9.3 V/F CURRENT LIMITATION [26] P0135 – Maximum Output Current Adjustable 0.2 to 2xI Factory 1.5xI nom-HD nom-HD Range: Setting: Properties: V/f and VVW Access groups 01 PARAMETER GROUPS via HMI: 26 V/f Current Limit P0344 – Current Limitation Configuration Adjustable 0 = Hold -FL ON Factory...
Page 101 Scalar Control (V/f) Current limitation of the "Ramp Deceleration" type:  It avoids the stalling of the motor during a torque overload at the acceleration or at constant speed.  Working: if the motor current exceeds the value adjusted in P0135, the input of the speed ramp is set to zero forcing a deceleration.
Page 102: V/F Dc Voltage Limitation [27]
Scalar Control (V/f) 9.4 V/F DC VOLTAGE LIMITATION [27] There are two functions in the inverter for limiting the DC link voltage during the motor braking. They act limiting the braking torque and power, avoiding therefore the tripping of the inverter by overvoltage (F022). The overvoltage on the DC link is more common when a load with high inertia is driven or when a short deceleration time is programmed.
Page 103 Scalar Control (V/f) DC Link Voltage (P0004) F022 – Overvoltage DC Link Regulation P0151 Nominal U Time Output Speed Time Figure 9.11 - Example of the DC link voltage limitation working with the Ramp Hold function 2 - Ramp Acceleration: It is effective in any situation, regardless of the motor speed condition, accelerating, decelerating or at constant speed.
Page 104 Scalar Control (V/f) DC Link Voltage (P0004) F022-Overvoltage P0151 DC Link Regulation Nominal U Time Output Speed Time Figure 9.13 - Example of the DC link voltage limitation working with the Ramp Acceleration function P0150 – DC Regulator Type (V/f) Adjustable 0 = Ramp Hold Factory...
Page 105 Scalar Control (V/f) Description: It is the actuation level of the DC link voltage limitation function for the V/f mode. Setting of P0151 value: a) The P0151 factory setting leaves inactive the DC link voltage limitation function for the V/f mode. In order to activate it, one must reduce the value of P0151 as suggested in the Table 9.2 on page 9-13.
Page 106: Energy Saving Function
Scalar Control (V/f) 9.5 ENERGY SAVING FUNCTION Induction motors are designed considering an optimized efficiency for operation with rated flux and torque between 75 % and 100 % of the rated value. In order to increase the efficiency of induction motors under reduced load conditions, there is an energy saving function available on the CFW11 inverters that reduces voltage/flux with partial loads.
Page 107 Scalar Control (V/f) Description: This parameter defines the reference cos ø for the energy saving function. It is automatically adjusted according to parameter P0407. It assumes the value of 0.9 x P0407 whenever P0407 is changed. If necessary, the value of P0587 can be manually set to the desired value. For the proper operation of the energy saving function, the motor rated power factor (P0407) must be adjusted according to the motor nameplate.
Page 108 Scalar Control (V/f) P0590 – Energy Saving Minimum Speed Adjustable 0 to 18000 rpm Factory 600 (525) rpm Range: Setting: Properties: V/f and Vector Access groups 01 PARAMETER GROUPS via HMI: 45 Energy Saving Description: This parameter defines the minimum speed value at which the energy saving function will remain active. That is, for speeds greater than P0590, the energy saving function is activated.
Page 109: Tart-Up In The V/F Control Mode
Scalar Control (V/f) Table 9.3 - Options of parameter P0600 P0600 Action Inactive: no action Inverter -> MemCard: saves the inverter firmware on the MMF. When starting this process, the inverter will go to config, and when finishing parameter, P0600 returns to 0 automatically MemCard ->...
Page 110 Scalar Control (V/f) 9-18...
Page 111: Vvw Control
VVW Control 10 VVW CONTROL The VVW (Voltage Vector WEG) control mode uses a control method with intermediate performance between V/f and Sensorless Vector. Refer to the Figure 10.1 on page 10-2 block diagram. The main advantage compared to the V/f control is the better speed regulation with higher torque capability at low speeds (frequencies below 5 Hz), allowing a sensible improvement of the inverter performance in permanent regimen.
Page 112 VVW Control Figure 10.1 - VVW control block diagram 10-2...
Page 113: Motor Data [43]
VVW Control 10.1 VVW CONTROL [25] The parameter group [25] – VVW Control – contains only 5 parameters related to that function: P0139, P0140, P0141, P0202 and P0397. However, since the parameters P0139, P0140, P0141 and P0202 were already presented in the Section 9.1 V/F CONTROL [23] on page 9-2, only the parameter P0397 will be described next.
Page 114 The default value of this parameter is adjusted automatically when the parameter P0404 is changed. The suggested value is valid for three-phase, IV pole WEG motors. For other motor types the setting must be done manually. P0408– Run Self-Tuning P0409 –...
Page 115: Vvw Control Mode Start-Up
VVW Control P0414 – Motor Magnetization Time Adjustable 0.000 to 9.999 s Factory 0.000 s Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data Description: This parameter allows setting a motor magnetization time different from 2 x P0412, and then this is the time the inverter takes into account to indicate the motor is general enabled (or magnetized) after receiving the general enable command.
Page 116 VVW Control Parameters related to the motor: - Program the contents of parameters from P0398 to P0407 directly with the motor nameplate data. Refer to the Section 11.7 MOTOR DATA [43] on page 11-10 - Options for the setting of parameter P0409: I –...
Page 117 VVW Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication Ready 0rpm Config 0rpm - Monitoring Mode. Language P0201: English - Press "Menu" - Set the content of P0202 Type of Control (right "soft key"). pressing "Select". P0202: V/f 60Hz 13:48 Menu - Next press...
Page 118 VVW Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication - If necessary, change - If necessary, change the content of P0400 the content of P0406 Config 0rpm according to the motor according to the motor Config 0rpm Motor Rated Power rated voltage.
Page 119: Vector Control
Vector Control 11 VECTOR CONTROL It consists in the control type based on the separation of the motor current into two components:  Flux producing current I (oriented with the motor electromagnetic flux).  Torque producing current I (perpendicular to the motor flux vector). The I current is related to the motor electromagnetic flux, while the I current is directly related to the torque...
Page 120 Vector Control Figure 11.1 - Sensorless vector control block diagram 11-2...
Page 121 Vector Control The Vector Control with Encoder presents the same advantages of the sensorless control previously described, with the following additional benefits:  Torque and speed control down to 0 (zero) rpm.  Speed control accuracy of 0.01 % (if the 14-bit analog speed reference via optional board IOA-01 is used, or if digital references are used, for instance via keypad (HMI), Profibus DP , DeviceNet, etc.).
Page 122 Vector Control Figure 11.2 - Vector with encoder control block diagram 11-4...
Page 123: I/F Mode (Sensorless)
In the option P0408 = 1 (No Rotation) the motor remains stopped throughout the self-tuning. The magnetizing current value (P0410) is obtained from a table, valid for WEG motors up to 12 poles. In the option P0408 = 2 (Run for I ) the value of P0410 is estimated with the motor rotating and the load decoupled from the motor shaft.
Page 124: Optimal Flux For Sensorless Vector Control
Active function only on the Sensorless Vector mode (P0202 = 3), if P0406 = 2. The Optimal Flux function can be used for driving some types of WEG motors (*) making it possible the operation at low speed with rated torque without the need of forced ventilation on the motor. The frequency range for operation is 12:1, i.e., from 5 Hz to 60 Hz for 60 Hz rated frequency motors and from 4.2 Hz to 50 Hz for...
Page 125: Torque Control
Vector Control NOTE! (*) WEG motors that can be used with the Optimal Flux function: Nema Premium Efficiency, Nema High Efficiency, IEC Premium Efficiency, IEC Top Premium Efficiency and "Alto Rendimento Plus". When this function is activating, the motor flux is controlled in a way to reduce their electric losses on slow speeds.
Page 126: Optimal Braking
Vector Control NOTE! For torque control in the sensorless vector mode (P0202 = 3), observe: - The torque limits (P0169/P0170) must be higher than 30 % to assure the motor starting. After the start and with the motor rotating above 3 Hz, they can be reduced, if necessary, to values below 30 %. - For torque control applications with frequencies until to 0 Hz, use the vector with encoder control mode (P0202 = 4).
Page 127 Vector Control The Optimal Braking makes it possible braking the motor with a higher torque than the one obtained with traditional methods, as for instance, the braking by the injection of direct current (DC braking). In the DC braking case, only the losses in the motor rotor are used to dissipate the energy stored as the mechanic load inertia, rejecting the total friction losses.
Page 128: Motor Data [43]
Vector Control 1 hp/0.75 kW, IV poles: η = 0.76 resulting in TB1 = 0.32. Examples: 20 hp/15.0 kW, IV poles: η = 0.86 resulting in TB1 = 0.16. Figure 11.3 - T x N curve for Optimal Braking with a typical 10 hp/7.5 kW motor, driven by an inverter with the torque adjusted at a value equal to the motor rated torque (a) Torque generated by the motor in normal operation, driven by the inverter in the "motor mode"...
Page 129 Vector Control P0398 – Motor Service Factor Adjustable 1.00 to 1.50 Factory 1.00 Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data Description: It is the continuous overload capability, i.e., a reserve of power that gives the motor the capability to withstand working in adverse conditions.
Page 130 Vector Control Description: Set it according to the used motor nameplate data, taking into consideration the motor voltage. In the Guided Start-up routine the value adjusted in P0401 automatically modifies the parameters related to the motor overload protection, according to the Table 11.2 on page 11-14.
Page 131: Parameter Groups
Vector Control Table 11.1 - P0404 (Motor Rated Power) setting Motor Rated Motor Rated P0404 P0404 Power (hp) Power (hp) 0.33 300.0 0.50 350.0 0.75 380.0 400.0 430.0 440.0 450.0 475.0 500.0 540.0 600.0 620.0 10.0 670.0 12.5 700.0 15.0 760.0 20.0 800.0...
Page 132 Vector Control P0406 – Motor Ventilation Adjustable 0 = Self-Ventilated Factory Range: 1 = Separate Ventilation Setting: 2 = Optimal Flux 3 = Extended Protection Properties: Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data Description: During the Oriented Start-up Routine, the value adjusted in P0406 changes the parameters related to the motor overload automatically, in the following manner: Table 11.2 - Motor overload protection modification in function of P0406 P0406...
Page 133: Adjustment Of The Parameters P0409 To P0412 Based On The Motor Data Sheet
Vector Control P0414 – Motor Magnetization Time Adjustable 0.000 to 9.999 s Factory 0.000 s Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data Description: This parameter allows setting a motor magnetization time different from 2 x P0412, and then this is the time the inverter takes into account to indicate the motor is general enabled (or magnetized) after receiving the general enable command.
Page 134 σls P0411 = Regardless of the connection type used on the motor and of the connection type indicated on the data sheet, parameters P0410 and P0412 are defined as: P0410=I P0412= T For conditions not included above, contact WEG. 11-16...
Page 135: Vector Control [29]
Vector Control 11.8 VECTOR CONTROL [29] 11.8.1 Speed Regulator [90] The parameters related to the CFW-11 speed regulator are presented in this group. P0160 – Speed Regulator Configuration Adjustable 0 = Normal Factory Range: 1 = Saturated Setting: Properties: CFG, PM and Vector Access groups 01 PARAMETER GROUPS via HMI:...
Page 136 Vector Control Procedure for Manual Optimization of the Speed Regulator: 1. Select the acceleration (P0100) and/or deceleration (P0101) time according to the application. 2. Adjust the speed reference for 75 % of the maximum value. 3. Configure an analog output (AOx) for Real Speed, by programming P0251, P0254, P0257 or P0260 in 2. 4.
Page 137: Current Regulator [91]
Vector Control P0165 – Speed Filter Adjustable 0.012 to 1.000 s Factory 0.012 s Range: Setting: Properties: PM and Vector Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 90 Speed Regulator Description: It sets the time constant of the motor speed filter either measured by the encoder when P0202 = 4, or estimated when P0202 = 3.
Page 138: Flux Regulator [92]
Vector Control P0168 – Current Regulator Integral Gain Adjustable 0.000 to 1.999 Factory 0.010 Range: Setting: Properties: Vector Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 91 Current Regulator Description: Parameters P0167 and P0168 are adjusted automatically as a function of the parameters P0411 and P0409, respectively.
Page 139 Vector Control P0177 – Minimum Flux Adjustable 0 to 120 % Factory 30 % Range: Setting: Properties: Sless Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 92 Flux Regulator Description: Minimum current value at the regulator output for sensorless control. NOTE! The P0177 parameter value is ignored when the energy saving function is enabled.
Page 140 Vector Control P0188 – Proportional Gain of the Maximum Output Voltage Regulator P0189 – Integral Gain of the Maximum Output Voltage Regulator Adjustable 0.000 to 7.999 Factory P0188 = 0.200 Range: Setting: P0189 = 0.001 Properties: Vector Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 92 Flux Regulator...
Page 141: I/F Control [93]
Vector Control 11.8.4 I/f Control [93] P0180 - Iq* After the I/f Adjustable 0 to 350 % Factory 10 % Range: Setting: Properties: Sless Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 93 Control I/f Description: It allows setting an offset in the torque current reference variable (Iq*) of the speed regulator in the first execution of this regulator after the transition from I/f mode to sensorless vector.
Page 142: Self-Tuning [05] And [94]
Vector with encoder P0413 P0408 = 1 – No rotation: The motor stands still during the self-tuning. The P0410 value is obtained from a table, valid for WEG motors up to 12 poles. NOTE! Therefore P0410 must be equal to zero before initiating the self-tuning. If P0410 ≠ 0, the self-tuning routine will keep the existent value.
Page 143 The parameter P0413 (Mechanic time constant – Tm) will be adjusted to a value close to the motor mechanic time constant. Therefore, the motor rotor inertia (table data valid for WEG motors), the inverter rated voltage and current are taken into consideration.
Page 144 WEG motors, when P0408 = 1 (No rotation). When a standard WEG motor is not used and it is not possible to run the self-tuning with P0408 = 2 (Run for I then adjust P0410 with a value equal to the motor no load current, before initiating the self-tuning.
Page 145 Vector Control P0411 – Motor Flux Leakage Inductance (σls) Adjustable 0.00 to 99.99 mH Factory 0.00 mH Range: Setting: Properties: CFG and Vector Access groups 01 PARAMETER GROUPS 05 SELF-TUNING via HMI: 29 Vector Control 94 Self-tuning Description: The value is automatically adjusted by the self-tuning (Section 11.3 SELF-TUNING on page 11-5).
Page 146 1.2 / 1.3 0.9 / 1.0 NOTE! When adjusted via the keypad (HMI), this parameter may change automatically the following parameters: P0175, P0176, P0327 and P0328. For motors larger than 500 CV, contact WEG. P0413 – T Constant (Mechanical Time Constant) Adjustable 0.00 to 99.99 s...
Page 147: Torque Current Limitation [95]
Vector Control Note: Values of P0161>12.0 may turn the torque current (I ) and the motor speed unstable (oscillating). Vector control with encoder (P0202 = 4): The load may be coupled to the motor shaft for this step of the routine. The P0413 value is estimated by the self-tuning when P0408 = 3 or 4.
Page 148: Dc Link Regulator [96]
Vector Control In the torque limitation condition the motor current can be calculated by: - P0410 x P0178 P0401 (Rated torque current) non_torque P0169* x I P0410 x P0178 nom_torque motor The maximum torque developed by the motor is given by: (%) = P0169 ∙ k motor Where the factor k is defined by:...
Page 149 Vector Control Table 11.8 - DC link regulation modes P0184 Action 0 = With losses The Optimal Braking is active as described at P0185. This assures the minimum possible decelera- (Optimal Braking) tion time without using dynamic or regenerative braking Automatic control of the deceleration ramp.
Page 150: Start-Up In The Vector Modes Sensorless And With Encoder
Vector Control P0186 – DC Link Voltage Regulation Proportional Gain Adjustable 0.0 to 63.9 Factory 18.0 Range: Setting: P0187 – DC Link Voltage Regulation Integral Gain Adjustable 0.000 to 9.999 Factory 0.002 Range: Setting: Properties: PM and Vector Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control...
Page 151 Vector Control Parameters related to the motor:  Program the contents of parameters from P0398, P0400 to P0406 directly with the motor nameplate data.  Options for the setting of parameters P0409 to P0412: - Automatic, with the inverter executing the self-tuning routine as selected in one of the P0408 options. - From the motor data sheet supplied by its manufacturer.
Page 152 Vector Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication - Monitoring Mode. - In this moment the Oriented Ready 0rpm - Press "Menu" Start-up routine is initiated (right "soft key"). and the "Config" status is indicated at the top left part 13:48 Menu of the keypad (HMI).
Page 153 Vector Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication - If necessary, change - If necessary, change the content of P0296 the content of P0402 according to the used line according to the rated Config 0rpm voltage. Therefore press motor speed.
Page 154 Vector Control Seq. Action/Result Display Indication At this point, the keypad (HMI) presents the option to run the "Self-Tuning". Whenever possible the Self- Tuning must be carried out. Config 0rpm - Thus, press "Select" to Motor Ventilation P0406: Self-Vent. access P0408 and then Run Self-Tuning P0408: No to select the...
Page 155: Functions Common To All The Control Modes
Functions Common to All the Control Modes 12 FUNCTIONS COMMON TO ALL THE CONTROL MODES This section describes the functions that are common to all the CFW-11 inverter control modes (V/f, VVW, Sensorless, and Encoder). 12.1 RAMPS [20] The inverter RAMPS functions allow the motor to accelerate and decelerate in a faster or a slower manner. P0100 –...
Page 156 Functions Common to All the Control Modes open DIx - Run/Stop Time ramp DIx open Time P0102 P0103 P0100 P0101 Motor Speed Time Figure 12.1 - Second ramp actuation In this example, the commutation to the 2nd ramp (P0102 or P0103) is done by means of one of the digital inputs from DI1 to DI8, provided that it had been programmed for 2nd ramp function (refer to the Item 13.1.3 Digital Inputs [40] on page...
Page 157: Speed References [21]
Functions Common to All the Control Modes P0105 – 1st/2nd Ramp Selection Adjustable 0 = 1 Ramp Factory Range: 1 = 2 Ramp Setting: 2 = DIx 3 = Serial/USB 4 = Anybus-CC 5 = CANopen/DeviceNet/Profibus DP 6 = SoftPLC 7 = PLC11 Properties: Access groups...
Page 158: Parameter Groups
Functions Common to All the Control Modes P0121 – Keypad Reference Adjustable 0 to 18000 rpm Factory 90 rpm Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 21 Speed References Description: When the HMI keys are active (P0221 or P0222 = 0), this parameter sets the value of the motor speed reference.
Page 159: Speed Limits [22]
Functions Common to All the Control Modes P0122 – JOG + Speed Reference P0123 – JOG - Speed Reference Adjustable 0 to 18000 rpm Factory 150 rpm Range: Setting: (125 rpm) Properties: PM and Vector Access groups 01 PARAMETER GROUPS via HMI: 21 Speed References Description:...
Page 160 Functions Common to All the Control Modes P0133 – Minimum Speed Reference Limit Adjustable 0 to 18000 rpm Factory 90 rpm Range: Setting: (75 rpm) P0134 – Maximum Speed Reference Limit Adjustable 0 to 18000 rpm Factory 1800 rpm Range: Setting: (1500 rpm) Properties:...
Page 161: Multispeed [36]
Functions Common to All the Control Modes 12.4 MULTISPEED [36] The MULTISPEED function is used when one wishes to have up to 8 predefined fixed speeds, which are commanded through the digital inputs (DI4, DI5 and DI6). P0124 – Multispeed Reference 1 Adjustable 0 to 18000 rpm Factory...
Page 162 Functions Common to All the Control Modes Description: The Multispeed brings as advantages the stability of the predefined fixed references, and the immunity against electric noises (isolated digital inputs DIx). In order to activate the Multispeed function one must configure the parameter P0221 = 8 and/or P0222 = 8 (Reference Selection).
Page 163: Electronic Potentiometer [37]
Functions Common to All the Control Modes 12.5 ELECTRONIC POTENTIOMETER [37] The ELECTRONIC POTENTIOMETER (E.P .) function allows that the speed reference be adjusted by means of 2 digital inputs (one for incrementing it and another for decrementing it). In order to enable this function, the speed reference must first be configured to be via E.P ., by setting P0221 = 7 and/or P0222 = 7.
Page 164: Zero Speed Logic [35]
Functions Common to All the Control Modes 12.6 ZERO SPEED LOGIC [35] This function allows the configuration of a speed in which the inverter will enter a stop condition (disable itself). It is recommended to use this function when the commands Run/Stop, Direction of Rotation, LOC/REM and JOG are generated by the keyboard (HMI) or by the digital inputs (DIx).
Page 165: Flying Start/Ride-Through [44]
Functions Common to All the Control Modes When the PID regulator is active (P0203 = 1) and in Automatic mode, for the inverter to leave the disable condition, besides the condition programmed in P0218, it is also necessary that the PID error (the difference between the Setpoint and the process variable) be higher than the value programmed in P0535.
Page 166: V/F Flying Start And Vvw
Functions Common to All the Control Modes 12.7.1 V/f Flying Start and VVW In the V/f and VVW mode, the inverter imposes a fixed frequency at the start, defined by the speed reference, and applies a voltage ramp defined at the parameter P0331. The Flying Start function will be activated after the time adjusted in P0332 elapses (to allow the motor demagnetization), every time a "Run"...
Page 167 Functions Common to All the Control Modes NOTE! When parameter P0229 is set to the stop by ramp condition, the speed detection is always performed after the activation of the of the inverter general enable. In case it is necessary to detect the speed whenever the motor is stopped, follow the instruction of parameter P0181 (magnetization mode).
Page 168 Functions Common to All the Control Modes The frequency variation rate is determined by: (P0329 x P0412). General Enable (with Run/Stop = on) or Run/Stop (with General Enable = on) H. Geral (c/ G/P=ON) ou G/P( c/ HG=ON) +24 V 24 v tempo time...
Page 169: P0202 = 4
Functions Common to All the Control Modes 12.7.2.2 P0202 = 4 During the time period when the motor is being magnetized, the identification of the motor speed occurs. Once the magnetization is finished, the motor will be operated starting from that speed until reaching the speed reference indicated in P0001.
Page 170: Vector Ride-Through
Functions Common to All the Control Modes P0331 – Voltage Ramp Adjustable 0.2 to 60.0 s Factory 2.0 s Range: Setting: Properties: V/f and VVW Access groups 01 PARAMETER GROUPS via HMI: 44 FlyStart/RideThru Description: This parameter sets the necessary time for the output voltage to reach the rated voltage value. It is used by the Flying Start function as well as by the Ride-Through function (both in V/f and VVW mode), together with the parameter P0332.
Page 171 Functions Common to All the Control Modes Back" (t4) level, defined at the parameter P0323. The motor will reaccelerate, following the adjusted ramp, from the actual speed value to the value defined by the speed reference (P0001) (refer to the Figure 12.8 on page 12-17).
Page 172 Functions Common to All the Control Modes P0321 – DC Link Power Loss Adjustable 178 to 282 V Factory 252 V (P0296 = 0) 308 to 616 V 436 V (P0296 = 1) Range: Setting: 308 to 616 V 459 V (P0296 = 2) 308 to 616 V 505 V (P0296 = 3) 308 to 616 V...
Page 173: Dc Braking [47]
Functions Common to All the Control Modes P0325 – Ride-Through Proportional Gain Adjustable 0.0 to 63.9 Factory 22.8 Range: Setting: P0326 – Ride-Through Integral Gain Adjustable 0.000 to 9.999 Factory 0.128 Range: Setting: Properties: Vector Access groups 01 PARAMETER GROUPS via HMI: 44 FlyStart/RideThru Description:...
Page 174 Functions Common to All the Control Modes P0299 - DC-Braking Start Time Adjustable 0.0 to 15.0 s Factory 0.0 s Range: Setting: Properties: V/f, VVW and Sless Access groups 01 PARAMETER GROUPS via HMI: 47 DC Braking Description: This parameter sets the DC braking time at starting. INJECTION OF DIRECT CURRENT AT STARTING Motor Speed...
Page 175 Functions Common to All the Control Modes (a) V/f scalar Motor Speed P0300 P0301 Time DEAD TIME +24 V DIx – Run/Stop Open (b) VVW and Sensorless Vector DC Current Injection Motor Speed P0300 P0301 Time +24 V DIx – Run/Stop Open Figure 12.11 - (a) and (b) - DC braking operation at the ramp disabling (via ramp disable) Figure 12.12 on page 12-21...
Page 176 Functions Common to All the Control Modes P0301 – DC-Braking Speed Adjustable 0 to 450 rpm Factory 30 rpm Range: Setting: Properties: V/f, VVW and Sless Access groups 01 PARAMETER GROUPS via HMI: 47 DC Braking Description: This parameter establishes the beginning point for the DC braking application at stopping. Refer to the Figure 12.11 on page 12-21 (a) and (b).
Page 177: Skip Speed [48]
Functions Common to All the Control Modes 12.9 SKIP SPEED [48] The parameters of this group prevent the motor from operating permanently at speed values where, for instance, the mechanic system enters in resonance (causing exaggerated vibration or noise). P0303 – Skip Speed 1 Adjustable 0 to 18000 rpm Factory...
Page 178: Search Of Zero Of The Encoder
Functions Common to All the Control Modes Motor speed P0305 2 x P0306 P0304 2 x P0306 P0303 Speed Reference Figure 12.13 - "Skip Speed" actuation curve 12.10 SEARCH OF ZERO OF THE ENCODER The zero search function attempts to synchronize the minimum counting or the maximum counting visualized in the parameter P0039.
Page 179 Functions Common to All the Control Modes P0192 – Status Encoder Zero Search Adjustable 0 = Off Factory Range: 1 = Finished Setting: Properties: RO V/f, VVW and Vector Access groups 00 ALL PARAMETERS via HMI: Description: On the inverter initialization, this parameter starts on zero. When the value is changed to 1 (Concluded), it indicates that the zero search function was executed, and this function returns to the state of Inactive, although P0191 continues equal to one (Active).
Page 180 Functions Common to All the Control Modes 12-26...
Page 181: Digital And Analog Inputs And Outputs
Digital and Analog Inputs and Outputs 13 DIGITAL AND ANALOG INPUTS AND OUTPUTS This section presents the parameters for the configuration of the CFW-11 inputs and outputs, as well as the parameters for the command of the inverter in the Local or Remote Situations. 13.1 I/O CONFIGURATION [07] 13.1.1 Analog Inputs [38] Two analog inputs (AI1 and AI2) are available in the CFW11 standard configuration, and two more can be...
Page 182 Digital and Analog Inputs and Outputs P0230 – Analog Input Dead Zone Adjustable 0 = Off Factory Range: 1 = On Setting: Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI: 38 Analog Inputs 38 Analog Inputs Description: This parameter acts only for the analog inputs (AIx) programmed as speed reference, and it defines if the Dead Zone at those inputs is On (1) or Off (0).
Page 183 Digital and Analog Inputs and Outputs P0231 – AI1 Signal Function P0236 – AI2 Signal Function P0241 – AI3 Signal Function Adjustable 0 = Speed Reference Factory 1 = N* Without Ramp Range: Setting: 2 = Maximum Torque Current 3 = Process Variable 4 = PTC 5 = Not Used 6 = Not Used...
Page 184 Digital and Analog Inputs and Outputs In order that the expressions which determine the total current and the maximum torque developed by the motor (Section 11.5 TORQUE CONTROL on page 11-7 Item 11.8.6 Torque Current Limitation [95] on page 11-29) remain valid, replace P0169, P0170 by P0018 to P0021.
Page 185 Digital and Analog Inputs and Outputs P0250 – AI4 Filter Adjustable 0.00 to 16.00 s Factory 0.00 s Range: Setting: Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI: 38 Analog Inputs 38 Analog Inputs Description: AI1’ - P0018 AI2’...
Page 186: Analog Outputs [39]
Digital and Analog Inputs and Outputs P0238 – AI2 Signal Type P0248 – AI4 Signal Type Adjustable 0 = 0 to 10 V/20 mA Factory Range: 1 = 4 to 20 mA Setting: 2 = 10 V/20 mA to 0 3 = 20 to 4 mA 4 = –10 V to +10 V Properties:...
Page 187 Digital and Analog Inputs and Outputs P0014 – AO1 Value P0015 – AO2 Value Adjustable 0.00 to 100.00 % Factory Range: Setting: P0016 – AO3 Value P0017 – AO4 Value Adjustable -100.00 to 100.00 % Factory Range: Setting: Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI:...
Page 188 Digital and Analog Inputs and Outputs P0257 – AO3 Function P0260 – AO4 Function Adjustable 0 = Speed Reference Factory P0257 = 2 1 = Total Reference Range: Setting: P0260 = 5 2 = Real Speed 3 = Torque Current Reference 4 = Torque Current 5 = Output Current 6 = Process Variable...
Page 189 Encoder Speed P0696 Value P0697 Value P0698 Value P0699 Value PLC11 Id* Current Exclusive WEG Use 24 to 71 24 to 71 * Factory Setting P0252 – AO1 Gain P0255 – AO2 Gain P0258 – AO3 Gain P0261 – AO4 Gain Adjustable 0.000 to 9.999...
Page 190 Digital and Analog Inputs and Outputs Function AO1 - P0251 AO2 - P0254 AO3 - P0257 AO4 - P0260 Speed Reference Total Reference Real Speed Torque Current Reference Torque Current Output Current Value Process Variable (PID) AO1 - P0014 AO2 - P0015 Active Current AO3 - P0016 AO4 - P0017...
Page 191 Digital and Analog Inputs and Outputs Table 13.4 - Full scale SCALE OF THE ANALOG OUTPUT INDICATIONS Variable Full Scale (*) Speed Reference Total Reference P0134 Real Speed Encoder Speed Torque Current Reference Torque Current 2.0 x I nomHD Torque Current > 0 Motor Torque 2.0 x I Output Current...
Page 192: Digital Inputs [40]
Digital and Analog Inputs and Outputs Table 13.5 - DIP switches related to the analog outputs Parameter Output Switch Location P0253 S1.1 Control Board P0256 S1.2 P0259 S2.1 P0262 S2.2 Table 13.6 - Configuration of the analog outputs AO1 and AO2 signals P0253, P0256 Output Signal Switch Position...
Page 193 Digital and Analog Inputs and Outputs The indication is done by means of the numbers 1 and 0, representing respectively the "Active" and "Inactive" states of the inputs. The state of each input is considered as one digit in the sequence where DI1 represents the least significant digit. Example: In case the sequence 10100010 is presented on the keypad (HMI), it will correspond to the following status of the DIs: Table 13.8 - Digital inputs status...
Page 194 Digital and Analog Inputs and Outputs Table 13.9 - Digital input functions P0263 P0264 P0265 P0266 P0267 P0268 P0269 P0270 Functions (DI1) (DI2) (DI3) (DI4) (DI5) (DI6) (DI7) (DI8) Not used 0, 13 and 23 0, 13 and 23 0*, 13 and 23 0* and 23 0 and 23 0 and 23 0*, 13 and 23 0*, 13 and 23...
Page 195 Digital and Analog Inputs and Outputs When Torque is selected, the speed regulator parameters P0161 and P0162 become inactive (*). Thus, the Total Reference becomes the input of the Torque Current Regulator. Refer to the Figure 11.1 on page 11-2 Figure 11.2 on page 11-4.
Page 196 Digital and Analog Inputs and Outputs Programming Off: when this function is programmed and the digital input is with +24 V, parameter changes will not be allowed, regardless of the values set at P0000 and P0200. When the DIx input is with 0 V, the parameter changes will be conditioned to the P0000 and P0200 settings.
Page 197 Digital and Analog Inputs and Outputs (a) RUN/STOP (b) GENERAL ENABLE Acceleration ramp Motor runs free (coasts) Deceleration Acceleration ramp ramp Motor speed Motor speed Time Time 24 V 24 V Open Open Time Time Note: All the digital inputs programmed for General Enable, Note: All the digital inputs programmed for Run/Stop, Fast Fast Stop, Forward Run or Reverse Run must be in the ON Stop, Forward Run or Reverse Run must be in the ON state,...
Page 198 Digital and Analog Inputs and Outputs (h) JOG JOG Speed (P0122) Motor speed Acceleration ramp Deceleration ramp Time 24 V Run/Stop Open Time 24 V DIx - JOG Open Time 24 V General enable Open Time (i) JOG + and JOG - JOG+ (P0122), JOG- (P0123) Speed Motor speed Time...
Page 199 Digital and Analog Inputs and Outputs (k) 3-WIRE START / STOP 24 V DIx - Start Open Time 24 V DIx - Stop Open Time Motor speed Time (l) FWD Run / REV Run 24 V DIx - Forward Open Time 24 V DIx - Reverse...
Page 200: Digital Outputs / Relays [41]
Digital and Analog Inputs and Outputs 13.1.4 Digital Outputs / Relays [41] The CFW-11 has 3 relay digital outputs as standard on its control board, and 2 more digital outputs of the open collector type that can be added with the accessories IOA-01 or IOB-01. The next parameters configure the functions related to those outputs.
Page 201 Digital and Analog Inputs and Outputs P0274 – Hysteresis for Torque Current – Iq Adjustable 0.00 to 9.99 % Factory 2.00 % Range: Setting: Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI: 41 Digital Outputs 41 Digital Outputs Description: It establishes the percentage of hysteresis applied to the commutation of a digital or relay output DOx when they are programmed in options 43 or 44.
Page 202 Digital and Analog Inputs and Outputs Table 13.11 - Digital output functions P0275 P0276 P0277 P0278 P0279 Functions (DO1) (DO2) (DO3) (DO4) (DO5) 0, 29, 37, 38, 39, 0, 29, 37, 38, 39, Not Used 0 and 29 40, 41 and 42 40, 41 and 42 N* >...
Page 203 Digital and Analog Inputs and Outputs "Torque" corresponds to the motor torque as indicated at parameter P0009. - Remote: it means that the inverter is operating in Remote situation. - Run: it corresponds to enabled inverter. In this moment the IGBTs are commutating, and the motor may be at any speed, inclusive zero.
Page 204 Digital and Analog Inputs and Outputs - No F160: It signalizes that the inverter is not disabled by F160 fault (Safety Stop Relay); - No Alarm: it means that the inverter in not in the alarm condition. - No Fault and No Alarm: it means that the inverter is not disabled by any type of fault and it is not in alarm condition. - PLC11: This option configures the signal at the DO1 (RL1), DO2 (RL2) and DO3 (RL3) outputs to be used by the PLC11.
Page 205 Digital and Analog Inputs and Outputs On the master CFW11: On the slave CFW11: (Vector with Encoder) (Vector with Encoder) P0275, P0276, P0277, P0278 or P0279 = 43 or 44 P0100 = P0101 = 0 P0273 = 0.1 s P0160 = 1 P0274 = 2.00 % P0223 = P0226 = DIx = 4 P0251 = 2...
Page 206 Digital and Analog Inputs and Outputs Definitions of the symbols used in the function: N = P0002 (Motor Speed). N* = P0001 (Speed Reference). Nx = P0288 (Nx Speed) – It is a reference point of the speed selected by the user. Ny = P0289 (Ny Speed) –...
Page 207 Digital and Analog Inputs and Outputs (b) N > Nx (a) N* > Nx P0287 Nx (P0288) Nx (P0288) Time P0287 Time Relay/ Relay/ Transistor Transistor OFF (c) N < Ny (d) N = N* P0287 Ny (P0289) Time P0287 Time Relay/ Transistor ON...
Page 208 Digital and Analog Inputs and Outputs (e) N = 0 (Zero) Speed (f) Is > Ix Speed P0291 Ix (P0290) Time Relay/ Relay/ Transistor OFF Transistor (g) Is < Ix (h) Torque > Tx Motor Torque (P0009) Ix (P0290) Tx (P0293) Time Time Relay/...
Page 209 Digital and Analog Inputs and Outputs (m) Process Variable < PVy (l) Process Variable > PVx VPx (P0533) VPy (P0534) Time Time Process Process Variable Variable Relay/ Relay/ Transistor Transistor (n) Pre-Charge Ok (o) Time enabled > Hx 6553 h DC Link Hx (P0294) Pre-charge...
Page 210 Digital and Analog Inputs and Outputs P0281 – Fx Frequency Adjustable 0.0 to 300.0 Hz Factory 4.0 Hz Range: Setting: Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI: 41 Digital Outputs 41 Digital Outputs Description: It is used in the digital output and relay functions: F>Fx and F>Fx P0282 –...
Page 211 Digital and Analog Inputs and Outputs P0287 – Hysteresis for Nx and Ny Adjustable 0 to 900 rpm Factory 18 rpm Range: Setting: (15 rpm) Properties: Access groups 07 I/O CONFIGURATION 01 PARAMETER GROUPS via HMI: 41 Digital Outputs 41 Digital Outputs Description: It is used in the N >...
Page 212 Digital and Analog Inputs and Outputs Description: It specifies the value in rpm, ± 1 % of the motor rated speed (hysteresis), below which the actual speed will be considered null for the Zero Speed Disable function. This parameter is also used by the functions of the digital and relay outputs, and by the PID regulator. The hysteresis is ±...
Page 213: Local And Remote Command
Digital and Analog Inputs and Outputs 13.2 LOCAL AND REMOTE COMMAND In those parameter groups one can configure the origin of the main inverter commands when in the LOCAL or in the REMOTE situation, as the Speed Reference, Speed Direction, Run/Stop and JOG. P0220 –...
Page 214: Parameter Groups
Digital and Analog Inputs and Outputs Description: They define the origin of the Speed Reference in the LOCAL situation and in the REMOTE situation. Some notes about the options for those parameters: The AIx’ designation refers to the analog signal obtained after the addition of the AIx input to the offset and its multiplication by the applied gain (refer to the Item 13.1.1 Analog Inputs [38] on page 13-1).
Page 215 Digital and Analog Inputs and Outputs P0224 – Run/Stop Selection – LOCAL Situation P0227 – Run/Stop Selection - REMOTE Situation Adjustable Factory P0224 = 0 0 = Keys Range: Setting: P0227 = 1 1 = DIx 2 = Serial/USB 3 = Anybus-CC 4 = CANopen/DeviceNet/Profibus DP 5 = SoftPLC 6 = PLC11...
Page 216 Digital and Analog Inputs and Outputs P0229 – Stop Mode Selection Adjustable 0 = Ramp to Stop Factory 1 = Coast to Stop Range: Setting: 2 = Fast Stop 3 = By Ramp with Iq* 4 = Fast Stop with Iq* Properties: Access groups 01 PARAMETER GROUPS...
Page 217 Digital and Analog Inputs and Outputs (*) Valid only for P0202 = 3 and 4. Figure 13.10 - Speed Reference block diagram 13-37...
Page 218: 3-Wire Command [33]
Digital and Analog Inputs and Outputs LOCAL REFERENCE (P0221) FORWARD/REVERSE (P0220) (P0223) LOCAL/REMOTE Selection LOCAL RUN/STOP (P0224) REFERENCE JOG (P0225) REFERENCE REFERENCE REMOTE REFERENCE LOCAL COMMANDS COMMANDS REMOTE COMMANDS REMOTE COMMANDS REFERENCE (P0222) FORWARD/REVERSE (P0226) RUN/STOP (P0227) JOG (P0228) Figure 13.11 - Local/Remote situation block diagram 13.3 3-WIRE COMMAND [33] The group defined as "3-Wire Command"...
Page 219: Dynamic Braking
Dynamic Braking 14 DYNAMIC BRAKING The braking torque that can be obtained through the application of frequency inverters without dynamic braking resistors varies from 10 % to 35 % of the motor rated torque. In order to obtain higher braking torques, resistors for dynamic braking are used. In this case the regenerated energy is dissipated on the resistor mounted externally to the inverter.
Page 220 Dynamic Braking The next table presents the overvoltage trip level. Table 14.1 - Overvoltage (F022) trip levels Inverter V P0296 F022 220/230 V > 400 V 380 V 400/415 V > 800 V 440/460 V 480 V 500/525 V 550/575 V >...
Page 221 Dynamic Braking P0155 – Dynamic Braking Resistor Power Adjustable 0.02 to 650.00 kW Factory 2.60 kW Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 28 Dynamic Braking Description: This parameter adjusts the trip level of the braking resistor overload protection. It must be set according to the used braking resistor rated power (in kW).
Page 222 Dynamic Braking 14-4...
Page 223: Faults And Alarms
Faults and Alarms 15 FAULTS AND ALARMS The troubleshooting structure of the inverter is based on the indication of faults and alarms. In a fault event the IGBTs firing pulses are disabled and the motor coasts to stop. The alarm works as a warning to the user that critical operation conditions are occurring and a fault may occur if the situation does not change.
Page 224: Motor Overtemperature Protection
Faults and Alarms NOTE! In order to assure the conformity of the CFW-11 motor overload protection with the UL508C standard, observe the following: The "TRIP" current is equal to 1.25 times the motor nominal current (P0401) adjust in the "Oriented Start-up" menu. The maximum allowed value for P0398 (Motor Service Factor) is 1.15.
Page 225 Faults and Alarms (a) AO1, AI1 XC1: Program P0231 = 4. Set S1.4 = OFF (0 to 10 V). Program P0251 = 13. Set S1.1 = OFF (4 to 20 mA, 0 to 20 mA). CC11 (b) AO2, AI2 Program P0236 = 4. Set S1.3 = OFF (0 to ±...
Page 226: Protections [45]
Faults and Alarms 15.3 PROTECTIONS [45] The parameters related to motor and inverter protections are found in this group. P0030 – U Arm IGBT Temperature P0031 – V Arm IGBT Temperature P0032 – W Arm IGBT Temperature P0033 – Rectifier Temperature P0034 –...
Page 227 Faults and Alarms Description: These parameters are used for the motor overload protection (I x t – F072). The motor overload current (P0156, P0157 and P0158) is the value from which the inverter starts considering that the motor is operating with overload. The bigger the difference between the motor current and the overload current, the faster F072 trip will occur.
Page 228 Faults and Alarms P0159 – Motor Thermal Class Adjustable 0 = Class 5 Factory Range: 1 = Class 10 Setting: 2 = Class 15 3 = Class 20 4 = Class 25 5 = Class 30 6 = Class 35 7 = Class 40 8 = Class 45 Properties:...
Page 229 Faults and Alarms Example: For a motor with the following characteristics, = 10.8 A = 4 s (hot motor blocked rotor time) = 7.8 ⇒ I = 7.8 x 10.8 A= 84.2 A SF = 1.15 one gets, 84.2 Overload Current = x 100 = 678 % x SF 10.8 x 1.15...
Page 230 Faults and Alarms Overload Time 100000 10000 1000 Class 45 Class 40 Class 35 Class 30 Class 25 Class 20 Class 15 Class 10 Class 5 Current x In for F.S. = 1.00 Current x In for F.S. = 1.15 (b) - Hot motor overload curves for loads of the HD and ND types Figure 15.3 - (a) and (b) - Cold and hot motor overload curves for loads of the HD and ND types For the previous example, by plotting the 678 % value (x axis) of the Overload Current with the 4 seconds (y axis) of the Overload...
Page 231: Parameter Groups
Faults and Alarms NOTE! The faults F051, F078, F156, F301, F304, F307, F310, F313, F316, F319, F322, F325, F328, F331, F334, F337, F340 and F343 allow a conditional Reset, i.e., the Reset will only occur if the temperature gets back to the normal operation range. If after Auto-Reset, the same fault is repeated three times consecutively, the Auto-Reset function will be disabled.
Page 232 Faults and Alarms P0343 – Ground Fault Detection Adjustable 0 = Off Factory Range: 1 = On Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 45 Protections Description: This parameter enables the Ground Fault Detection, which will be responsible for the F074 (Ground Fault) actuation. Thus if wished, it is possible to inhibit the Ground Fault (F074) occurrence by setting P0343 = Off.
Page 233 Faults and Alarms Description: This parameter defines the level for the motor overload protection alarm actuation (A046), it is expressed as a percentage of the trip level of the overload integrator. It will only be effective if P0348 is programmed in 1 (Fault/Alarm) or 3 (Alarm). P0350 –...
Page 234 Faults and Alarms Table 15.4 - Actions for the parameter P0351 options P0351 Action The overtemperature protection is disabled. Faults or alarms for the motor operation in the 0 = Off overtemperature condition will not be generated The inverter will show an alarm (A110) and will generate a fault (F078) when the motor reaches 1 = Fault / Alarm the overtemperature actuation values.
Page 235 Faults and Alarms Table 15.5 - Options of the parameter P0352 P0352 Action Heatsink fan is always OFF 0 = HS-OFF, Int-OFF Internal fan is always OFF Heatsink fan is always ON 1 = HS-ON, Int-ON Internal fan is always ON Heatsink fan is controlled via software 2 = HS-CT, Int-CT Internal fan is controlled via software...
Page 236 Faults and Alarms Table 15.6 - Options of the parameter P0353 P0353 Action Enables fault (F051) – IGBT Overtemperature and alarm (A050) – IGBT High Temperature Enables fault (F153) – Internal Air Overtemperature and alarm (A152) – Internal Air High 0 = HS-F/A, Air-F/A Temperature Enable Alarm of Overtemperature on the Rectifier (A010)
Page 237 Faults and Alarms Description: This parameter allows disabling the actuation of F185 fault – Fault in the preload contactor. If P0355 = 0, the Fault in the preload contactor will remain deactivated. F185 fault will not be generated. When the inverter is a frame size E with DC power supply it’s necessary to adjust P0355 = 0. P0356 –...
Page 238 Faults and Alarms P0358 – Encoder Fault Configuration Adjustable 0 = Off Factory Range: 1 = F067 ON Setting: 2 = F065, F066 active 3 = All active Properties: CFG and Encoder Access groups 01 PARAMETER GROUPS via HMI: 45 Protections Description: This parameter allows disabling the fault detection by software: a) F067 –...
Page 239 Faults and Alarms P0362 – Motor Stop Time Fault Adjustable 0 to 999 s Factory 20 s Range: Setting: Properties: V/f, VVW, Vector and PM Access groups 01 PARAMETER GROUPS 01 PARAMETER GROUPS via HMI: 20 Ramps 45 Protections Description: This parameter defines the time to generate fault F028 in the motor stop command.
Page 240 Faults and Alarms P0814 – Phase W Book 5 Temperature Adjustable -20.0 °C to 150.0 °C Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS 09 READ ONLY PARAMETERS via HMI: 45 Protections Description: These read only parameters indicate, in Celsius degrees (°C), the internal temperature of the IGBTs of each phase of each book.
Page 241: Motor Overtemperature Protection Using The Ioe-01, Ioe-02 Or Ioe-03 Module
Faults and Alarms 15.4 MOTOR OVERTEMPERATURE PROTECTION USING THE IOE-01, IOE-02 OR IOE-03 MODULE For each type of temperature sensor, PTC, PT100 or KTY84, there is an optional module associated, IOE-01, IOE-02 or IOE-03, respectively. P0374 - Sensor 1 Temperature Fault/Alarm Configuration P0377 - Sensor 2 Temperature Fault/Alarm Configuration P0380 - Sensor 3 Temperature Fault/Alarm Configuration P0383 - Sensor 4 Temperature Fault/Alarm Configuration...
Page 242: Ptc Type Temperature Sensor
Faults and Alarms 15.4.1 PTC Type Temperature Sensor The next parameters will be shown on the HMI when the IOE-01 module is connected into the slot 1 (XC41 connector). Refer to the Figure 3.1 on page 3-2. P0373 - PTC 1 Sensor Type P0376 - PTC 2 Sensor Type P0379 - PTC 3 Sensor Type P0382 - PTC 4 Sensor Type...
Page 243 Faults and Alarms P0388 - Sensor 1 Temperature P0389 - Sensor 2 Temperature P0390 - Sensor 3 Temperature P0391 - Sensor 4 Temperature P0392 - Sensor 5 Temperature Description: These parameters indicate, in Celsius degrees, the PT100 or KTY84 sensor temperatures. P0393 - Highest Sensor Temperature Adjustable -20 to 200 ºC...
Page 244 Faults and Alarms P0394 – Alarm Temperature Broken Cable Adjustable -20 to 200 ºC Factory -20 °C Range: Setting: Properties: Grupos de 01 PARAMETER GROUPS acesso via HMI: 45 Protections Description: This parameter detects breaks in the sensor cable (SEN1 to SEN5 of connector XC12) of PT100 (IOE-02) or KTY84 (IOE-03) through the temperature value set in P0394.
Page 245: Read Only Parameters [09]
Read Only Parameters [09] 16 READ ONLY PARAMETERS [09] In order to facilitate the visualization of the main reading variables of the inverter, the group [09] - "Read Only Parameters" can be accessed directly. It is important to point out that all the parameters of that group can only be visualized on the keypad (HMI) display, and that they do not allow changes by the user.
Page 246 Read Only Parameters [09] P0003 – Motor Current Adjustable 0.0 to 4500.0 A Factory Range: Setting: Properties: Access groups 09 READ ONLY PARAMETERS via HMI: Description: It indicates the inverter output current in Amps (A), by means of 1.0 second filter. P0004 –...
Page 247 Read Only Parameters [09] Description: It indicates one of the 8 possible inverter states. The description of each state is presented in the next table. In order to facilitate the visualization, the inverter status is also showed on the top left corner of the keypad (HMI) (Figure 5.3 on page 5-10 –...
Page 248 Read Only Parameters [09] x 100 x Y P0009 = P0410 x P0178 2 0.5 1) P0202 ≠ 3: I = P0401 in V/f or VVW the adjusts are: P0178 = 100 % and P0190 = 0.95 x P0400 2) P0202 = 3 or 4: The motor torque (P0009) in percentage in the operating condition of permanent duty is given by: - P0410 x P0178 P0003...
Page 249 Read Only Parameters [09] P0011 – Cos Phi of the Output Adjustable 0.00 to 1.00 Factory Range: Setting: Properties: Access groups 09 READ ONLY PARAMETERS via HMI: Description: This parameter indicates the value of the cosine of the angle between the voltage and output current. The electric motor are inductive loads and, therefore, consumes reactive power.
Page 250 Read Only Parameters [09] P0030 – Temperature IGBTs U P0031 – Temperature IGBTs V P0032 – Temperature IGBTs W P0033 – Temperature of the Rectifier Adjustable -20.0 to 150.0°C Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 45 Protections 09 Read only Description:...
Page 251 Read Only Parameters [09] Description: It indicates the heatsink fan actual speed, in revolutions per minute (rpm). NOTE! This parameter has no function in mechanics of Modular Drive. P0037 – Motor Overload Status Adjustable 0 to 100 % Factory Range: Setting: Properties: Access groups...
Page 252 Read Only Parameters [09] P0040 – PID Process Variable P0041 – PID Setpoint Value Refer to the Section 20.6 PARAMETERS on page 20-9, for more details. P0042 – Time Powered Adjustable 0 to 65535 h Factory Range: Setting: Properties: Access groups 09 READ ONLY PARAMETERS via HMI: Description:...
Page 253 Read Only Parameters [09] Description: It indicates the energy consumed by the motor. It indicates up to 65535 kWh, and then it gets back to zero. By setting P0204 = 4, the value of the parameter P0044 is reset to zero. This value is kept even when power is removed from the inverter.
Page 254: Fault History [08]
-32768 to 32767 Factory Range: Setting: Properties: Access groups 09 READING PARAMETERS via HMI: Description: It indicates the number of the inverter firmware version for Weg's internal control. P0614 – PLD Revision Adjustable -32768 to 32767 Factory Range: Setting: Properties: Access groups...
Page 255 Read Only Parameters [09] P0050 – Last Fault P0054 – Second Fault P0058 – Third Fault P0062 – Fourth Fault P0066 – Fifth Fault P0070 – Sixth Fault P0074 – Seventh Fault P0078 – Eighth Fault P0082 – Ninth Fault P0086 –...
Page 256 Read Only Parameters [09] P0083 – Ninth Fault Day/Month P0087 – Tenth Fault Day/Month Adjustable 00/00 to 31/12 Factory Range: Setting: Properties: Access groups 08 FAULT HISTORY via HMI: Description: They indicate the day and the month of the last to the tenth fault occurrence. P0052 –...
Page 257 Read Only Parameters [09] P0053 – Last Fault Time P0057 – Second Fault Time P0061 – Third Fault Time P0065 – Fourth Fault Time P0069 – Fifth Fault Time P0073 – Sixth Fault Time P0077 – Seventh Fault Time P0081 – Eighth Fault Time P0085 –...
Page 258 Read Only Parameters [09] P0091 – DC Link Voltage at the Moment of the Last Fault Adjustable 0 to 2000 V Factory Range: Setting: Properties: Access groups 08 FAULT HISTORY via HMI: Description: It is the record of the inverter DC link voltage at the moment of the last fault occurrence. P0092 –...
Page 259 Read Only Parameters [09] P0095 – Motor Voltage at the Moment of the Last Fault Adjustable 0 to 2000 V Factory Range: Setting: Properties: Access groups 08 FAULT HISTORY via HMI: Description: It is the record of the motor voltage at the moment of the last fault occurrence. P0096 –...
Page 260 Read Only Parameters [09] Description: It indicates the state of the digital outputs at the moment of the last fault occurrence. The indication is done by means of an hexadecimal code, which when converted to binary will indicate the states "active"...
Page 261: Parameter Groups
Read Only Parameters [09] P0814 – Phase W Book 5 Temperature Adjustable -20.0 to 150.0°C Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 45 Protections 09 Read only Description: These reading parameters indicate, in Celsius degrees (ºC), the internal temperature of the IGBTs of each phase. In a modular drive, this information is shown for each Book, and for frame H it is shown for each IGBT module.
Page 262 Read Only Parameters [09] 16-18...
Page 263: Communication [49]
P0683 – Serial / USB Speed Reference Those are parameters for the configuration and operation of the RS-232 and RS-485 serial interfaces. For a detailed description, refer to the RS-232/RS-485 communication manual, available in www.weg.net. 17.2 CAN INTERFACE – CANOPEN/DEVICENET P0684 –...
Page 264: Anybus-Cc Interface
P0722 – CANopen Node Status Those are parameters for the configuration and operation of the CAN interface. For a detailed description, refer to the CANopen communication manual or to the DeviceNet communication manual, available in www.weg.net. 17.3 ANYBUS-CC INTERFACE P0686 – Anybus-CC Control Word P0687 –...
Page 265 Communication [49] P0733 – Anybus Reading Word #8 P0734 – Anybus Writing Word #3 P0735 – Anybus Writing Word #4 P0736 – Anybus Writing Word #5 P0737 – Anybus Writing Word #6 P0738 – Anybus Writing Word #7 P0739 – Anybus Writing Word #8 P0741 –...
Page 266: Profibus Dp Interface
P0968 – PROFIdrive Status Word Those are parameters for the configuration and operation of the Anybus-CC interface. For a detailed description, refer to the Anybus-CC communication manual, available in www.weg.net. 17.4 PROFIBUS DP INTERFACE P0684 – Control Word via CANopen/DeviceNet/Profibus DP P0685 –...
Page 267: Communication States And Commands
P0968 – Status Word 1 Those are parameters for the configuration and operation of the Profibus DP interface. For a detailed description, refer to the Profibus DP communication manual, available in www.weg.net. 17.5 COMMUNICATION STATES AND COMMANDS P0313 – Communication Error Action P0680 –...
Page 268 P0799 – I/O Update Delay Those parameters are used for monitoring and controlling the CFW-11 inverter by means of communication interfaces. For a detailed description, refer to the communication manual of the used interface. These manuals are available in www.weg.net. 17-6...
Page 269: Softplc [50]
SoftPLC [50] 18 SOFTPLC [50] 18.1 SOFTPLC The SoftPLC function allows the frequency inverter to assume PLC (Programmable Logical Controller) functions. For more details regarding the programming of those functions in the CFW-11, refer to the CFW-11 SoftPLC manual. The parameters related to the SoftPLC are described next. P1000 –...
Page 270: Digital Outputs [41]
SoftPLC [50] P0025 – DI9 to DI16 Status Adjustable Bit 0 = DI9 Factory Range: Bit 1 = DI10 Setting: Bit 2 = DI11 Bit 3 = DI12 Bit 4 = DI13 Bit 5 = DI14 Bit 6 = DI15 Bit 7 = DI16 Properties: Access groups...
Page 271: Trace Function [52]
Trace Function [52] 19 TRACE FUNCTION [52] 19.1 TRACE FUNCTION The trace function is used to record variables of interest from the CFW-11 (as current, voltage, speed) when a particular event occurs in the system (e.g.: alarm/fault, high current, etc.). This system event, for starting the data recording process, is called "trigger".
Page 272 Trace Function [52] Description: It defines the value for comparison with the variable selected in P0550. The full range of the variables selectable as trigger is presented in the next table. Table 19.1 - Full scale of the variables selectable as trigger Variable Full Scale Speed Reference...
Page 273 Trace Function [52] - If P0552≠6 and any DI is configured for "Trace Function", the trigger will never occur as a result of the DI activation. - These three programming options do not prevent the inverter from being enabled. P0553 – Trace Sampling Period Adjustable 1 to 65535 Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 52 Trace Function Description: It defines the sampling period (time between two sampling points) as a 200 µs multiple.
Page 274 Trace Function [52] P0560 – Trace Available Memory Adjustable 0 to 100 % Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 52 Trace Function Description: It shows the amount of memory available for storing Trace Function points. The range from 0 to 100 % indicates that from 0 to 15 KB are available for the Trace Function.
Page 275 Trace Function [52] Description: They select the signals that will be recorded at the channels 1 to 4 of the Trace Function. The options are the same that are available at P0550. By selecting the "Not Selected" option, the total memory available for the Trace function is distributed between the active channels.
Page 276 Trace Function [52] Description: P0572 to P0575 record the date and hour of the trigger occurrence. These parameters and the points acquired by the Trace Function are not saved when the inverter is powered off. There are two possibilities for P0572 to P0575 being null: - No acquisition was performed after the inverter power on, or.
Page 277: Pid Regulator [46]
PID Regulator [46] 20 PID REGULATOR [46] 20.1 DESCRIPTION AND DEFINITIONS The CFW-11 has the special function PID REGULATOR, which can be used to control a closed loop process. This function places a proportional, integral and derivative regulator, superposed to the normal CFW-11 speed control.
Page 278 PID Regulator [46] Figure 20.1 - PID Regulator function block diagram 20-2...
Page 279: Commissioning
PID Regulator [46] 20.2 COMMISSIONING Before doing a detailed description of the parameters related to this function, a step by step guide for putting the PID into operation will be presented. NOTE! In order that the PID function works properly, it is fundamental to verify if the inverter is configured correctly to drive the motor at the desired speed.
Page 280 PID Regulator [46] (a) Direct Process Variable P0040 Direct PID (P0527 = 0) Set Point P0041 ed = P0041 - P0040 (%) P0535 (b) Reverse Process Variable Reverse PID (P0527 = 1) P0040 P0535 er = P0040 - P0041 (%) P0041 Set Point (c) Sleep Mode...
Page 281 PID Regulator [46] Example: - Full scale of the transducer (maximum output value) = 25 bar (FS = 25); - Operation range (range of interest) = 0 to 15 bar (OR = 15). Opting to maintain P0237 = 1.000 and P0239 = 0 (factory setting), which is the most common for most of the applications: - P0525 = 50 % (Keypad PID setpoint) will be equivalent to the used sensor full scale value, i.e., 0.5 x FS = 12.5 bar.
Page 282 PID Regulator [46] Example: Given a pressure transducer with a 4 to 20 mA output and a full scale of 25 bar (i.e., 4 mA = 0 bar and 20 mA = 25 bar) and P0237=2.000. If it is wished to control 10 bar, the following setpoint must be entered: x 2 x 100 % = 80 % Setpoint (%) = In case the setpoint is defined via analog input (AI1 for instance), P0231 must be configured = 0 (AI1 Signal Function:...
Page 283 PID Regulator [46] As a summary of this guide, a schematic of the connections of the CFW-11 for the PID regulator application, as well as the setting of the parameters used in this example, are presented next. 4-20 mA Pressure Transducer 0-25 bar Setpoint...
Page 284: Sleep Mode
PID Regulator [46] 20.3 SLEEP MODE The sleep mode is a useful resource for saving energy when using the PID regulator. Refer to the Figure 20.2 on page 20-4. In many PID applications energy is wasted by keeping the motor turning at the minimum speed when, for instance, the pressure or the tank level keeps increasing.
Page 285: Connection Of A 2-Wire Transducer
PID Regulator [46] 20.5 CONNECTION OF A 2-WIRE TRANSDUCER In the 2-wire configuration the transducer signal and its supply share the same wires. The Figure 20.5 on page 20-9 illustrates this type of connection. Setpoint via keypad 24VCC CFW-11 DGND +REF AI1+ AI1-...
Page 286 PID Regulator [46] P0203 – Special Function Selection Adjustable 0 = None Factory Range: 1 = PID Regulator Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 46 Regulador PID Description: It enables the use of the PID Regulator special function, when set to 1. When P0203 is changed to 1, the following parameters are changed automatically: P0205 = 10 (Reading Parameter Selection 1).
Page 287: Parameter Groups
PID Regulator [46] Table 20.3 - Suggestions for PID regulator gain settings Gains Quantity Proportional Integral Differential P0520 P0521 P0522 Pneumatic system pressure 0.043 0.000 Pneumatic system flow 0.037 0.000 Hydraulic system pressure 0.043 0.000 Hydraulic system flow 0.037 0.000 Temperature 0.004 0.000...
Page 288 PID Regulator [46] Description: It selects the regulator feedback input (process variable). After choosing the feedback input, the function of the selected input must be programmed at P0231 (for AI1), P0236 (for AI2), P0241 (for AI3) or P0246 (for AI4). P0525 –...
Page 289 PID Regulator [46] P0529 – Process Variable Decimal Point Adjustable 0 = wxyz Factory Range: 1 = wxy.z Setting: 2 = wx.yz 3 = w.xyz Properties: Access groups 01 PARAMETER GROUPS via HMI: 46 PID Regulator Description: Those parameters define how the process variable (P0040) and the PID Setpoint (P0041) will be shown. The parameter P0529 defines the number of decimal places after the dot.
Page 290 PID Regulator [46] P0530 – Process Variable Engineering Unit 1 P0531 – Process Variable Engineering Unit 2 P0532 – Process Variable Engineering Unit 3 Adjustable 32 to 127 Factory P0530 = 37 Range: Setting: P0531 = 32 P0532 = 32 Properties: Access groups 01 PARAMETER GROUPS...
Page 291 PID Regulator [46] P0535 – Wake Up Band Adjustable 0 to 100 % Factory Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 46 PID Regulator Description: The parameter P0535 works together with the parameter P0218 (Condition to Leave the Zero Speed Disable), giving the additional condition for leaving the Zero Speed Disable.
Page 292: Academic Pid
PID Regulator [46] 20.7 ACADEMIC PID The controller implemented in the CFW-11 is of the academic type. The equations that characterize the Academic PID, which is the base of this function algorithm, are presented next. The transfer function in the Academic PID regulator frequency dominion is: y(s) = Kp x e(s) x [ 1 + + sTd] By replacing the integrator by a sum and the derivative by the incremental quotient, one gets an approximation for...
Page 293: Pm Vector Control
PM Vector Control 21 PM VECTOR CONTROL 21.1 PERMANENT MAGNET SYNCHRONOUS MOTORS (PMSM) Permanent magnet synchronous motors are alternating current motors with three-phase stator winding, similar to the induction motor, and permanent magnet rotor. PMSM for industrial applications have sinusoidal CEMF and feeding current, so that the developed torque is smooth.
Page 294: Sensorless Pm - P0202 = 7
PM Vector Control 21.2.1 Sensorless PM - P0202 = 7 The Sensorless PM control uses two rotor position estimation methods, the method for low speed injects a signal with a frequency of ±1 kHz, which causes an increase in the acoustic noise, and the method for higher speeds is based on the output voltages and currents.
Page 295: Pm With Encoder - P0202 = 6
PM Vector Control 21.2.2 PM with Encoder - P0202 = 6 The PM with encoder control presents the advantages described for the Sensorless control, plus a speed control accuracy of 0.01 % (by using the 14-bit analog reference via IOA-01, or by digital references via HMI, Profibus DP , DeviceNet).
Page 296: Modified Functions
PM Vector Control 21.2.3 Modified Functions Almost all the functions presented in this manual remain active when the options 6 or 7 are programmed in P0202. The functions no longer active or that suffered any modification are described in the Section 21.3 PROGRAMMING BASIC INSTRUCTIONS –...
Page 297 PM Vector Control Torque control range: 10 % to 180 %. Accuracy: ± 5 % of the rated torque. When the speed regulator is positively or negatively saturated, then P0169 and P0170 limit the torque current, respectively. The torque, in percentage, at the motor shaft (showed at P0009) is given by: Iq* x P0401 motor Where Iq* (in Volts) is the value read at the analog outputs AO1...
Page 298: Motor Data [43] And Self-Tuning [05] And [94]
PM Vector Control 21.6 MOTOR DATA [43] AND SELF-TUNING [05] AND [94] The parameters for the used motor data setting are listed in this group. They must be adjusted according to the motor nameplate data, except P0405. P0398 – Motor Service Factor P0400 –...
Page 299 PM Vector Control P0404 – Motor Rated Power P0405 – Number of Encoder Pulses P0408 - Run Self-Tuning The function is inactive. P0409 – Motor Stator Resistance (Rs) Adjustable 0.000 to 9.999 ohm Factory 0.000 ohm Range: Setting: Properties: CFG, PM, Vector and VVW Access groups 01 PARAMETER GROUPS 05 SELF-TUNING...
Page 300 PM Vector Control P0433 – Lq Inductance P0434 – Ld Inductance Adjustable 0 to 100.00 mH Factory 0.00 mH Range: Setting: Properties: Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data P0442 – Inductance Lq - CT P0443 – Inductance Lq - CT Adjustable 0.0 to 400.0 mH Factory...
Page 301: Pm Vector Control [29]
PM Vector Control P0444 – Constant Ke – CT Adjustable 0 to 3000 Factory 100 V/krpm Range: Setting: Properties: CFG and PM Access groups 01 PARAMETER GROUPS via HMI: 43 Motor Data Note: ke is the generated voltage constant. It is a characteristic of the motor, which determines the voltage generated as a function of the motor speed.
Page 302: Current Regulator [91]
PM Vector Control 21.7.2 Current Regulator [91] The parameters related to the CFW-11 current regulator are presented in this group. P0438 – Iq Current Regulator Proportional Gain P0440 – Id Current Regulator Proportional Gain Adjustable 0.00 to 1.99 Factory P0438 = 0.80 Range: Setting: P0440 = 0.50...
Page 303: Torque Current Limitation [95]
PM Vector Control This parameter defines the value of the maximum output voltage. Its default value is defined for the condition of the nominal supply voltage. The voltage reference used in the "Maximum Output Voltage" regulator is directly proportional to the supply voltage. If the supply voltage increases, the output voltage can increase up to the value adjusted in the parameter P0400 - Nominal Motor Voltage.
Page 304: Dc Link Regulator [96]
PM Vector Control P0174 – Minimum Torque Current Adjustable 0.0 to 350.0 % Factory 30.0 % Range: Setting: Properties: Sless Access groups 01 PARAMETER GROUPS via HMI: 29 Vector Control 95 Torque Curr.Limit Description: This parameter defines the minimum value of torque + (P0169) and torque – (P0170) limitations for sensorless control.
Page 305: Flying Start/Ride-Through [44]
PM Vector Control 21.7.6 Flying Start/Ride-Through [44] P0321 – DC Link Power Loss P0322 – DC Link Ride-Through P0323 – DC Link Power Back P0325 – Ride-Through Proportional Gain P0326 – Ride-Through Integral Gain Adjustable 0.000 to 9.999 Factory 0.128 Range: Setting: Properties:...
Page 306 PM Vector Control b) Prepare the drive system and power up the inverter according to the CFW-11 user's manual section 5.1 - Prepare for Start-up. c) Set the password P0000 = 5, according to the Section 5.3 PASSWORD SETTING IN P0000 on page 5-3, in this manual.
Page 307 PM Vector Control - F071 at the end of the acceleration ramp: 1. Decrease proportional gain of the id current regulator (P0440) in steps of 0.1 up to a minimum of 0.2. 2. Decrease the proportional gain of the speed regulator (P0161) in steps of 1.0 up to a minimum of 4.0. 3.
Page 308 PM Vector Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication - Set the content of P0202 Ready 0rpm - Monitoring Mode. pressing "Selec.". - Press "Menu" - Next press until Config 0rpm (right "soft key"). selecting the option: "[007] Language P0201: English 13:48...
Page 309 PM Vector Control Seq. Action/Result Display Indication Seq. Action/Result Display Indication - If necessary, change - Set P0409 according to the content of P0401 the motor data sheet. Config 0rpm according to the rated Therefore, press "Selec.". Config 0rpm Encoder Pulses Number motor current.
Page 310: Faults And Alarms
PM Vector Control 21.9 FAULTS AND ALARMS When the control mode is PM with encoder (P0202 = 6), fault reset will only be accepted with stopped motor. Except for the F079 (Encoder fault) reset, which could occur with the motor shaft in movement; however, the motor must be stopped in order to avoid operation problems after the fault reset.
Page 311 PM Vector Control 21-19...
Page 312 WEG Drives & Controls - Automação LTDA. Jaraguá do Sul - SC - Brazil Phone 55 (47) 3276-4000 - Fax 55 (47) 3276-4020 São Paulo - SP - Brazil Phone 55 (11) 5053-2300 - Fax 55 (11) 5052-4212 automacao@weg.net www.weg.net...

WEG CFW-11 V6.0X Programming Manual

Quick Links

Need help?

Questions and answers

Related Manuals for WEG CFW-11 V6.0X

Summary of Contents for WEG CFW-11 V6.0X

Table of Contents
