2190 Boul. Dagenais West
LAVAL (QUEBEC)
CANADA
H7L 5X9
Your pump has been carefully packaged at
the factory to prevent damage during
shipping. However, occasional damage may
occur due to rough handling. Carefully
inspect your pump for damages that could
cause failures. Report any damage to
your carrier or your point of purchase.
INITIAL START UP PROCEDURES:
1.
Inspect the pump and the sewage tank for
any obvious condition that may
necessitates cleaning, correction,
adjustement or repair.
2.
Assure that the pump is secure and
vertical for proper operation.
3.
Assure that there is adequate clearance
from any combustible materials or
structure. Stored materials must be kept
away from the pump. Shelves or cabinet
structures must not be in close proximity
over the pump.
4.
Assure that the motor is securely plugged
into a proper 'GFCI' electrical outlet.
5.
Test the 'GFCI' outlet by pressing its test
switch. This should prove that the outlet is
energized and will trip off to protect against
a ground fault. Be sure to reset the 'GFCI'
by pressing its reset switch.
(Repeat this step monthly)
6.
Lift the float to assure that the pump will
start when required. (Step 7 below will test
submersible pumps with enclosed floats).
7.
Pour pails of water in the sewage tank to
turn the pump on. Assure that any check
valve present will permit the sewage to flow.
8.
Observe that the plumbing can pump the
sewage safely out of the residence.
(Repeat this step monthly)
© 2009 BUR-CAM Printed in Canada 450375
TEL: 514.337.4415
FAX: 514.337.4029
info@burcam.com
INSTALLATION
INSTRUCTIONS
MODEL
400505C
400419C
SEWAGE
Please read these
carefully. Failure
instructions and
may void the
PUMPS
instructions
to comply to
designed
operation of
this system,
warranty.
Advertisement
Related Manuals for Burcam 400505C
Summary of Contents for Burcam 400505C
- Page 1 INSTALLATION INSTRUCTIONS MODEL 2190 Boul. Dagenais West TEL: 514.337.4415 LAVAL (QUEBEC) FAX: 514.337.4029 400505C CANADA H7L 5X9 info@burcam.com 400419C Your pump has been carefully packaged at the factory to prevent damage during SEWAGE shipping. However, occasional damage may occur due to rough handling. Carefully...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS: This fine pump that you have just purchased is designed from the latest in material and workmanship. Before installation and operation, we recommend the following procedures: CHECK WITH YOUR LOCAL ELECTRICAL AND PLUMBING CODES TO ENSURE YOU COMPLY WITH THE REGULATIONS. THESE CODES HAVE BEEN DESIGNED WITH YOUR SAFETY IN MIND. -
Page 3: Installation Steps
APPLICATIONS FEATURES Vortex designed impeller made from noryl, Designed for a permanent installation for homes will not corrode. Rugged cast iron pump body. and cottages application. To pumping where the total head requirements Stainless steel mechanical rotary type motor do not exceed 15 feet, including pipe friction losses. - Page 4 Screw the pipe with the male adaptor into the 2” discharge opening in the pump. Lower pump STEP 5 with piping attached into the sewage basin. Make sure that the pump is as close as possible to the centre of the basin. Adjusting the pump in centre of basin will keep mechanical float switch from rubbing on side of basin.
-
Page 5: Repair Parts
STEP 9 Fill with water and STEP 2 test operation Install sewage basin 400505C STEP 4 Drill a 1/4” hole STEP 3 Cement 2” adaptor to pipe REPAIR PARTS # REF DESCRIPTION... - Page 6 TROUBLE SHOOTING GUIDE CHECKLIST NEVER MAKE ADJUSTMENTS TO ANY ELECTRICAL APPLIANCE OR PRODUCT WITH THE POWER CONNECTED. DON’T JUST UNSCREW THE FUSE OR TRIP THE BREAKER, REMOVE THE POWER FROM THE RECEPTACLE. TROUBLE PROBABLE CAUSE ACTION Turn switch to on position Motor does not Switch is off position Replace...
