Kuryakyn 1072 Installation

f L A M E S h I f T L I N k A G E
PARTS INCLUDED
1 Flame Shift Linkage Assembly
1 Installation Instructions
Please read and understand entire instructions before starting installation.
ThANk YOU fOR ChOOSING küRYAkYN!
IN ORDER TO PROTECT YOU AND OThERS fROM POSSIBLE INjURY
AND/OR PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION
TO ALL INSTRUCTIONS, WARNINGS, CAUTIONS AND ATTENTION NOTES
REGARDING ThE USE AND CARE Of ThIS PRODUCT.
WARNING! THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE
CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR
SERIOUS INJURY.
CAUTION! This indication alerts you to the fact that ignoring the contents described
herein can result in potential injury or material damage.
ATTENTION! This indication alerts you to the fact that ignoring the contents described
herein may negatively affect product performance and functionality.
NOTE:
Installation shown on a 2006 Touring and 2007 Softail Deluxe; while
representative of typical procedure, there may be minor differences when installed on
other models.
TOOLS SUGGESTED
Set of open-end wrenches; set of hex wrenches.
STRICTLY OBSERVE ThE fOLLOWING
GUIDELINES IN ORDER TO USE ThE
PRODUCT PROPERLY AND AVOID
POTENTIALLY DANGEROUS ACCIDENTS.
PROCEDURE
STEP 1
Read and understand all steps in the
instructions before starting the installation. Park
the motorcycle on a hard, level surface; turn off
the ignition and allow the engine to cool.
WARNING! YOU WILL BE WORKING AROUND
THE ENGINE AND ExHAUST SYSTEM DURING
INSTALLATION. ENSURE THAT THE ENGINE
AND ExHAUST SYSTEM HAvE FULLY
COOLED TO PREvENT INJURY.
STEP 2 Remove stock shift linkage; set aside
for later. See PIC. 1. (Touring Model
shown)
-cont.-
1072-11hD-0510
PIC. 1
REMOVE
ST O Ck NUT
ST OCk
Sh If T
LINkAGE
PIC. 2
ADj UST NEW
LIN kAGE TO BE
SAME LENGT h AS
ST OCk LINkAG E
T IGhTEN
LOCkIN G
NUT Af TER
AD jUSTI NG
BARREL jOIN T STUDS
I N S TA L L AT I O N
1 0 7 2
INSTALLATION QUESTIONS
techsupport@kuryakyn.com
Küryakyn warrants that any Küryakyn products sold
hereunder, shall be free of defects in materials and
workmanship for a period of one (1) year from the
date of purchase by the consumer excepting the
• Küryakyn shall have no obligation in the event
the customer is unable to provide a receipt showing
the date the customer purchased the product(s).
• The product must be properly installed,
maintained and operated under normal conditions.
• Küryakyn makes no warranty, expressed or
implied, with respect to any gold plated products.
• Küryakyn shall not be liable for any consequential
and incidental damages, including labor and
paint, resulting from failure of a Küryakyn product,
failure to deliver, delay in delivery, delivery in non-
conforming condition, or for any breech of contract
or duty between Küryakyn and a customer.
• Küryakyn products are often intended for use
in specific applications. Küryakyn makes no
warranty if a Küryakyn product is used in
• Küryakyn electrical products are warranted for
one (1) year from the date of purchase by the con-
sumer. Components of Küryakyn products containing
L.E.D.s will be warranted for defects in materials and
workmanship for 3 years from the date of purchase.
R EMOVE • Küryakyn makes no warranty of any kind in
regard to other manufacturer's products distributed
BARR EL
by Küryakyn. Küryakyn will pass on all warranties
jOIN T STUD
made by the manufacturer and where possible, will
expedite the claim on behalf of the customer,
but ultimately, responsibility for disposition of the
warranty claim lies with the manufacturer.
ABOUT OUR CATALOG
You'll find all our innovations for H-D, GL and
Metric Cruisers in our annual catalogs. Order
online today–select the "CATALOGS" icon. Each
Küryakyn product comes with a Proof-of-Purchase
good for a complimentary catalog. Details in
Sh IfTER
R OD
LEVER
