Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be
sure you have all needed parts and know where they go.
If question exist, please call us @1-800-222-7023. We will be happy to answer any questions concerning this product.
Check all fasteners for proper torque. Check to ensure for adequate clearance between all components.
Periodically check all hardware for tightness.
KIT CONTENTS:
Windshield x1
Seal x1
Straps x4
Torque Specs:
Size
Grade 5
5/16"
15 ft/lbs
3/8"
30 ft/lbs
7/16"
45 ft/lbs
1/2"
65 ft/lbs
9/16"
95 ft/lbs
5/8"
135ft/lbs
3/4"
185ft/lbs
Can-Am 2016-20 Defender Full Front Windshield
Thank you for choosing Rough Country for all your vehicle needs.
Grade 8
Size
20ft/lbs
6MM
35ft/lbs
8MM
60ft/lbs
10MM
90ft/lbs
12MM
130ft/lbs
14MM
175ft/lbs
16MM
280ft/lbs
18MM
Class 8.8
Class 10.9
5ft/lbs
9ft/lbs
18ft/lbs
23ft/lbs
32ft/lbs
45ft/lbs
55ft/lbs
75ft/lbs
85ft/lbs
120ft/lbs
130ft/lbs
165ft/lbs
170ft/lbs
240ft/lbs
92198162030A
Advertisement
Related Manuals for rough country 98262030
Summary of Contents for rough country 98262030
- Page 1 92198162030A Can-Am 2016-20 Defender Full Front Windshield Thank you for choosing Rough Country for all your vehicle needs. Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be sure you have all needed parts and know where they go.
- Page 2 INSTALLATION INSTRUCTONS 1. Clean the surface of the UTV that the windshield will be applied to. See Photo 1. 2. Remove the protective cover from the windshield. See Photo 2. Photo 1 Photo 2 Clean the windshield surface. Remove the protective cover. 3.
- Page 3 6. NOTE: How the strap is wrapped behind the pin. See Photo 6. 7. Install the 4 straps into the opening in each corner of the windshield. See Photo 7. Photo 7 Photo 8 Install the 4 straps. Wrap the strap behind the pin. 8.
- Page 4 By purchasing any item sold by Rough Country, LLC, the buyer expressly warrants that he/she is in compliance with all applicable, State, and Local laws and regulations regarding the purchase, ownership, and use of the item. It shall be the buyers responsibility to comply with all Federal, State and Local laws governing the sales of any items listed, illustrated or sold.
