THANK YOU FOR CHOOSING ROUGH COUNTRY FOR ALL OF YOUR VEHICLE NEEDS
Rough Country recommends a certified technician install this system. In addition to these instructions, professional
knowledge of disassembly/reassembly procedures as well as post installation checks must be known. Attempts to
install this system without this knowledge and expertise may jeopardize the integrity and/or operating safety of the
vehicle. Please read instructions before beginning installation. Check the kit hardware against the parts list on this
page and the product layout on the last page. Be sure you have all needed parts and know where they go. Also
please review tools needed list and make sure you have needed tools.
Rough Country makes no claims regarding lifting devices and excludes any and all implied claims. We will not be
responsible for any product that is altered.
If questions exist we will be happy to answer any questions concerning the design, function, and correct use of our
products.
Any vehicle equipped with any Rough Country product should have a "Warning to Driver" decal installed on
the inside of the windshield or on the vehicle's dash. The decal should act as a constant reminder for
whoever is operating the vehicle of its unique handling characteristics. Re-torque all installed hardware as
often as possible to ensure safe operation.
INSTALLING DEALER - it is your responsibility to install the warning decal and forward these installation
instructions on to the vehicle owner for review. These instructions should be kept in the vehicle for its service
Ram 2500 / 3500-150 2WD/4WD (2019-2025) Manual Bed Step
PRODUCT USE INFORMATION
NOTICE TO DEALER AND VEHICLE OWNER
PW050141
.
Advertisement
Related Manuals for rough country PW050141
Summary of Contents for rough country PW050141
- Page 1 PRODUCT USE INFORMATION Rough Country makes no claims regarding lifting devices and excludes any and all implied claims. We will not be responsible for any product that is altered.
-
Page 2: Installation Instructions
Manual Corner Step 19-24 Dodge Ram 2500-3500 INSTALLATION INSTRUCTIONS PARTS LIST: Item Quantity Linkage Arm Assembly Step Pad Frame Mounting Bracket Support Bracket 8mm x 25mm Combo Bolts 8mm Lock Washer 8-1.25mm x 20mm Hex Bolt 8mm Nylon Lock Nuts 8mm x 24mm x 2mm Flat Washers 8-1.25mm x 20mm T-Bolts 14mm x 50mm x 4mm Flat Washers... -
Page 3: Tools Required
Manual Corner Step 19-24 Dodge Ram 2500-3500 TOOLS REQUIRED 13mm Socket Rachet Extensions Wrench Follow (Fig 1) to combine the mounting bracket to the support bracket. Do not fully tighten hardware at this time. (2) 8mm Combo Bolts (Fig 1) Combine Support Bracket to Frame Mounting Bracket Follow (Fig 2 –... - Page 4 Manual Corner Step 19-24 Dodge Ram 2500-3500 (Fig 2b) Starting at the rear DS remove the (4) OEM Hex Bolts Model with Hitch farther from mounting point pictured (Model ‘B’) (1) 14mm Flat Washer (Fig 3) Attach combined brackets to vehicle reusing (4) OEM Hex Bolts, using additional flat washer to keep bolt from falling through bracket...
- Page 5 Manual Corner Step 19-24 Dodge Ram 2500-3500 (Fig 4a) Mounted Brackets for Model ‘A’ vehicles (Fig 4b) Mounted Support Bracket for Model ‘B’ vehicles (Fig 4c) Mounted Frame Mounting Bracket for Model ‘B’ vehicles Page 4 of 6...
- Page 6 Manual Corner Step 19-24 Dodge Ram 2500-3500 Follow (Fig 5 – 8) to install the rest of the linkage arm assembly to the mounting bracket. Once finished, Tighten all hardware at this time to the preferred position. Do periodic inspections to the installation to make sure that all hardware is secure and tight. (Fig 5) Mount the frame &...
- Page 7 Federal, State and Local laws governing the sales of any items listed, illustrated or sold. The buyer expressly agrees to indemnify and hold harmless Rough Country, LLC for all claims resulting directly or indirectly from the purchase, ownership, or use of the items.
