11640.10

Hurricane Flat Fender Flares

PATENT PENDING

OMIX-ADA

TECHNICAL SUPPORT

PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com

FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com

, Inc.

Need help?

Do you have a question about the OMIX-ADA Alloy 11640.10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rugged Ridge OMIX-ADA Alloy 11640.10

Page 1 11640.10 Hurricane Flat Fender Flares PATENT PENDING OMIX-ADA TECHNICAL SUPPORT ® PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com 460 Horizon Drive #400 | Suwanee, GA 30024 USA | www.omix-ada.com | Copyright © 2013 Omix-Ada ®...
Page 3 Page 1/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 10mm Shield 8mm Shield Retainer x 24 Retainer x 2 M6 Flange 16mm M6 Nut x 26 Bolt x 26 Washer x 12 45mm Decorative Black Black Washer x 12 Bolt x 56 Nut x 56 Nylon Nut 20mm...
Page 4 Page 2/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 1. Remove the front & rear factory fender flare, flare support and wheel liner. Remove factory fasteners with a flat head screw driver or similar. 2. Cut side marker off 2 inches from the base of light fixture. 3.
Page 5 Page 3/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 4. Attach and crimp female terminals to wires. 5. Insert female terminals into side marker lights supplied. 6. Attach support arm to fender with M8 carriage bolt, 16mm washer and M8 nut.. NOTICE Do not tighten.
Page 6 Page 4/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 8. Secure wires to support arm with zip tie. 9. Loosely fasten flare to the side of the fender using 2 M6 flange bolts and M6 nuts. 10. Mark your fender using the hole shown as a guide. Remove fender flare after fender is marked.
Page 7 Ridge Snorkel skip to Step 14. CAUTION Cutting/Sharp Edge Hazard: Cut carefully using gloves and eye protection. 13. If you have a Rugged Ridge Snorkel, mark passenger side wheel liner where indicated. Carefully cut area marked. CAUTION Cutting/Sharp Edge Hazard: Cut carefully using gloves and eye protection.
Page 8 Page 6/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 15. Place and position cut front liner in wheel well. 16. Use factory screws previously removed and 45mm washers to Red Arrows secure wheel liner where indicate. Green Arrow Replace factory nut where indicates.
Page 9 Page 7/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 18. Attach and tighten Hurricane flare with M6 flange bolts, Red Arrows 16mm washers and M6 nuts where the indicate. Green Secure rest of the flare with large push fasteners where Arrows indicate.
Page 10 Page 8/8 11640.10 Hurricane Flat Fender Flares PATENT PENDING 21. Secure wheel liner using M6 flange bolts, 16mm washers and Arrows. M6 nuts in locations indicated by Green Secure wheel liner with 8mm shield retainer indicated by Arrow. 22. Attach your choice of either black or stainless steel decorative bolts into the double pockets.
