- Page 1 Installation Instructions of Handleset Tutorial Video Scan the QR code to get the video. Need Help? Contact Us! +1(855)400-3853 Call us at ( Monday-Friday 9:00am-5:00pm PST ), if you have any questions. support@iveise.com iveise.com...
-
Page 2: Table Of Contents
Content Parts List Prepare the Door & Check Dimensions Latch Adjustment Install the Latch & Strike Install Handleset Install Handle Lever... -
Page 3: Installation Overview
Installation Overview Handle Lever Latch(B) Handleset Handle Lever Strike & Handleset Screws Dust Cover(optional) Latch & Strike Screws(G) Spacer(H) Handle Lever & Handleset Screws... -
Page 4: Parts List
Parts List Latch x1 Handleset x1 Strike x1 Handle Lever Dust Cover x1 (optional) Handle Lever x1 & Handleset Screws x3 Spacer x1 Latch & Strike Screws x4 TOOL REQUIRED: Do not use an electric screwdriver during installation. -
Page 5: Prepare The Door & Check Dimensions
Prepare the Door & Check Dimensions If your door already has the holes shown in the picture below, proceed to the next step; if your door does not have holes, use the mounting template to drill a new hole. -
Page 6: Latch Adjustment
Latch Adjustment Note: Be sure to use the Latch provided in the package or it won't work. Backset is the distance from the door edge to the center of the hole in the door. If the backset of your door is 2-3/8" (60mm), no need to adjust the Latch. -
Page 7: Install The Latch & Strike
Install the Latch Opening outwards Opening inwards Install the Strike Opening outwards Strike Screws Opening Note: The bevel of the Latch should be aligned inwards to the bevel of the Strike. -
Page 8: Install Handleset
Install Handleset Torque Blade IMPORTANT: The Torque Blade must be rotated aligning to the square hole. -
Page 9: Install Handle Lever
Install Handle Lever Test the Handleset and Handle Lever IMPORTANT: Don't press the knob during the Keep the door open, checking out installation of the handle. Handleset and Handle Lever to test if they work smoothly. - Page 10 Need Help? Contact Us! If you have any questions, please contact us at +1(855)400-3853 (Monday-Friday 9:00am-5:00pm PST) support@iveise.com iveise.com If you have your order ID, videos or images of your problem (if necessary) ready before contacting Customer Support, we will solve your problem faster and better.
