- Page 1 User Guide VE008 Smart Lock Please fully read and understand this manual before using and keep this manual for future reference.
-
Page 2: Installation Video
INSTALLATION VIDEO Please watch this video first and use this manual as a guide. www.iveise.com/videos Go to to watch installation video. +1(855)400-3853 If you have any questions, contact us at SCAN ME (Monday-Friday 9:00-5:00pm PST) -
Page 3: Table Of Contents
USER GUIDE How to Lock / Unlock STEP 3: Install exterior assembly How to change lock mode STEP 4: Install interior assembly STEP 1: Prepare the door STEP 5: Install battery and check dimensions STEP 2: Install the latch and strike APP Guide... - Page 4 AT A GLANCE Exterior Assembly Interior Assembly Fingerprint Thumb Turn Light Type-C Keyhole Interface...
-
Page 5: How To Lock / Unlock
HOW TO LOCK / UNLOCK Type-C Interface Keyhole • Key To Unlock • Fingerprint unlock • Auto-lock Insert the key into the keyhole Put finger on the sensor to In the Normal & Privacy located at the edge of the unlock the knob. -
Page 6: Factory Default Settings
FACTORY DEFAULT SETTINGS Restore the Factory Setting Rotate the thumb turn from the circular mark to the unlock sign on the left and then return the thumb turn to the circular mark, after repeating this operation 5 times, perform the same opera- tion to the right for 5 times. -
Page 7: How To Change Lock Mode
HOW TO CHANGE LOCK MODE • Normal Mode • Passage Mode • Privacy Mode As the figures shows, rotate the thumb As shown at right, rotate the As shown in the figures, rotate the turn to circular mark above the thumb thumb turn to unlock sign on the thumb turn to lock sign on the right turn to switch to normal mode. -
Page 8: Parts List
PARTS LIST If any parts are missing or damaged, please contact us at +1(855)400-3853. Exterior Knob x1 Latch x1 Strike x1 Dust Cover x1 (optional) Latch&Strike screws x4 Interior Knob x1 Long Screws x2 User Manual x1 Backup Key x2... -
Page 10: Step 1: Prepare The Door And Check Dimensions
STEP 1: PREPARE THE DOOR AND CHECK DIMENSIONS 2-3/8" or 2-3/4" 1-1/5" to 2-1/8" (60 or 70mm) (30mm to 55mm) B a c k s e 1" 2-1/8" 25mm (54mm) Depth: 1" (25mm) Measure to confirm that Measure to confirm that the Measure to confirm that the Make sure the hole in the door the hole in the door is... -
Page 11: Step 2: Install The Latch And Strike
STEP 2: INSTALL THE LATCH AND STRIKE Latch backset adjustment Backset is the distance from the door edge to the center of the hole in the door. If the backset of your door The latch is provided with is 2-3/4"(70mm), please adjustable design which can fit adjust the latch as shown either 2-3/8’’(60mm) or... - Page 12 STEP 2: INSTALL THE LATCH AND STRIKE Install the latch Latch Screws (E) Opening outwards Opening inwards Chiseled...
- Page 13 STEP 2: INSTALL THE LATCH AND STRIKE Install strike on the door frame. IMPORTANT: Strike Screws (E) Make sure the hole in door frame is drilled a minimum of 1" (25mm) deep. Strike screws(E) Dust Cover(D) (optional) (Actual Size)
-
Page 14: Step 3: Install Exterior Assembly
STEP 3: INSTALL EXTERIOR ASSEMBLY Route the cable over the latch, the 2 rod bolts going through the round holes on the latch, and insert the torque blade going through the square holt. Note: The "UP" label mark on the rosette facing up, and the keyhole facing down. -
Page 15: Step 4: Install Interior Assembly
STEP 4: INSTALL INTERIOR ASSEMBLY Screws built-in battery cover Loosen the screws on the interior Knob Insert the cable connector to the socket. and remove the battery cover. Push the connector in firmly until it is completely (Actual Size) attached. - Page 16 STEP 4: INSTALL INTERIOR ASSEMBLY Long Screws(G) x 2 (Actual Size) The tailpiece going through the square hole on Insert the Long Screws into the circular holes and tighten the interior assembly; them to secure the rosette. Note: The "up" mark on the rosette facing up.
-
Page 17: Step 5: Install Battery
STEP 5: INSTALL BATTERY Please install the battery correctly according to the positive and negative poles as shows. Insert 4 AAA alkaline batteries and put on the battery cover (the Screws built-in battery cover battery cover pillar should be inserted into the corresponding hole), secure the battery cover with two screws. - Page 19 DEFINITIONS Action Buzzer Indicator Inactive Power on Beep once Fingerprint added successfully Long Beep Stay green for a while Unlocking successful Beeps once Blinks green once Unlocking failure Beeps twice Blinks red once Beeps once (after using Blinks green then blinks red (after Low battery warning fingerprint or App to unlock) using fingerprint or App to unlock)
-
Page 20: How To Register
HOW TO REGISTER Download “smart life” App in Google Play or App Store. Notes: The smart life is required to operate the lock. After the lock is properly installed, make sure this step is performed by the lock owner. - Page 22 FINGERPRINTS Tap on "Member Management". Choose the Tap on "+ Add". member and tap on it. Follow the instruction in the App and Complete fingerprint addition.
-
Page 23: Fcc Warning Statements
FCC warning statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
