Summarization of Contents
1. INTRODUCTION
Approvals
Lists the certifications and standards the instrument complies with, such as NTEP and OIML.
Trade Modes
Explains the operation modes (Industrial, OIML, NTEP) and their restrictions for trade compliance.
Manuals
References for further information, including the Reference Manual and Connector Pinouts.
3. INSTALLATION
3.1 Loadcell Connection
Details on connecting loadcells, including 4-wire and 6-wire systems and specifications.
3.2 Other Connections (Serial, Digital Inputs and Outputs)
Describes serial ports, digital inputs/outputs, and 5V output for external devices.
3.3 Optical Communications
Explains the use of the rinLINK attachment for PC communication via infrared.
3.4 Accessory Card connection
Information on connecting optional communication and expansion cards for added functionality.
4. SETUP MENUS
4.1 General Options
Configuration settings for passcodes, date/time formats, key locking, and display options.
4.2 Scale
Settings for scale configuration, including range type, decimal points, capacity, and resolution.
4.3 Serial
Configuration of serial ports, baud rates, data bits, stop bits, and network protocols.
4.4 Set Points (K304 - 8 Basic, K306 - 8 Advanced)
Settings for configuring setpoints, including type, logic, timing, target weight, and alarms.
4.5 App
Configuration for special functions like piece counting, check weighing, auto tare, and special function keys.
4.6 Test
Procedures for testing display, digital outputs/inputs, overload counts, and mV/V signals.
4.7 DSD (K304, K306)
Options for enabling and configuring Data Storage Device (DSD) features.
4.8 End
Instruction to save and close the setup menu.
6. APPENDIX - ERROR MESSAGES
6.1 Weighing Errors
Lists and explains error messages related to weighing operations and their resolutions.
6.2 Setup Errors
Lists and explains error messages encountered during instrument setup and their resolutions.
6.3 Diagnostic Errors
Details E-type error messages indicating internal circuit faults and their solutions.
6.4 Calibration Errors
Lists and explains errors that occur during the calibration process and provides resolutions.
