- Page 1 300 Series (K367) Reference Manual...
- Page 4 Reference Manual V1.03 Software Versions 4.xx Table of Contents INTRODUCTION ........................2 1.1. Features ........................2 INSTALLATION ........................3 2.1. Introduction ........................ 3 2.2. General Warnings ...................... 3 2.3. Electrical Safety ......................3 2.4. Cleaning ........................3 2.5. Panel Mount Template ....................3 2.6.
- Page 5 Reference Manual V1.03 Software Versions 4.xx 1. Introduction Figure 1: Indicator This instrument is used to mimic 300 series and T610/T620 indicator families. K367 firmware has two modes of operation: Mimic Mode • Total Mode • A single indicator or multiple indicators can be connected in a ring network to the K367 mimic instrument.
- Page 6 Reference Manual V1.03 Software Versions 4.xx Installation 2.1. Introduction The following steps are required to set up the indicator. • Inspect indicator to ensure good condition & appropriate firmware. Use connection diagrams to wire up power and auxiliary cables as required. •...
- Page 7 Reference Manual V1.03 Software Versions 4.xx 2.8. Slave instrument Connections Instruments can be configured in a Ring Network. When operating in a Ring Network, the slave Instruments must have: same serial port options, i.e., baud, parity, data bits, stop bits; •...
- Page 8 Reference Manual V1.03 Software Versions 4.xx 2.9. Outputs To drive external loads (e.g. wireless accessory), connect a short jumper from PWR+ to COM. This will provide source power to OUT1 or OUT2 for accessory power. This works well for low power cut the cable Bluetooth options. Figure 3: Instrument Outputs PWR+ PWR-...
- Page 9 Reference Manual V1.03 Software Versions 4.xx Operation There are 2 modes of operation, Mimic and Total mode. Following sections describes how to navigate between each mode and operate in each mode. Note: Apart from the 2 operation modes the instrument automatically detects if there is only one slave or multiple slaves are connected.
- Page 10 Reference Manual V1.03 Software Versions 4.xx ZERO Key A remote <ZERO> key press will be sent to the slave unit. Long press: A remote <ZERO> key long press will be sent to slave unit. TARE Key A remote <TARE> key press will be sent to the slave unit. SELECT Key A remote <SELECT>...
- Page 11 Reference Manual V1.03 Software Versions 4.xx 3.3. Total Mode Total mode shows summation of the weight of all slave units in ring network. Following settings\modes of all the slave units must be same. Decimal points • Gross\Net mode • Units •...
- Page 12 Reference Manual V1.03 Software Versions 4.xx Note: Only the Master instrument output will be turned off. No change will happen to Slave outputs. Refer Setpoints section for details. Page 9 003R-685-103...
- Page 13 Reference Manual V1.03 Software Versions 4.xx Setpoints The instrument is capable of working with two internal setpoints. The status of these setpoints are displayed on the LCD. Each setpoint is associated with a physical output driver but it may also be simply used as an indicator.
- Page 14 Reference Manual V1.03 Software Versions 4.xx Setup The instrument digital setup facilities provide the means to configure the instrument. 5.1. Accessing Setup Setup menu can be access via short press of rear setup button. 5.2. Setup Display Prompts When accessing Setup, the instrument will beep thrice and then display the following: •...
- Page 15 Reference Manual V1.03 Software Versions 4.xx 5.4.4. B.LIGHT (Backlight Operation) Sets the operation of the backlight. When operating the backlight with batteries the brightness is lowered automatically to conserve power and the backlight will automatically turn off after 10 seconds of inactivity. To turn on again, press the <POWER> key. Options: OFF: Backlight is off.
- Page 16 Reference Manual V1.03 Software Versions 4.xx Appendix – Dimensions R320 Weight Indicator Dimensions in mm (1 inch = 25.4 mm) 3D View Front View Side View Back View R323 Weight Indicator (Panel Mounted) Dimensions in mm (1 inch = 25.4 mm) Panel Mounted 3D View Front View Rear View...
- Page 17 Reference Manual V1.03 Software Versions 4.xx Error Messages A number of error messages may be displayed to note interruptions to operation. These messages are described below. When in Mimic mode extra diagnostic errors will be shown depending on the slave unit. Refer slave unit reference manual for details.
