  • Page 1 S M A R T W E I G H IN G S O L U T I O N S C3 Series Digital Indicators Reference Manual C300-600 ROW Rev 1.0.2...
  • Page 2 Rinstrum Pty Ltd. Disclaimer Rinstrum Pty Ltd reserves the right to make changes to the products contained in this manual in order to improve design, performance or reliability. The information in this manual is believed to be accurate in all respects at the time of publication, but is subject to change without notice.

  • Page 3: Table Of Contents

    Editing Weight and Number Items .............. 20 Editing With Functions ................20 5 Setup Menus General Options ..................21 Scale ....................... 24 Serial ...................... 31 Set Points ....................34 App ......................36 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 4 Automatic Weight Output (SER.AUT) ............62 Printing (PRINT) ..................63 10 Setpoints (SETP) 10.1 Common Settings ..................66 10.2 Weigh in (OVER) Setpoints and Weigh Out (UNDER) Setpoints ....67 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 5 16 Appendix - Dimensions 17 Appendix - Error Messages 17.1 Weighing Errors ..................91 17.2 Setup Errors .................... 91 17.3 Diagonostic Errors ..................92 17.4 Calibration Errors ..................93 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 6: Introduction

    0.5mV/V at display resolutions of up to 10000 divisions. The C3 series digital weight indicators have a RGB LCD with 6 digits, 9 segments with units indicators and annunciators. The instrument has 8 setpoints which can be set to display using main display colors.

  • Page 7: Installation

    · Storage temperature range: -20 °C to 50 °C · C320: DC power supply (5-24 VDC) · C350 and C357: AC (110-240VAC 50/60Hz) or DC (5-24 VDC) power supply C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 8: Electrical Safety

    Stainless steel mounting bracket for scale base The panel mount template is supplied with the instrument. It shows the location of the rectangular cut-out and the four mounting screws. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 9: Power Connections

    2 ohms. 2.7 Loadcell Connection The C3 series can drive any number of full bridge strain gauge loadcells up to the equivalent of 8 x 350 ohm cells. The span range of the loadcell outputs (the change of signal from the loadcells between zero load and full gross load) must be within the range of 0.1 to 5.0 mV/V.
  • Page 10 ±Excitation and ±Signal). When a four wire loadcell system is connected, it is necessary to ensure that the excitation voltages are fed into the sense inputs using jumper wires as shown in below diagram. Figure 3: 4-Wire Connection C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 11: Other Connections (Serial, Digital Inputs And Outputs)

    Warning! Sense lines must be connected or 4/6 wire jumpers fitted as shown in dashed lines in above figure. Failure to do this will result in the C3 series displaying an error message (E00040, E00080 or E000C0).
  • Page 12 Remote Display The remote display documentation should be referred for connection details. Connect Tx to Rx, Rx to Tx and GND on the remote display as shown in the diagram. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 13 Figure 6: Remote display Connection 2.8.2 Digital Input and Output Connection The C3 series isolated digital inputs should be connected as shown in the diagram below. The digital outputs are isolated high side drivers. They should be connected as indicated in the diagram below.

  • Page 14: Optical Communications

    Caution: Some load cells connect the cable shield directly to the load cell (and therefore the scale base). Connection of the load cell cable shield in this situation may be site specific. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 15: Accessory Card Connection

    · Communication cards · Expansion Cards These are connected to rear of the indicator using the accessory port. Figure 10: Accessory Card Connection C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 16: Basic Operation

    3. BASIC OPERATION The C3 series has a has six digit RGB LCD display and a 7 key keypad. The 7 front panel keys that control the operation of the instrument. The 8th key (SETUP) is on the rear of the instrument.

  • Page 17: Display

    If however, the key beeps normally, but does not appear to trigger the desired action, it may be waiting for the weight reading to settle before the action can proceed. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 18: Stability - What Is A "Error Motion

    Operation it will operate whenever external power is available and will not need to be manually turned on again if the power is interrupted. 3.6 Zero Key Zero Key C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 19: Tare Key

    Instead of going back to GROSS though when TARE cleared we can go back to NET.PT as an indication of material available in the vessel. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 20: Select Key

    Refer to KEY.LOC (Front Panel Key Locking) for more information. A long press of the key may be used for certain functions depending on Long Press the primary function of the key. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 21: Data Entry

    If an attempt is made to enter Full Setup using the incorrect passcode, the instrument will respond with the message ENTRY DENIED. Refer to Passcodes (GEN.OPT:PCODE) for more information. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 22: Exiting Setup Menus

    Method 1: Press and hold both the <POWER> and <SELECT> keys together for two seconds. Method 2: Press the <ZERO> key repeatedly. When End displays press <OK> key. When exsiting the following is displayed: Software Software Version (eg. V1.0) Counter (eg. C.00010). C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 23: Navigation

    F1 Key Setup Menu Step through the list of fourth level menu items. function Setup editor Increment selected digit in number editor. Previous option function in bit and list editor. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 24: Editing Option Items

    · Press the OK key to show the current setting · Press the keys until the correct setting is shown · Press the OK key to exit the editor C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 25: Editing Weight And Number Items

    · All functions are different and there are no standard keys. The user will be prompted for what is required. · Use the cancel key to exit the function C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 26: Setup Menus

    • Range 000000 (Default) to 999999 TIME Time settings Configure the date and time settings. TI.FMT Time format Sets the time format for the indicator. • 12 (Default) • 24 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 27 POWER key. BL.TIME Backlight power down The backlight can be set up to automatically power time (s) down after a period of no activity (B.LIGHT=AUTO). C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 28 Buzzer enable • OFF: The buzzer is turned off • ON (Default): The buzzer is turned on USR.DEF Indicator defaults Set the non-calibration settings to defaults. Local function only. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 29: Scale

    If using multiple interval/range, this sets the count- by (or resolution) of the lowest range/interval. • 1 (Default) • 2 • 5 • 10 • 20 • 50 • 100 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 30 (TYPE=TRIPLE.I, TRIPL.R) • 000000 (Default) • 00000.0 • 0000.00 • 000.000 • 00.0000 • 0.00000 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 31 Tertiary weighing units Sets the tertiary weighing units for the scale. • OFF: Off (Default) • g: Grams • kg: Kilograms • t: Tonnes • lb: Pounds • oz: Ounces C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 32 This setting is given as xd – yt where weight change of more than x divisions in y seconds will trigger motion. This value is displayed as weight change (0.5 or 1.0 graduations) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 33 Settable over the full weight range. Always enter a number in multiples of display units. • Range: -1 to 999999 • Default: 0 (i.e. –0.5 to 0.5 graduations) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 34 • OFF (Default): Disable gravity compensation • ON: Enable gravity compensation G.FACT Factory gravitational Sets the gravitational acceleration of the factory acceleration location. • Range: 9.750 to 9.860 • Default: 9.810 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 35 QA expiry date Enter QA expiry date - day • Range: 1 (Default) - 31 This item is trade critical and will affect the calibration counter(s) if changed. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 36: Serial

    Sets the data format. • FMT.A (Default) to FMT.I and CUSTOM AUTO.SPD Serial output Sets the serial output frequency frequency • SINGLE (Default) • FULL • 10Hz • 5Hz • 2Hz C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 37 Sets the interlock weight. • Range 000000 (Default) to 999999 P.WIDTH Page width Sets the page width. A setting of zero disables page width checking. • Range 0 (Default) to 80 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 38 • Range 0 (Default) to 10 SP.BOT Bottom spacing Sets the number of blank lines added to the bottom of the print out. • Range 0 (Default) to 10 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 39: Set Points

    Hysteresis defines the amount of weight required for an active setpoint to become inactive again (TYPE=OVER, UNDER, W.IN, W.OUT). A value of 0 still allows for 0.5 graduations of hysteresis. • Range 000000 (Default) to 999999 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 40 Disable setpoint Input to disable the setpoint. • NONE (Default), IO1 to IO8 NAME Name of the setpoint Setpoint name. Used in the target function key to identify the setpoint. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 41: App

    Check weighing target Sets the target check weight (CW.MODE=REL) • Range -99999 to 999999 • Default: 005000 CW.TOL.H Check weighing upper Sets the upper tolerance for relative check tolerance weighing (CW.MODE=REL). C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 42 • FUNC.EN: Function enable PRT.OUT Printout Configuration of the PRINT Special Function (TYPE=PRINT). Printouts are configured in the SERIAL menu. • SER 1 (Default) • SER 2 • SER 3 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 43 This is the percentage that the weight on the scale must change by to restart the live weighing process once a held weight has been captured (TYPE=LIVE). A value of 0 means that automatic retriggering is disabled. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 44 (TYPE=PK.HOLD). • ALWAYS • STABLE (Default) REM.KEY Remote key function Allows for external inputs to be used to trigger instrument key functions (TYPE=REM.KEY). The C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 45 (TYPE=LIVE). • Range -99999 to 999999 • Default: 0 IDLE Idle time (s) Idle time before timeout (TYPE=LIVE). • Range: 1 to 20 • Default: 5 C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 46: Test

    · DSD.STR DSD String Custom string to be stored along with the traceable data when the DSD is written. This accepts all print tokens. 5.8 End Save and Close C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 47: Configuration

    The values are: · Units = kg · Full Scale = 5000 · Count-by = 5 Calculating the total number of graduations: Signal voltages can be calculated as follows: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 48: Filtering Techniques

    Fullscale Tare No restrictions Tare values must be > 0 Tare values must be > 0 Test Modes Unlimited time Limited to five seconds Limited to five seconds allowed C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 49: Calibration Counter

    No more than three failed attempts can made to access Full/Safe Setup before the instrument blocks access completely. The instrument must be turned off and on again before further attempts can be made. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 50: Calibration (Scale:cal)

    It is important that an initial Zero calibration is performed before any SPAN calibrations. The chart shown here demonstrates how the zero and span points are used to interpolate a weight reading from the load cell reading. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 51: Performing A Calibration With Direct Mv/V Entry

    Zero and full scale Span. The Direct Zero setting (CAL:DIR.ZER) specifies a gross zero point for the scale. The Direct Span setting (CAL:DIR.SPN) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 52: Using Linearisation (Ed.lin)

    Multiple linearisation points can be set independently between zero and full scale depending on the indicator. Unused or unwanted points may also be cleared (CAL:CLR.LIN). The maximum correction that can be applied using a linearisation point is + / - 2%. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 53: Using Gravity Compensation (Gravity)

    The G.INST setting can be edited directly in the calibration menu however this will result in the calibration counter being incremented. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 54: Special Functions (Func)

    P.HOLD Key: Long Press A long press of the <PEAK> hold key clears the peak value (note: it will immediately resample a peak value). Short press <PEAK> to return to normal weighing. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 55: Single

    The <PRINT> function is used not only to print the current weight but also to add that weight to the current total. Note accumulation must be ON within the setup for this key to have effect. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 56: Print

    (Note: the total weight can be displayed by configuring a <TOTAL> function key) 000048 06/05/2023 15:10 120.0 kg G 0.0 kg N 0.0 kg T 000049 06/05/2023 15:11 100.0 kg G C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 57 · When Docket printing, a long press ends the docket. COUNTING Active: If counting is active, the printout has a fifth line for the counting information (p for pieces): C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 58: Target

    · display will show first set point name followed by its output target. · <OK> to enter edit mode and use the <ARROW> keys to edit the setpoint target. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 59: Units

    The instrument begins to calculate a long-term average that compensates for any movement in the animal. o Retrigger percentage: during the weighing process a movement in weight by more than the retrigger percentage will cause the weighing average to be restarted. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 60 The Hold (H) annunciator is steady when the final sample weight is shown on the display. Short press: to restart sequence Long Press: to stop the live weigh function C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 61: Serial Outputs (Serial)

    All slaves must process broadcast commands. When replying to broadcasts, slaves reply with their own address in this field. CMD is a two character hexadecimal field: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 62 If a command cannot be processed, the indicator returns an error. The ERROR bit in the ADDR field is set and the DATA field contains the Error Code as follows: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 63 ( Read Final) Read Gross Weight (Register 0026): ADDR = 20 : Reply required from any instrument CMD = 11 : Read Final REG = 0026 : Gross Weight C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 64 REG = 10 : Save Settings RESPONSE D: Instrument #1 reports ”Command Successful”. Description Trigger Zero Button COMMAND A: Press Send down the Zero button key code. (Write Final) RESPONSE A: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 65: Network Protocol Simple (Simple)

    The response setting (RESP) defines if there is any response sent to successful commands. A setting of OK will send OK<CR> on successful receipt of command or ??<CR> if the command is not understood. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 66: Network Remote (Remote)

    REM.M: Operates in a similar manner to MIMIC except that the scale unit is not a C3 but another Rinstrum indicator. The remote C3 asks for weight and status only. In this case the remote C3 may not be a perfect copy of the main scale and not all scale keys may be supported.

  • Page 67: Automatic Weight Output (Ser.aut)

    <STATUS(OL,ST,US)><GROSS(GR,NT)>< SIGN>< WEIGHT(7)>< UNITS(2)> Start of transmission character (ASCII 02). End of transmission character (ASCII 03 SIGN(Except The sign of the weight reading (space for positive, dash (-) for negative). FMT.G) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 68: Printing (Print)

    For custom printing each print event has an associated token string which includes literal ASCII text along with special token characters that are expanded at the time of printing to fields like weight, time and date. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 69 6.15 kg, Total 27.90 kg Items Thank You! FMT.B Joe's Fruit & Veg 30 Yarmouth Pde Tamworth 2040 13/03/03 11:09:27 4.06 kg 5.04 kg 3.15 kg 5.02 kg 4.48 kg C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 70 To produce Weight: 30.0kg ^ when the print key is pressed. Events are triggered by short and long press of the Print key and changing products as listed as listed in the tables for each type. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 71: Setpoints (Setp)

    Reference Manual Rev 1.0.2 10. SETPOINTS (SETP) The C3 series has 8 setpoints with setpoints 1 and 2 linked to the onboard digital outputs. Setpoint status can be used to drive the onboard outputs directly, sound the buzzer, change display background colour, or can be transferred to external control systems using Modbus RTU or through field bus expansion.

  • Page 72: Weigh In (Over) Setpoints And Weigh Out (Under) Setpoints

    · ‘GR or NT’ uses either gross or net depending on which is currently displayed. · PIECE uses gross or net piece count depending on which is currently displayed. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 73: Over Setpoint Timing Options

    The GR.or.NT option uses the currently selected weight (gross or net). · NET: Setpoint is active when the NET annunciator is lit. · MOTION: Setpoint is active when the MOTION annunciator is lit. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 74 (ex: Filling a tank) · W.OUT: Setpoint is active till target weight is reached. Weight should be decremented till the target value is reached. (ex: Draining a tank) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 75: Digital Storage Device (Dsd)

    DSD records on alibi mode. You can manually send communications commands to the instrument to retrieve DSD records. The following registers relate to the DSD. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 76 ID, date (in YYYY/MM/DD format), time (in 24:MM:SS format), weight, units, gross/net status, PT weight. User Tare weight, custom string If the custom string DSD.STR: TOTAL\BE\D8 is set then the reply will be: 81108295:64,2024/05/21,19:51:40, 236,kg, NET, 0,kg, 591,kg,TOTAL 827 kg C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 77: Alibi Application

    The following keys apply in Alibi Weighing and Counting modes: Short press Zero Zero the scale Long press (None) Short press Tare Tare the scale Long press Present Tare Enter a preset tare C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 78: Dsd And Change Log Viewer Modes

    Go to the first item within the current record Short press Prev record Go to the previous record Long press First record Go to the first record (Oldest record) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 79 · ˆ T are: Tare weight · P.Tare: Preset Tare weight · ˆ D ate: Date stamp of print (yy.mm.dd) · ˆ T ime: Time stamp of print (hh.mm.ss) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 80: Licensing

    There may however be situations where license codes are used to activate the indicator software in the field. License codes are unique for each indicator and firmware can be purchased from Rinstrum or directly through rinLIVE. 13.1 Unlicensed Software If indicator has not yet been licensed (activated), the message “ENTER” “LICENC” will be displayed on start up.

  • Page 81: Upgrading Fimware

    Reference Manual Rev 1.0.2 14. UPGRADING FIMWARE C3 Series indicator firmware are field upgradable. 14.1 Upgrade using flash programming executable Warning: If the indicator firmware is upgraded the calibration counter may be incremented If the upgrade is major firmware release (ie: V1.xx t0 V2.xx).
  • Page 82 8. The indicator will display “PROG”, and programming software will first program, and then verify the new firmware. 9. The indicator will restart running the new firmware, and the programming software will display the following: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 83: Upgrade In Boot Mode

    4. Click “Start” on the flash programming software. 5. Select the serial port for the USB optical cable and click Ok. 6. Click “Next >>>” 6. The flash programming software will display “Connecting”. This will fail. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 84 8. The indicator will display “PROG”, and programming software will first program, and then verify the new firmware. 9. The indicator will restart running the new firmware, and the programming software will display the following: C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 85: Print And Automatic Transmission Tokens

    ‘M’ 103 (67 ‘g’ (*) Use ASCII 128 to implement a literal NULL character in a custom string. ASCII 0 is used to define the end of the string. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 86: Use Of Characters In The Extended Ascii Table

    Code Token Page 0: Current Weight Page 1: Held Weight Page 2: Held or Current Page 3: Traceable Weight C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 87 Time of peak held weight Auto out weight (set in SER.AUT -> SOURCE) Page 3 (BB ) only tokens These tokens hold traceable weight information. Code Token Traceable weight date C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 88 M, C, ‘ ‘ Motion, over/under Capacity _G__, _N__, _ __ Gross, Net I, O, U Inscale, Overload, Underload M, S Motion, Stable (E1 H ) ST, US, OL Stable, unstable, overload C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 89 Secondary units Tertiary units Display string Display units (DF H ) Flip string direction Epson release command Horizontal line of '_' Time delimiter is ‘.’ Date delimiter is ‘-‘ C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 90 (9C H ) Positive symbol ‘ ‘, negative ‘-‘ Positive symbol ‘0 ‘, negative ‘-‘ Positive symbol ‘+ ‘, negative ‘-‘ Don't send decimal point Decimal point is ‘.’ C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 91 10kg and a formatted with no units is needed: \BE\AA\D7 would be 10 Whereas if the AA is used after the D7 it has no effect. \BE\D7\AA would be 10kg C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 92: Appendix - Dimensions

    Reference Manual Rev 1.0.2 16. APPENDIX - DIMENSIONS C320 Panel Mount. C320 with M6001 black desk mount housing on a desk. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 93 Reference Manual Rev 1.0.2 C320 with M6001 black desk mount housing mounted on a desk. C320 with M6001 black desk mount housing mounted on a wall. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 94 Reference Manual Rev 1.0.2 C320 with M6003 black desk mount housing mounted on a desk. C320 with M6003 black desk mount housing mounted on a wall. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
  • Page 95 Reference Manual Rev 1.0.2 C350 Desk/Wall Mount. C357 Desk/Wall Mount. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 96: Appendix - Error Messages

    (WR DENIED) The instrument may be in Safe Setup Access Full Setup to access this item. (RD DENIED) and an item that needs Full Setup has been selected for editing. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 97: Diagonostic Errors

    1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - A - B - C - D - E - F (For example, 2 + 4 = 6, or 4 + 8 = C) C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...

  • Page 98: Calibration Errors

    (FAILED) An attempt has been made to add a linearisation point Check weights and retry. (TOO CLOSE) too close to zero, span or another linearisation point. C300-600 ROW Rev 1.0.2 C3 Series © 2024 Rinstrum Pty Ltd...
