Trinity i7205
S2662
Revision 1.04
Copyright © TYAN Computer Corporation, 2001-2002. All rights reserved. No part of this manual
may be reproduced or translated without prior written consent from TYAN Computer Corp.
All registered and unregiste red trademarks and company names contained in this manual are
property of their respective owners including, but not limited to the following.
TYAN, Trinity i7205 are trademarks of TYAN Computer Corporation.
Intel, Pentium, and combinations thereof are trademarks of Intel Corporation.
Microsoft and Windows are trademarks of Microsoft Corporation.
Phoenix BIOS is a trademark of Phoenix Technologies.
Winbond is a trademark of Winbond Electronics Corporation.
LSI is a trademark of LSI Logic Corporation.
AnalogDevice and ADM are trademarks of Analog Devices Inc.
Sony/Philips Digital Interface (SPDIF) is a trademark of Sony Corporation and Philips Electronics.
PS/2 is a trademark of International Business Machines Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer Corporation and has been
reviewed for accuracy and reliability prior to printing. TYAN assumes no liability and disclaims any
express or implied warranty relating to sale and/or use of TYAN products; we also assume no
including liability or warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications at any time without
notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential
damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of
information contained in this document.
1
http://www.TYAN.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TYAN TRINITY I7205
Summary of Contents for TYAN TRINITY I7205
- Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
3.6 BIOS Power Menu ………………………………..Page 31 3.7 BIOS Boot Menu ………………………………..Page 32 3.8 BIOS Exit Menu ………………………………..Page 33 Chapter 4: Diagnostics ………………………………..Page 34 4.1 Beep Codes ………………………………..Page 34 4.2 Flash Utility ………………………………..Page 34 Appendix I: Glossary ………………………………..Page 35 Technical Support ………………………………..Page 39 http://www.TYAN.com... -
Page 3: Before You Begin
1x 34-Pin floppy drive cable 1x LVD SCSI cable (if option SCSI included) 1x Ultra-D M A-100/66/33 IDE cable 1x Trinity i7205 S2662 user’s manual 1x TYAN driver CD 1x SCSI driver diskette (if optional SCSI included) 1x I/O shield... -
Page 4: Chapter 1: Introduction
S2662 strengths are its AGP 8X graphics and USB 2.0/1.1 capabilities. Remember to visit Tyan’s web site at http://www.tyan.com. There you can find information on all of Tyan’s products with FAQs, a complete distributors list, and BIOS setting explanations. - Page 5 • Wake-Up from S3 (suspend to RAM) • European Community CE (Declaration o f - PCI_PME# Conformity) - PS/2 keyboard, PS/2 mouse - USB activity/connect/disconnect (optional) - RTC - Power Button • Power-On from S4 (suspend to disk) and S5 - RTC - Power Button http://www.TYAN.com...
-
Page 6: Chapter 2: Board Installation
Ground yourself properly before removing your motherboard from the antistatic bag. Unplug the power from your computer power supply and then touch a safely grounded object to release static charge (i.e. power supply case). For the safest conditions, Tyan recommends wearing a static safety wrist strap. -
Page 7: Board Image
This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above picture. The following page includes details on the vital components of this motherboard. http://www.tyan.com... -
Page 8: Board Parts, Jumpers And Connectors
The board you receive may not look exactly like the above diagram. Jumper Legend Jumper OFF without jumper cover Jumper ON with jumper cover To indicate where the location of pin-1 To indicate where the location of pin-1 http://www.tyan.com... -
Page 9: Jumper And Connector Settings
(USB Port-C, USB Port-D, USB Close Pin-2 and Pin-3 (Default) Port-E and USB Port-F) Front panel USB devic es’ ACPI S1/S3/S4 wake up Front Panel Audio Connector Chassis Intrusion Connector Front Panel USB Header -1 Front Panel Connector Front Panel USB Header -2 http://www.tyan.com... - Page 10 2.5 – AUX Audio connector (J11) and CD Audio connector (J12) J11 (AUX Audio connector) Connects to internal audio sources such as TV tuner, MPEG, or other similar cards J12 (CD Audio connector) Connects to a CD-ROM drive via an optional CD audio cable http://www.tyan.com...
- Page 11 - Use jumper to close JP28 for several seconds to Clear CMOS - Take off jumper from JP28 (default setting) - Reconnect power supply to AC source - Power on system - Use “F2” key to go into system BIOS setup http://www.tyan.com...
- Page 12 Description MIC input Analog GND MIC power Analog VCC Right line Right line output return Left line Left line output return 2.11 – Chassis Intrusion Connector (J72) Pin-1 Intrusion cable detection (low asserted) Pin-2 Intrusion detection (low asserted) Pin-3 http://www.tyan.com...
- Page 13 Channel F Data negative Data negative Channel E Channel F Data positive Data positive Channel E Channel F connected 2.14 – OEM Reserved Connectors and Jumpers (J31 and J78) These connectors and jumpers are reserved for OEM use only. http://www.tyan.com...
-
Page 14: Mounting The Motherboard
These studs are usually manufacturer pre-installed, metal and are gold in color. If you are unsure of stud placement, lay the motherboard inside the chassis and align the studs. NOTE YOU MUST make sure that there are no studs where the re are no screw holes. http://www.tyan.com... -
Page 15: Installing The Memory
DDR200 and DDR266 memory modules can be used for FSB=400MHz Intel Pentium 4 processor but only DDR266 memory modules can be used for FSB=533MHz Intel Pentium 4 processor. For important memory information, please check Tyan’s web site at: www.tyan.com for recommendations. - Page 16 For memory performance, single memory channel solution is not recommended Dua l Memory Channel At least two unbuffered DDR ECC/non-ECC modules must be installed Memory modules must be installed in pairs DIMM1+DIMM2 or DIMM3+DIMM4 or DIMM1+DIMM2+DIMM3+DIMM4 Dual channel 128-bit memory bandwidth http://www.tyan.com...
- Page 17 To avoid bending and damaging your motherboard, place it on its anti -static bag and onto a flat surface, then proceed with memory installation. For important memory information, please check Tyan’s web site at www.tyan.com recommendations.
-
Page 18: Installing The Processor And Heatsink
2.18 – Installing the Processor and Heatsink The S2662 supports the mPGA478 Pentium 4 processors technologies from Intel. For important CPU information, please check Tyan’s web site at: www.tyan.com The following diagrams will detail how to install your processor: The processors you choose to use may not look exactly like the one pictured above, nor will the socket look exactly the same. - Page 19 (which should already be attached to the heatsink) to the motherboard. The following diagram illustrates how to connect fans onto the motherboard. After you have finished installing all the fans you can connect your drives (hard drives, CD -ROM drives, etc.) to your motherboard. http://www.tyan.com...
-
Page 20: Installing Add-In Cards
Before Continuing onto section Connecting External Devices , make sure everything is properly connected. Things like jumpers and case wiring are the most common causes of troubleshooting frustrations, both for the end -user and for any company doing technical support. http://www.tyan.com... -
Page 21: Connecting External Devices
SPDIF SPDIF RCA connector Sony/Philips Digital Interface (SPDIF) is the newest audio transfer file format. It provides impressive sound quality through this RCA connector and allows you to enjoy digital audio instead of analog audio. d. RJ45 LAN Port http://www.tyan.com... -
Page 22: Installing The Power Supply
4-pin square connector. The CPU won't be powered without connecting the 4 - pin square connector. ATX 12V (20-pin) connector + (4 -pin) connector YOU MUST unplug the power supply before plugging the 20-pin and 4 -pin cables NOTE to motherboard connectors. http://www.tyan.com... -
Page 23: Attaching Ide And Floppy Drive Cables
Attaching IDE drive cabling is simple. These cables are “keyed” to only allow them to be connected in the correct manner. Tyan motherboards have two on-board IDE channels, each supporting two drives. The black connector designates the Primary channel, while the white connector designates the Secondary channel. -
Page 24: Finishing Up
In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistanc e. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com... -
Page 25: Chapter 3:Bios
Use the left/right ( ) arrow keys to make a selection To display a sub-menu (A pointer “4” marks all sub menus) Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. http://www.tyan.com... -
Page 26: Bios Menu Bar
Select the previous value/setting of the field <F6> or <+> or <Space> Select the next value/setting of the field <F9> Load the default configuration values of the menu <F10> Save and exit <Enter> Execute command or select submenu <Alt-R> Refresh screen http://www.tyan.com... -
Page 27: Bios Main Menu
Select Yes when required to restore the manufacturer's defaults 3.3.4 – System Time Feature Option Description HH : MM : SS Set the system time 3.3.5 – System Date Feature Option Description MM : DD : YYYY Set the system date http://www.tyan.com... -
Page 28: Bios Advanced Menu
360 KB This setting selects the type of the 1.3 MB floppy disk drive installed in system. 720 KB 1.44/1.25 MB 2.88 MB Floppy Disk Contr oller Enabled This setting determines whether the Disabled floppy disk controller is activated. Auto http://www.tyan.com... - Page 29 Disabled – To turn off the port. Auto – To let BIOS configure the port automatically during POST Parallel Port Mode Bi-directional Output Only Parallel Port Base I/O Address Parallel Port Interrupt IRQ7 IRQ5 Parallel Port DMA Channel DMA3 DMA1 http://www.tyan.com...
- Page 30 This setting determines whether the Disabled option ROM of the PCI slot is loaded during system BIOS POST. Latency Timer Default This setting controls how long each 0020h PCI device can hold the bus before another PCI device takes over. 00E0h http://www.tyan.com...
-
Page 31: Bios Security Menu
Set to stay off to leave the computer in the power off state. Set to last state to restore the system to the previous status before power failure or interrupt occurred. Set to power on to leave the computer in the power on state. http://www.tyan.com... -
Page 32: Bios Boot Menu
AGP card 3.7.4 – Boot Device Priority Sub-Menu The boot menu will list all bootable devices. Arrange the priorities of all bootable devices by using arrow keys and then pressing <Enter>. http://www.tyan.com... -
Page 33: Bios Exit Menu
Use this option when system CMOS values have been corrupted or modified incorrectly. 3.8.4 – Discard Changes Use this option to restore all new setup values that you have made but not saved into CMOS. 3.8.5 – Save Changes Use this option to store all new setup values in to CMOS. http://www.tyan.com... -
Page 34: Chapter 4: Diagnostics
Graphics initialization failed Before contacting your vendor or Tyan Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution. -
Page 35: Appendix I: Glossary
SRAM instead of slower DRAM. Note that the cache is also much smaller than your regular memory: a typical cache size is 512KB, while you may have as much as 4GB of regular memory. http://www.tyan.com... - Page 36 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com ESCD (Extended System Configuration Data): a format for storing information about Plug -n- Play devices in the system BIOS.
- Page 37 RAID level 1 also allows for faster access time and fault -tolerance, since either hard drive can be read at the same time. RAID level 0+1 is both striping and mirroring, providing fault-tolerance, striping, and faster access all at the same time. RAIDIOS: RAID I/O Steering (Intel) http://www.tyan.com...
- Page 38 ZIF Socket (Zero Insertion Force socket): these sockets make it possible to insert CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...
-
Page 39: Technical Support
Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton a nd the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. http://www.tyan.com... - Page 40 D anger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D 1490 - 100 http://www.tyan.com...
