Tomcat i7210 S5112
User's Manual
///
Tomcat i7210
S5112
Revision 1.00
Copyright © TYAN Computer Corporation, 2004. All rights reserved. No part of this manual
may be reproduced or translated without prior written consent from TYAN Computer Corp.
All registered and unregistered trademarks and company names contained in this manual are
property of their respective owners including, but not limited to the following.
TYAN, Tomcat, i7210 and S5112 are trademarks of TYAN Computer Corporation.
Intel, Pentium 4, and combinations thereof are trademarks of Intel Corporation.
Award, AwardBIOS are trademarks of Award Software Incorporated.
Microsoft and Windows are trademarks of Microsoft Corporation.
Linux is a trademark of Linus Torvalds.
IBM, PC, AT and PS/2 are trademarks of IBM Corporation.
ATI, ATI RAGE is a trademark of ATI Technologies Incorporated.
Winbond is a trademark of Winbond Electronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer Corporation and has
been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability
whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of
TYAN products including liability or warranties relating to fitness for a particular purpose or
merchantability.
TYAN retains the right to make changes to product descriptions and/or
specifications at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting
from errors or inaccuracies of information contained in this document.
i
http://www.tyan.com
Advertisement
Table of Contents
Related Manuals for TYAN TOMCAT I7210
Summary of Contents for TYAN TOMCAT I7210
- Page 1 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
Tomcat i7210 S5112 Table of Contents Table of Contents Before you begin… ......................... iii Chapter 1: Introduction......................1-1 1.1 – Congratulations!...................... 1-1 1.2 – Hardware Specifications ..................1-1 Chapter 2: Board Installation ....................2-1 2.1 – Board Diagram ......................2-2 2.2 –... -
Page 3: Before You Begin
1x Tomcat i7210 S5112 motherboard 1x 34-Pin floppy drive cable 1x Ultra-DMA-133/100/66/33 IDE cable 1x Tomcat i7210 S5112 User’s Manual 1x Tomcat i7210 S5112 Quick Reference Guide 1x TYAN driver CD 1x I/O shield 1 x Serial ATA driver diskette... -
Page 4: Chapter 1: Introduction
You have purchased one of the most powerful server solutions for the Intel Pentium processor, the Tomcat i7210 S5112 based on the Intel E7210 chipset. The Tomcat i7210 S5112 is an ATX form factor server board and features two onboard Gigabit Ethernet ports, six Serial ATA RAID ports, two 64-bit PCI-X 66MHz slots, and an onboard ATI 8MB PCI RAGE XL controller. - Page 5 Microsoft Windows 2000 Advanced Server Microsoft Windows Server 2003 Microsoft Windows NT4.0 Red Hat 8.0, 9.0 SuSE Server 8.0 Other distributions of Linux pending validation TYAN reserves the right to add support or discontinue support for any OS with or without notice. http://www.tyan.com...
-
Page 6: Chapter 2: Board Installation
(i.e. power supply case). For the safest conditions, TYAN recommends wearing a static safety wrist strap. (2) Hold the motherboard by its edges and do not touch the bottom of the board, or flex the board in any way. -
Page 7: Board Diagram
Tomcat i7210 S5112 Chapter 2: Board Installation 2.1 – Board Diagram The above picture is purely representative. Due to engineering updates and new board revisions, certain components may change and or be repositioned. The picture above may or may not look exactly like the board you received. -
Page 8: Board Parts
Tomcat i7210 S5112 Chapter 2: Board Installation 2.2 – Board Parts This jumper diagram is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above diagram. -
Page 9: Jumper Settings & Definitions
Tomcat i7210 S5112 Chapter 2: Board Installation 2.3 – Jumper Settings & Definitions Jumper / Connector Function Ref. Page CMOS CMOS Clear See Section 2.3.1 P1FAN CPU fan connector See Section 2.3.2 FAN2 Chassis Fan Connector See Section 2.3.2 FAN3 Chassis Fan Connector See Section 2.3.2... - Page 10 Tomcat i7210 S5112 Chapter 2: Board Installation 2.3.1 - Clear CMOS Jumper Pin_3 Pin_3 Default Clear Pin_1 Pin_1 You can reset the CMOS settings by using this jumper if you have forgotten your system/setup password or need to clear system BIOS setting.
- Page 11 Chapter 2: Board Installation 2.3.3 - COM2 port (COM2, via a cable) Signal PIN # PIN # Signal 2.3.4 - SMDC Header Connect Server Management Daughter Card (SMDC) Compatible with Tyan M3289 (SMDC) See Appendix III for details about the Tyan SMDC http://www.tyan.com...
- Page 12 Chapter 2: Board Installation 2.3.5 – TYAN Front Panel Connector (TYFP) Your chassis will usually come with connectors to install onto the motherboard, such as HDD and Power LEDs. The TYAN Front Panel Connector (TYFP) has been implemented for such purposes. Function...
- Page 13 Tomcat i7210 S5112 Chapter 2: Board Installation 2.3.7 - Front USB Connector (USB2) Signal Signal Description Description USB Channel_0 USB Channel_1 Data - Data - USB Channel_0 USB Channel_1 Data + Data + 2.3.8 - Enable/Disable onboard ATI Rage XL graphics (JP3)
- Page 14 Tomcat i7210 S5112 Chapter 2: Board Installation 2.3.9 - Enable/Disable onboard 82541GI GbE NIC (JP4) Pin_3 Enable (Default) Pin_1 Pin_3 Disable Pin_1 2.3.10 - Enable/Disable onboard SI3114 SATA Controller (JP6) Pin_3 Enable (Default) Pin_1 Pin_3 Disable Pin_1 http://www.tyan.com...
- Page 15 Tomcat i7210 S5112 Chapter 2: Board Installation 2.3.11 – External Speaker Header (J8) Pin_1: Speaker + Pin_4 Pin_2: Buzzer - Pin_3: Speaker - Pin_1 Pin_4: Speaker - 2. 3.12 – Gigabit LAN1 LED Header (J27) & LAN2 LED Header (J29)
- Page 16 Tomcat i7210 S5112 Chapter 2: Board Installation 2.3.13 - Serial ATA Connectors (SATA1 & SATA2 & SATA3 & SATA4 & SATA5 & SATA6) SATA1/SATA2 (from Hance Rapids): RAID0, 1 function is supported SATA3/SATA4/SATA5/SATA6 (from Silicon Image SiI3114 chip): RAID0, 1, 10 function is supported.
-
Page 17: Mounting The Motherboard
TYAN recommends using metal studs with screws that will fasten the motherboard more securely in place. - Memory Type: The Tomcat i7210 S5112 supports unbuffered ECC and non-ECC type memory modules. Registered Memory is NOT supported. Below is a chart detailing what the most common motherboard studs look like and how they should be installed it. -
Page 18: Installing The Memory
The following diagram shows the types of RAM modules you may encounter depending on your board: DDR Unbuffered DDR Unbuffered ECC Here are a few key points to note before installing memory into your Tomcat i7210 S5112: • 128MB, 256MB, 512MB and 1GB unbuffered ECC and non-ECC PC2100/PC2700/PC3200 DDR memory modules are supported •... -
Page 19: Memory Installation Procedure
Tomcat i7210 S5112 Chapter 2: Board Installation • Supported System Bus Frequency and Memory Speed Combinations To use this type of DIMM… The processor’s system bus frequency must be… DDR400 800MHz DDR333 *800MHz or 533MHz *When using an 800MHz system bus frequency processor, DDR333 memory is clocked at 320MHz. -
Page 20: Installing The Processor And Heatsink
Tomcat i7210 S5112 Chapter 2: Board Installation 2.7 – Installing the Processor and Heatsink Your Tomcat i7210 S5112 supports the latest processor technologies from Intel. Check the following page on TYAN’s website for latest processor support: http://www.tyan.com The following diagrams will detail how to install your processor: The diagram is provided as a visual guide to help you install socket processors and may not be an exact representation of the processors you have. - Page 21 Tomcat i7210 S5112 Chapter 2: Board Installation Heatsink Installation After you are done installing the processor, you should proceed to installing the heatsink. The heatsink will ensure that the processor does not overheat, and will continue to operate at maximum performance. An overheated processor is also dangerous to the long-term reliability of the motherboard.
-
Page 22: Attaching Drive Cables
Attaching IDE drive cabling is simple. These cables are “keyed” to only allow them to be connected in the correct manner. TYAN motherboards have two on-board IDE channels, each supporting two drives. The black connector designates the Primary channel, while the white connector designates the Secondary channel. - Page 23 Tomcat i7210 S5112 Chapter 2: Board Installation Serial ATA Attaching Serial ATA cables to the Serial ATA connectors is illustrated below: Se rial ATA Hard drive Serial ATA Cable Serial ATA Connector Serial ATA Cable Power Cable Simply plug in the BLACK END of the Serial ATA cable into the motherboard Serial ATA connector, and the other end(s) into the drive(s).
-
Page 24: Installing Add-In Cards
Tomcat i7210 S5112 Chapter 2: Board Installation Below are some symptoms of incorrectly installed floppy drives. While they are minor and installing them incorrectly doesn’t cause severe problems, it may cause your system to freeze or crash when trying to read and/or write to diskettes. -
Page 25: Connecting External Devices
Tomcat i7210 S5112 Chapter 2: Board Installation 2.10 – Connecting External Devices Connecting external devices to the motherboard is an easy task. The standard devices you should expect to plug into the motherboard are keyboards, mouse, and printer cables. The... -
Page 26: Installing The Power Supply
Tomcat i7210 S5112 Chapter 2: Board Installation 2.11 – Installing the Power Supply There are two power connectors on this motherboard. By default, this motherboard requires that you have an ATX12V power supply that has the standard ATX-style 20-pin connector, as well as an additional 4-pin square connector. -
Page 27: Chapter 3: Bios Setup
Tomcat i7210 S5112 Chapter 3: BIOS Setup Chapter 3: BIOS Setup Installation The BIOS is the basic input/output system, the firmware on the motherboard that enables your hardware to interface with your software. This chapter describes different settings for the BIOS that can be used to configure your system. - Page 28 Chipset section unless you are absolutely sure of the outcome. The Chipset defaults were carefully chosen by TYAN or your system manufacturer for the best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.
-
Page 29: Main Bios Setup
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.1 – Main BIOS Setup When you enter Phoenix - AwardBIOS CMOS Setup Utility, the following screen will appear as below: Phoenix – AwardBIOS CMOS Setup Utility ► Standard CMOS Features ► Frequency/Voltage Control ►... - Page 30 Tomcat i7210 S5112 Chapter 3: BIOS Setup Load Optimized Defaults Use this menu to load the BIOS default values that are factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs.
-
Page 31: Standard Cmos Features
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.2 – Standard CMOS Features In this section, you can alter general features such as the date and time, as well as access to the IDE configuration options. Note that the options listed below are for options that can directly be changed within the Main Setup screen. - Page 32 Tomcat i7210 S5112 Chapter 3: BIOS Setup Drive A / B: Defines the floppy drive type. None / 360K, 5.25in / 1.2M, 5.25in / 720K, 3.5in / 1.44M, 3.5in / 2.88M, 3.5in Video: Defines video display mode. EGA/VGA / CGA 40 / CGA 80 / MONO Halt On: Determines if the computer should stop when an error is detected during power up.
-
Page 33: Advanced Bios Features
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.3 – Advanced BIOS Features In Advanced BIOS features, you will be able to adjust many of the feature that effect system speed and boot-up options. Phoenix – AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU L1 &... - Page 34 Tomcat i7210 S5112 Chapter 3: BIOS Setup Gate A20 Option: Select if chipset or keyboard controller should control GateA20. When set to Fast, the system chipset controls Gate A20. When set to Normal, a pin in the keyboard controller controls Gate A20.
- Page 35 Tomcat i7210 S5112 Chapter 3: BIOS Setup Small Logo (EPA) Show: Toggles the display of the EPA Energy Star logo at POST. Enabled / Disabled Boot Sequence: Phoenix – AwardBIOS CMOS Setup Utility Boot Sequence ►Hard Disk Boot Priority [Press Enter]...
- Page 36 Tomcat i7210 S5112 Chapter 3: BIOS Setup Console Redirection: Phoenix – AwardBIOS CMOS Setup Utility Console Redirection Console Redirection [Disabled] Item Help Baud Rate [9600] _________________________ Agent after boot [Disabled] Menu Level ►► [Enabled] Attempt to redirect console via COM port...
- Page 37 Tomcat i7210 S5112 Chapter 3: BIOS Setup DMI Event Log: Phoenix – AwardBIOS CMOS Setup Utility DMI Event Log DMI Event Log [Enabled] Item Help Clear All DMI Event Log [No] _________________________ View DMI Event Log [Enter] Mark DMI Events as Read [Enter] Menu Level ►►...
-
Page 38: Advanced Chipsets Features
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.4 – Advanced Chipsets Features In Advanced Chipset Features, you will be abled to adjust many of the chipset special features. Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Features DRAM Timing Selectable... - Page 39 Tomcat i7210 S5112 Chapter 3: BIOS Setup System BIOS Cacheable: Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result.
-
Page 40: Integrated Peripherals
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.5 – Integrated Peripherals Options related to onboard peripheral features can be altered through the following: Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals ► OnChip IDE Device [Press Enter] Item Help ► Onboard Device... - Page 41 Tomcat i7210 S5112 Chapter 3: BIOS Setup IDE HDD Block Mode: Leave this setting as is. Enabled / Disabled On-Chip Primary PCI IDE: The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select “Enabled” to activate each channel separately.
- Page 42 Tomcat i7210 S5112 Chapter 3: BIOS Setup USB Controller: This item allows you to “Enable” or “Disable” onboard USB function. Enabled / Disabled / 1&2 USB Port / 2&3 USB Port / 1&3 USB Port / 1 Port / 2 Port / 3 Port USB 2.0 Controller:...
- Page 43 Tomcat i7210 S5112 Chapter 3: BIOS Setup Super IO Controller: Phoenix – AwardBIOS CMOS Setup Utility Super IO Device Onboard FDC Controller [Enabled] Item Help Onboard Serial Port 1 [3F8 / IRQ4] _________________________ Onboard Serial Port 2 [2F8 / IRQ3]...
- Page 44 Tomcat i7210 S5112 Chapter 3: BIOS Setup 378/IRQ7 / 278/IRQ5 / 3BC/IRQ7 / Disabled Parallel Port Mode: This field allows the user to select the parallel port mode. SPP / EPP / ECP / ECP+EPP EPP Mode Select: This item allows you to determine the IR transfer mode of onboard I/O chip.
-
Page 45: Power Management Setup
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.6 – Power Management Setup Options related to power management can be altered through the following: Phoenix – AwardBIOS CMOS Setup Utility Power Management Setup ACPI Function [Enabled] Item Help ACPI Suspend Type... - Page 46 Tomcat i7210 S5112 Chapter 3: BIOS Setup Suspend Type: Defines the suspend type from Stop Grant or Power On Suspend. Stop Grant/ Power On Suspend MODEM Use IRQ: Name the interrupt request (IRQ) line assigned to the modem (if any) on your system. Activity of the selected IRQ always awakens the system.
- Page 47 Tomcat i7210 S5112 Chapter 3: BIOS Setup PWRON After PWR- Fail: Defines the state when the system power failure and returns again. On / Off / Former- Sts(Former Status) Soft-off by PWR-BTTN : Defines the system power- on method when push Power Button .
- Page 48 Tomcat i7210 S5112 Chapter 3: BIOS Setup Reload Global Timer Events: Phoenix – AwardBIOS CMOS Setup Utility Reload Global Timer Events Primary IDE 0 [Disabled] Item Help Primary IDE 1 [Disabled] _________________________ Secondary IDE 0 [Disabled] Secondary IDE 1 [Disabled] Menu Level ►►►...
-
Page 49: Pnp/Pci Configurations
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.7 – PnP/PCI Configurations Options related to all the configurations of PnP / PCI resources. Phoenix – AwardBIOS CMOS Setup Utility PnP / PCI Configurations Reset Configuration Data [Disabled] Item Help _________________________ Resources Controlled By... -
Page 50: Pc Health Status
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.8 – PC Health Status This menu is related to detecting system temperature, voltage, fan and speed. Phoenix – AwardBIOS CMOS Setup Utility PC Health Status CPU FAN Speed Control Item Help [100% Speed] Current CPU Temp. -
Page 51: Frequency/Voltage Control
↑↓←→: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults CPU Clock Ratio: Sets the CPU multiplier. TYAN does not recommend changing this setting from the default setting. 16X…22X / Auto / Default Auto Detect DIMM / PCI Clk: Sets the BIOS to automatically adjust PCI and memory bus speeds accordingly. -
Page 52: Load Fail-Safe Defaults
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.10 – Load Fail-Safe Defaults Phoenix – AwardBIOS CMOS Setup Utility ► Standard CMOS Features ► Frequency/Voltage Control ► Advanced BIOS Features Load Fail-Safe Defaults ► Advanced Chipset Features Load Optimized Defaults ► Integrated Peripherals Set Supervisor Password ►... -
Page 53: Supervisor/User Password Setting
Tomcat i7210 S5112 Chapter 3: BIOS Setup 3.12 – Supervisor/User Password Setting Phoenix – AwardBIOS CMOS Setup Utility ► Standard CMOS Features ► Frequency/Voltage Control ► Advanced BIOS Features Load Fail-Safe Defaults ► Advanced Chipset Features Load Optimized Defaults ► Integrated Peripherals Set Supervisor Password ►... -
Page 54: Exit Selecting
Tomcat i7210 S5112 Chapter 3: BIOS Setup Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>. You may also press <Esc>... - Page 55 Tomcat i7210 S5112 Chapter 3: BIOS Setup Exit Without Saving Phoenix – AwardBIOS CMOS Setup Utility ► Standard CMOS Features ► Frequency/Voltage Control ► Advanced BIOS Features Load Fail-Safe Defaults ► Advanced Chipset Features Load Optimized Defaults ► Integrated Peripherals Set Supervisor Password ►...
-
Page 56: Chapter 4: Diagnostics
The most common type of error is a memory error. Before contacting your vendor or TYAN Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution. -
Page 57: Appendix I: Glossary
Tomcat i7210 S5112 Appendix I: Glossary Appendix I: Glossary ACPI (Advanced Configuration and Power Interface): a power management specification that allows the operating system to control the amount of power distributed to the computer’s devices. Devices not in use can be turned off, reducing unnecessary power expenditure. - Page 58 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com...
- Page 59 Form factor: an industry term for the size, shape, power supply type, and external connector type of the Personal Computer Board (PCB) or motherboard. The standard form factors are the AT and ATX, although TYAN also makes some Baby-AT and ATX Footprint boards. Global timer: onboard hardware timer, such as the Real-Time Clock (RTC).
- Page 60 Tomcat i7210 S5112 Appendix I: Glossary Latency: the amount of time that one part of a system spends waiting for another part to catch up. This is most common when the system sends data out to a peripheral device, and it waiting for the peripheral to send some data back (peripherals tend to be slower than onboard system components).
- Page 61 Tomcat i7210 S5112 Appendix I: Glossary RAID (Redundant Array of Independent Disks): a way for the same data to be stored in different places on many hard drives. By using this method, the data is stored redundantly, also the multiple hard drives will appear as a single drive to the operating system. RAID level 0 is known as striping, where data is striped (or overlapped) across multiple hard drives, but offers no fault-tolerance.
- Page 62 Tomcat i7210 S5112 Appendix I: Glossary SSI (Server System Infrastructure): an industry initiative intended to provide ready-to-use design specifications for common server hardware elements (chassis, power supplies, and racks) to promote and support server industry growth. Standby mode: in this mode, the video and hard drives shut down; all other devices continue to operate normally.
-
Page 63: Appendix Ii: Post Error Code For Bios
Tomcat i7210 S5112 Appendix II: Post Error Code for BIOS Appendix II: Post Error Code for BIOS POST (hex) Description Test CMOS R/W functionality. CFh: Early chipset initialization: C0h: -Disable shadow RAM -Disable L2 cache (socket 7 or below) -Program basic chipset registers... - Page 64 Tomcat i7210 S5112 Appendix II: Post Error Code for BIOS POST (hex) Description Detect CPU information including brand, SMI type (Cyrix or Intel) and 18h: CPU level (586 or 686). Initial interrupts vector table. If no special specified, all H/W interrupts are 1Bh: directed to SPURIOUS_INT_HDLR &...
- Page 65 Tomcat i7210 S5112 Appendix II: Post Error Code for BIOS POST (hex) Description Test DMA Channel 1. 37h: Test DMA page registers. 39h: Test 8254 3Ch: Test 8259 interrupt mask bits for channel 1. 3Eh: Test 8259 interrupt mask bits for channel 2.
- Page 66 Tomcat i7210 S5112 Appendix II: Post Error Code for BIOS POST (hex) Description Prepare memory size information for function call: INT 15h ax=E820h 67h: Turn on L2 cache 69h: Program chipset registers according to items described in Setup & Auto- 6Bh: configuration table.
- Page 67 Tomcat i7210 S5112 Appendix II: Post Error Code for BIOS E8POST.ASM starts Description 1. Call chipset power management hook. 82h: 2. Recover the text fond used by EPA logo (not for full screen logo) 3. If password is set, ask for password.
-
Page 68: Appendix Iii: Smdc Information
Tyan SMDC is not a peripheral card. Unlike regular peripheral card such as AGP card, Network card or SCSI card, SMDC does not require any hardware specific driver. As long as a standby power comes into the system, SMDC will begin looking after the system. -
Page 69: Technical Support
Help Resources: 1. See the beep codes section of this manual. 2. See the TYAN website for FAQ’s, bulletins, driver updates, and other information: http://www.tyan.com 3. Contact your dealer for help BEFORE calling TYAN. 4. Check the TYAN user group: alt.comp.periphs.mainboard.TYAN... - Page 70 Tomcat i7210 S5112 Appendix III: SMDC Information Notice for the USA Compliance Information Statement (Declaration Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation.
