Tiger i7520SD
S5365
Version 1.2
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN, Tiger i7520SD are trademarks of TYAN Computer Corporation.
Intel, Sossaman, and combinations thereof are trademarks of Intel Corporation.
Phoenix, Phoenix-AwardBIOS are trademarks of Phoenix Technologies.
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE,is a trademark of SuSE AG.
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Notice
Information contained in this document is furnished by TYAN Computer
Corporation and has been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN products including liability or
warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications
at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
1

Advertisement

Table of Contents
loading

Related Manuals for TYAN TIGER I7520SD

Summary of Contents for TYAN TIGER I7520SD

  • Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.

  • Page 2: Table Of Contents

    Table of Contents Check the box contents! Chapter 1: Introduction Congratulations…………………………………………………………… Hardware Specifications………………………………………………… Chapter 2: Board Installation Board Image……………………………………………………………… Block Diagram……………………………………………………………. Board Parts, Jumpers and Connectors………………………………... Tips on Installing Motherboard in Chassis…………………………….. 18 Installing the Processor, Heatsink & Fan………………………………............19 Installing the Memory…………………………………………………….

  • Page 3: Check The Box Contents

    2 x Serial ATA Cable 1 x S5365 user’s manual 1 x S5365 Quick Reference guide 1 x TYAN driver CD 1 x I/O shield If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process.

  • Page 5: Chapter 1: Introduction

    S5365 offers exceptional performance and versatile solution for your server platform. Remember to visit TYAN’s Website at http://www.TYAN.com. There you can find information on all of TYAN’s products with FAQs, online manuals and BIOS upgrades. 1.2 - Hardware Specifications...
  • Page 6 •One (1) shrouded header for serial port •One (1) printed port header System Management •Total five (5) 3-pin fan headers •One (1) TYAN FPIO2 •One (1) TYFP FPIO header with control and tachometer monitoring •Monitors voltage for CPU, Form Factor •ATX 12”...

  • Page 7: Chapter 2: Board Installation

    Chapter 2: Board Installation You are now ready to install your motherboard. The mounting hole pattern of the Tiger i7520SD S5365 matches the ATX specification. Before continuing with installation, confirm that your chassis supports an ATX motherboard. How to install our products right… the first time The first thing you should do is reading this user’s manual.

  • Page 8: Board Image

    2.1- Board Image This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above picture. 2.2 - Block Diagram...
  • Page 9 Tiger i7520SD S5365G3NR Block Diagram...

  • Page 10: Board Parts, Jumpers And Connectors

    2.3 - Board Parts, Jumpers and Connectors DDRII B4 DDRII A4 DDRII B3 DDRII A3 DDRII B2 CPU1 DDRII A2 VG A1 DDRII B1 DDRII A1 CPU2 CPU2 E7520 LAN 1 PCIE PCIE PCI 33 6300ESB PCI 33 PCI X BIOS IDE1 PCI X...
  • Page 11 Jumper/Connector Function COM1 Connector Keyboard & Mouse Connectors IPMB Connector LAN Connectors J5/J14/J18 Chassis Fan Connector Tyan TARO Connector COM2 Connector J16/J22 CPU Fan Connector Front Panel 1 Header Front Panel 2 Header USB 2.0 Connector SATA1 Connector SATA2 Connector...
  • Page 12 CCMOS1 J24: LCM Module Header Signal Signal COM2_SIN 5VDUAL COM2_SOUT this header to connect the LCM module with system monitoring function. This header is reserved for barebone use.
  • Page 13 CCMOS1: Clear CMOS Jumper Use this jumper when you forgot your system/setup password or need to clear system BIOS setting. How to clear the CMOS data Normal Power off system and disconnect power (Default) supply from AC source Use jumper cap to close Pin_2 and 3 for several seconds to Clear CMOS Replace jumper cap to close Pin_1 and 2 Reconnect power supply to AC source...
  • Page 14 J20: USB2.0 Connector Signal Signal Use these headers to connect to the USB devices via the enclosed USB cable.
  • Page 15 J17: Front Panel 1 Header The Front Panel Header is used to connect some control or signal wires from motherboard to chassis, such as HDD LED, power LED, power button, and reset button. HDDLED+ PWR LED+ HDDLED- PWR LED- PWR SW+ Reset SW+ PANSWIN VCC3...
  • Page 17 J14 (FAN1): Chassis Fan Connector Sensor Use this header to connect the chassis cooling P WR fan to your motherboard to keep the system at optimum performance levels. J5 (FAN2)/J18(FAN3): Chassis Fan Connectors S en sor Use this header to connect the chassis cooling fan to your motherboard to keep the system at optimum performance levels.

  • Page 18: Tips On Installing Motherboard In Chassis

    Some chassis’ include plastic studs instead of metal. Although the plastic studs are usable, TYAN recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look...

  • Page 19: Installing The Processor, Heatsink & Fan

    2.5 - Installing the Processor, Heatsink & Fan Your Tiger i7520SD S5365 supports the latest processor technologies from Intel. Check the TYAN website for latest processor support: http://www.tyan.com CPU & Heatsink Installation The processor should be installed carefully. Make sure you are wearing an antistatic strap and handle the processor as little as possible.
  • Page 20 Install the retention module into the CPU socket from the reverse of motherboard. Tear off the stick on the retention module before installing. Place the heatsink on the CPU. Use a screw driver to fix the installation of heatsink.
  • Page 21 Follow the direction suggested as below to finish the installation. Cooling Fan Installation After you have installed the processor, the heatsink should be installed to ensure that the processor runs efficiently and does not overheat. Use the heatsink supplied for best results. Follow these instructions to install the heatsink shown.

  • Page 22: Installing The Memory

    Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Only DDRII 400 modules are required. Check the TYAN Web site at: www.tyan.com for details of the type of memory recommended for your motherboard.
  • Page 23 Memory Installation Procedure Follow these instructions to install memory modules into the S5365. Press the locking levers in the direction shown in the following illustration. Align the memory module with the socket. The memory module is keyed to fit only one way in the socket. Key slot Seat the module firmly into the socket by gently pressing down until it sits flush with the socket.

  • Page 24: Attaching Drive Cables

    Attaching IDE Drive Cable Attaching the IDE drive cable is simple. These cables are “keyed” to only allow them to be connected in the correct manner. TYAN motherboards have two on-board IDE channels, each supporting two drives. The black connector designates the Primary channel, while the white connector designates the Secondary channel.
  • Page 25 Tyan has supplied two SATA cables and one SATA power adapter. If you are in need of other cables or power adapters please contact your place of purchase. The following pictures illustrate how to connect an SATA drive 1.SATA drive cable connection 2.

  • Page 26: Installing Add-In Cards

    2.8 - Installing Add-In Cards Before installing add-in cards, it’s helpful to know if they are fully compatible with your motherboard. For this reason, we’ve provided the diagrams below, showing the slots that appear on your motherboard. PCI Express x8 Slot PCI-X (64/133) PCI Slot Simply find the appropriate slot for your add-in card and insert the card...

  • Page 27: Connecting External Devices

    2.9 - Connecting External Devices The following diagrams will detail the rear port stack for this S5365 motherboard: PS/2 Mouse/Keyboard 10/100 LAN Port + USB x 2 Gigabit Ethernet x 2 VGA Port Serial Port NOTE: Peripheral devices can be plugged straight into any of these ports but software may be required to complete the installation.

  • Page 28: Installing The Power Supply

    2.10 - Installing the Power Supply There are two power connectors on your Tiger i7520SD S5365. The Tiger i7520SD S5365 requires that you have an EPS12V power supply that has a 24- pin and an 8-pin power connector. Please be aware that ATX 2.x, ATX12V and ATXGES power supplies may not be compatible with the board and can damage the motherboard and/or CPU(s).

  • Page 29: Chapter 3: Bios Setup

    Chapter 3: BIOS Setup 3.1. About the BIOS The BIOS is the basic input/output system, the firmware on the motherboard that enables your hardware to interface with your software. The BIOS determines what a computer can do without accessing programs from a disk. The BIOS contains all the code required to control the keyboard, display screen, disk drives, serial communications, and a number of miscellaneous functions.
  • Page 30 Chipset section unless you are absolutely sure of what you are doing. The Chipset defaults have been carefully chosen either by TYAN or your system manufacturer for best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.

  • Page 31: Bios Main Menu

    3.2 BIOS Main Menu In this section, you can alter general features such as the date and time, as well as access to the IDE configuration options. Note that the options listed below are for options that can directly be changed within the Main Setup screen. System Time / Date setup System Time: Adjusts the system clock.
  • Page 32 Extended Memory This displays/allows you to change the amount of extended memory present on the system.
  • Page 33 3.2.1 IDE Channel 0/1 Master/Slave Setup Computer detects IDE drive type from drive C to drive F. Press Enter on any of the Channel 0 Master/Slave or Channel 1 Master/Slave options to view advanced details of the corresponding drive. The system displays advanced details like the number of heads/cylinders/sectors on the detected disk and the maximum storage capacity of the disk.
  • Page 34 system for use in Int 13h calls. The difference between LBA and ECHS is that when using ECHS the BIOS translates the parameters used by these calls from the translated geometry to the drive's logical geometry. With LBA, it translates from the translated geometry directly into a logical block (sector) number.
  • Page 35 3.2.2 Memory Cache This setting allows you to tweak the various cache settings for optimal performance of your system. Press Enter to display the various cache settings. Cache System BIOS Area This feature is only available when the system BIOS is shadowed. It enables or disables the caching of the system BIOS ROM at F0000h-FFFFFh via the L2 cache.
  • Page 36 As such, it would be a waste of L2 cache bandwidth to cache the video BIOS instead of data that are more critical to the system's performance. In addition, if any program writes into this memory area, it will result in a system crash. So, it is recommended that you write protect this area for optimal system performance.
  • Page 37 3.2.3 Boot Features This option allows setting boot parameters. Press Enter to view the Boot Features screen. Floppy Check This feature is used to verify floppy type on boot. Selecting “Disabled” will speed the boot process. Disabled / Enabled Summary Screen Enables or disables the display of the summary screen during boot up.
  • Page 38 Quick Boot Mode This BIOS feature allows you to decrease the time it takes to boot up the computer by shortening or skipping certain standard booting procedures. If enabled, the BIOS will shorten the booting process by skipping some tests and shortening others.

  • Page 39: Advanced Menu

    3.3 Advanced Menu This section facilitates configuring advanced BIOS options for your system. Installed OS Select the operating system installed on the PC. Note: An incorrect setting can cause the operating system to behave unpredictably. Win OS / Other Reset Configuration Data If you install a new piece of hardware or modify your computer's hardware configuration, the BIOS will automatically detect the changes and reconfigure the ESCD (Extended SystemConfiguration Data).
  • Page 40 Please note that the BIOS will automatically reset it to the default setting of No after reconfiguring the new ESCD. So, there is no need for you to manually disable this feature after rebooting. Yes / No Large Disk Access Mode This option determines whether a hard drive with more than 1024 cylinders, more than 16 heads and or more than 64 tracks per sector is present on the system.
  • Page 41 3.3.1 Advanced Chipset Control This section allows you to fine tune the chipset configuration. DRAM Data Integrity Mode If you have ECC memory modules installed, select the correct ECC mode with this setting. Disabled / 72-bit ECC / 144-bit ECC / Auto ECC Error Type When an ECC error occurs, it generates an interrupt.
  • Page 42 Memory RAS Feature Control This option is used to select the special feature of DIMM sparing or memory mirroring. Mirroring / Standard / Sparing 4GB PCI Hole Granularity This feature is used to select the granularity of PCI hole for PCI resource. If MTRRs are not enough, we may use this option to reduce the MTRR occupation.
  • Page 43 3.3.1.1 Integrated Device Control Sub-Menu OnChip USB Controller This option enables or disables IRQ allocation for the USB (Universal Serial Bus) controller. Enable this if you are using a USB device. If you disable this while using a USB device, you may have problems running that device. However, if you don't use any USB devices, set the option to Disabled.
  • Page 44 OnChip PCI-E LAN1 Controller This option is used to enable/disable OnChip PCI-E LAN1 controller. Enabled / Disabled Invoke Boot Agent This option is used to enable/disable Lan Boot ROM during BIOS post. Disabled / Disabled...
  • Page 45 3.3.2 Advanced Processor Options This section allows you to fine-tune the processor options. Processor Power Management This option is used to select the Processor Power Management desired. Disabled: C States and GV1/GV3 are disabled. GV1/GV3 Only: C States are disabled. Processor Enable This option is used to enable the CPU for use by the operating system.
  • Page 46 3.3.3 I/O Device Configuration This setting allows you to configure I/O devices. Floppy Disk Controller This defines how the floppy disk controller is detected and configured. Enabled/ Disabled Serial Port A: This defines how the first serial port is detected and configured. Enabled / Disabled Base I/O address: This feature is used to set the base I/O address for serial port A.
  • Page 47 Mode This feature is used to set the mode for serial port B. Normal / IrDA / ASK-IR Base I/O address: This feature is used to set the base I/O address for serial port B. 2F8 / 3F8 / 3E8 / 2E8 Interrupt This feature is used to set the interrupt for serial port A.
  • Page 48 3.3.4 Console Redirection Com Port Address If enabled it will use a port on the motherboard. Disabled / On-board COM A / On-board COM B Baud Rate This feature is used to enable the specified baud rate. 19.2K / 300 / 1200 / 2400 / 9600 / 38.4K / 57.6K / 115.2K Console Type This feature is used to enable the specified console type.
  • Page 49 3.3.5 DMI Event Logging Event Logging Select Enabled to allow logging of DMI events Enabled/ Disabled ECC Event Logging Select Enabled to allow logging of ECC events Enabled/ Disabled Mark DMI events as read Press <Enter> to mark DMI events as read. Clear all DMI event logs Setting this to ‘Yes’...
  • Page 50 3.3.6 Hardware Monitor Chassis Detection This feature is used to enable/disable the function: when chassis open event is detected, BIOS will record the event. Disabled / Enabled...
  • Page 51 3.3.6.1 Voltage Monitoring...
  • Page 52 3.3.6.2 Fan Speed Monitoring...
  • Page 53 3.3.6.3 Temperature Monitoring...
  • Page 54 3.3.6.4 Smart Fan Control...

  • Page 55: Security Menu

    3.4 Security Menu These settings allow you to configure the security options for your system. The system displays the current supervisor and user passwords. Diskette access This option allows the user to control access to diskette drives. Supervisor / Disabled Fixed disk boot sector This option allows the user to write protect boot sector on hard disk to protect against viruses.
  • Page 56 Password on boot When enabled, the system will ask for a password at every boot. The system will continue booting only if the correct password is entered. If the wrong password is entered three times, the system will automatically shut down. Disabled / Enabled...

  • Page 57: Power Menu

    3.5 Power Menu These settings allow you to configure the power options for your system. Resume on Modem Ring When enabled, the system will be waked up when an incoming call is detected on the system. Off / On Resume On Time When enabled, this allows the system to be worked up at a specified time.

  • Page 58: Boot Menu

    3.6 Boot Menu Use this screen to select options for the Boot Settings Configuration. The boot menu will list all bootable devices. Use <Enter> to expand or collapses devices with a ‘+’ or ‘-‘. Use <+> or <-> to arrange the priorities of all bootable devices.

  • Page 59: Exit Menu

    3.7 Exit Menu These settings set the exit options on your system. Exit Saving Changes This exits BIOS setup after saving the changes made. Exit Discarding Changes This exits BIOS setup after discarding the changes made. Load Setup Defaults Loads the factory default values. Discard Changes Discards all changes made without exiting BIOS setup.
  • Page 60 NOTE...

  • Page 61: Chapter 4: Diagnostics

    The most common type of error is a memory error. Before contacting your vendor or TYAN Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution.

  • Page 62: Bios Post Code

    4.3 - BIOS Post Code BootBlock POST Code List : Post Mnemonic Post Routine Description Code (Port TP_BB_CS_INIT Initializes the host PCI device. TP_BB_BRIDGE_INIT Initializes the SMB support. TP_BB_CPU_INIT Initializes the CPU if needed. TP_BB_TIMER_INIT Initializes timer. TP_BB_IO_INIT Configures I/O floppy and LPT port. TP_BB_FORCE Checks for a forced flash.
  • Page 63 Main BIOS POST Code List : Post Mnemonic Post Routine Description Code (Port TP_IPMI_INIT Initializes the IPMI interface and check BMC status. (Optional) TP_VERIFY_REAL Verifies if the CPU is in real mode from cold start. TP_DISABLE_NMI Disables NMIs. TP_GET_CPU_TYPE Gets CPU Type. TP_HW_INIT Miscellaneous hardware initialization.
  • Page 64 TP_8742_TEST Report if there was a keyboard controller failure. TP_SET_HUGE_ES Makes huge (4GB) segments for DS, ES, FS, GS, SS. TP_ENABLE_A20 (Optional) TP_SIZE_RAM Determines DRAM size and configure the chipset accordingly. TP_PMM_INIT Initializes the POST Memory Manager. TP_ZERO_BASE Zeros the RAM up to minimum RAM specified in the chipset RAM table.
  • Page 65 TP_QUIETBOOT_START (Optional) TP_VID_SHADOW Shadows the video BIOS. TP_CR_DISPLAY Displays the copyright message. TP_MULTBOOT_INIT Allocates storage for the old and new history tables. (Optional) TP_CPU_DISPLAY Displays CPU type and speed. TP_EISA_INIT (Optioanl) TP_KB_TEST Initializes and configures the keyboard and PS/2 mouse. TP_KEY_CLICK (Optional) TP_USB_INIT...
  • Page 66 TP_ERROR_MSGS Displays any errors found. TP_TEST_CONFIG Checks for bad configurations. TP_RTC_TEST (Optional) TP_KEYBOARD Reports if there was a keyboard or controller failure. TP_KEYLOCK (Optional) TP_HW_INTS Initializes hardware interrupt vectors. TP_ISM_INIT (Optional) TP_COPROC Tests for coprocessor. TP_IO_BEFORE (Optional) TP_LATE_DEVICE_INIT POST device initialization routine. (Optional) TP_RS232 (Optional)
  • Page 67 TP_CLEAR_HUGE_ES Performs a shutdown eight to transition from the warm start table to the cold start table. (Optional) TP_MP_FIXUP Fix-up MP table physical pointer and checksum. (Optional) TP_ROM_SCAN Configures Non-PCC PnP ISA devices, PCI IRQs, enables PCI devices and rom scan. TP_FDISK_CHECK_SMART POST task to check SMART status.
  • Page 68 and in extended memory. (Optional) TP_SYSEM_INIT (Optional) TP_PREPARE_BOOT Cleans up all graphics before booting. TP_DMI Executes DMI handlers. (Optional) TP_INIT_BCVS (Optional) TP_PARITY Clears the parity error latch, set correct NMI state. TP_BOOT_MENU Displays boot first menu. (Optional) TP_CLEAR_SCREEN Clears the screen. TP_CHK_RMDR Checks the reminder features.
  • Page 69 TP_FORCE Forces check. (Optional) TP_A20_TEST Performs A20 test. (Optional) TP_EXT_CHECKSUM Checks (and do) if flash recovery is necessary. TP_EISA_BEFORE_INIT (Optional) TP_SERIAL_KEY (Optional) TP_EISA_AFTER_INIT (Optional) TP_ROMRAM (Optional) TP_SAVE_MEMCFG (Optional) TP_SERIAL_VID (Optional) TP_RESTORE_MEMCFG (Optional) TP_PCMATA (Optional) TP_CONSOLE_VECTOR Reclaims console vector after H/W vectors are initialized.

  • Page 70: Appendix: How To Make A Driver Diskette

    Appendix 1: How to Make a Driver Diskette Follow the steps below to make a driver diskette from the TYAN driver CD provided Insert the Driver CD into the CD-ROM drive and copy the RAID driver from¡ @ \drivers\Windows\RAID\ESB RIAD Driver 6.075.2.3\ to the floppy disk in another Windows system 2.¡...

  • Page 71: Glossary

    Glossary ACPI (Advanced Configuration and Power Interface): a power management specification that allows the operating system to control the amount of power distributed to the computer’s devices. Devices not in use can be turned off, reducing unnecessary power expenditure. AGP (Accelerated Graphics Port): a PCI-based interface which was designed specifically for demands of 3D graphics applications.
  • Page 72 Bus: a data pathway. The term is used especially to refer to the connection between the processor and system memory, and between the processor and PCI or ISA local buses. Bus mastering: allows peripheral devices and IDEs to access the system memory without going through the CPU (similar to DMA channels).
  • Page 73 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com EMRL: Embedded RAID Logic.
  • Page 74 IDE (Integrated Device/Drive Electronics): a simple, self-contained HDD interface. It can handle drives up to 8.4 GB in size. Almost all IDEs sold now are in fact Enhanced IDEs (EIDEs), with maximum capacity determined by the hardware controller. IDE INT (IDE Interrupt): a hardware interrupt signal that goes to the IDE. I/O (Input/Output): the connection between your computer and another piece of hardware (mouse, keyboard, etc.) Initial Program Load (IPL): a feature built into BBS-compliant devices, describing...
  • Page 75 PCI-to-PCI bridge: allows you to connect multiple PCI devices onto one PCI slot. Pipeline burst SRAM: a type of RAM that can maintain it’s data as long as power is provided to the memory chips. In this configuration, SRAM requests are pipelined, which means that larger packets of data are sent to the memory at one time, and acted upon quickly.
  • Page 76 RAM (Random Access Memory): technically refers to a type of memory where any byte can be accessed without touching the adjacent data, is often used to refer to the system’s main memory. This memory is available to any program running on the computer.
  • Page 77 UltraDMA-33/66/100: a fast version of the old DMA channel. UltraDMA is also called UltraATA. Without proper UltraDMA controller, your system cannot take advantage of higher data transfer rates of the new UltraDMA/UltraATA hard drives. USB (Universal Serial Bus): a versatile port. This one port type can function as a serial, parallel, mouse, keyboard or joystick port.

  • Page 78: Technical Support

    Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you.
  • Page 79 Notice for the USA Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation.
